Hasselblad DC POWER GRIP Datasheet

The Dc Power grip, compatible with all H system models, allows
you to ignore the need for a reserve battery grip or having to
take inhibiting power-conservation measures when working
untethered.
applications can range from working in the studio to
specialised set ups on location where timed surveillance
or remote controlled situations, for example, require the
camera to be on standby for long periods unattended.
The grip fits the camera in the conventional manner but
takes its power requirements from an exterior source, con-
nected via the supplied transformer. The outlet can be a
sPeciFicaTioN:
input Voltage
output Voltage
Dimensions (W x H x D)
Weight including grip
Dc cable length
Dc plug type
ac plug type
compatibility
DC Power Grip
100-240 Vac/50-60 Hz/1.3a
7.5 VDc / 6 a
50 x 30 x 135 mm (power supply)
135 g
2 meters
Ø 6 mm, centre pin 1,9 mm
iec 60320 c7
all H system cameras
regular domestic type, a generator or a battery/transformer
configuration that matches the specifications listed below. a
conventional ac plug on the transformer allows the freedom
to use a standard power cord suited to the requirements of
the country of use.
in addition, the conventional Dc plug on the grip also
allows a direct connection to a suitable matching power
pack (7.5 VDc / 6 a ) without the need for the transformer,
for the optimum in flexibility.
included items:
camera grip
Power supply
ac power cords for eU and Us
accessories
