Summary of Contents for Atosa AEC Series
- Page 22 Manual cooking operation instruction 3.4.1 Set up preheating Preheating is an option, but it is highly recommended to use the preheating function for better cooking results (except for particular cooking situation that must start from cold cooking condition). Preheating must be carried out with the oven empty when it reaches the set preheating temperature, the oven makes a beep and a window will pop up highlighting that the food has to go into the oven;...
- Page 23 Min Load, Med Load, Max Load, Disabled, after the selection, we will go back to the last page automatically and the preheating icon will become the selected preheating mode icon. When selecting Custom mode, we will enter the preheating temperature setting interface: ④How to customize the preheating temperature Three ways to set the temperature：...
- Page 26 Example 1：Choose timed cooking mode Choose timed cooking mode Timed cooking mode setting page Manual cooking mode selection page Fig 13 Fig 14 Example 2：Choose factory preset cooking mode（Steam） Choose factory preset cooking mode Manual cooking mode selection page Factory preset cooking mode selection page Fig 15 Fig 16 ＾...
- Page 28 、Set up the cooking temperature In the timed cooking mode or core probe cooking mode setting interface, click “ ”, and now we are in the cooking temperature setting page. Fig 18 Fig 17 How to set up the cooking temperature The way to set up the cooking temperature is the same as the way to set up the preheating temperature, please refer to page 21.
- Page 29 Fig 20 Fig 19 How to set up the temperature difference The way to set up the cooking temperature is the same as the way to set up the preheating temperature, please refer to page 21. Note 1： When setting the temperature difference by dragging the bar or clicking the icon, the temperature difference setting range is 86-284 F(30-140°C).
- Page 30 Fig 22 Fig 21 How to set up the core probe temperature the core probe temperature setting methods are the same as the preheating temperature setting methods, please refer to page 21. Note 1: when dragging the bar or clicking the icon to set the temperature, the setting range is 86-248 F(30-140°C).
- Page 31 ④、Cooking time setting In the timed cooking mode setting page, click “ ”to enter the cooking time setting page. Fig 24 Fig 25 Three ways to set the cooking time: 1. Dragging the bar please refer to “dragging the bar” of the setting of preheating temperature (page 22).
- Page 32 need to delete a digit, click , one click to delete one digit， then click to close the window. Noted: the value of min part is 0-60, if the input value is above 60, then will automatically go to the hour part, only the rest will remain in min(e.g. enter 70 and it will go 1 h and 10min);...
- Page 33 ⑥、Fan speed setting In the cooking parameter setting page, click the icon” ”and now we are in the fan speed setting page. Fig 30 Fig 29 How to set up the fan speed The method to set up the fan speed is the same as the method to set up the steam input, so please refer to the steam input setting instructions (page 31).
- Page 34 , the pause function is activated, while when the icon is grey , the pause function is deactivated. Noted: this function is mainly used when the user has set up several cooking phases, when a cooking phase finishes, the user will be reminded to open the oven and take out the food for adding condiments or other Fig 31 processes.
- Page 38 3.4.6 Cooking in process When the cooking is in process according to the set recipe, it will go from one phase to the next automatically, and on the screen the cooking processing interface will show up (please refer to fig 37). During the cooking process, the user can also: 1.modify the recipe；...
- Page 40 3.4.8 Save as recipe If the manual cooking process goes well and the cooking result is satisfying, you could save the manual process as recipe in order to restart it and to obtain the same cooking result next time. How to save as recipe 1.
- Page 41 4. After step 3, click and the cooking process is set as recipe successfully, please refer to fig 45 in below. Fig 45-1 Fig 45-2...
- Page 42 3.5 Cookbook this function is used to manage the factory-set recipes and the user's recipes. Through the cookbook, you can check all the saved recipes and the parameters of all recipes can be modified. These 3 icons are 3 filters useful for finding the recipe Filter 2：...
- Page 48 To activate the shelf Timing function, please follow the steps in below： ①Click the Shelf Timing icon enter timing mode selection page. ② Select a shelf timing mode Fig 55 (Multi-timer or Banquet), in the fig 56, Multi-timer is selected. Fig 56 ③...
-
Page 68: Circuit Diagram
5.2 Circuit diagram 5.2.1 AEC-0511E Circuit diagram ＾... - Page 69 －AEC-0511E ＾...
- Page 70 5.2.2 AEC-0711E/AEC-1011E Circuit diagram ＾...
- Page 71 －AEC-0711E/AEC-1011E ＾...
- Page 72 5.2.3 AEC-0621E ＾...
- Page 73 －AEC-0621E ＾...
- Page 74 5.2.4 AEC-1021E ＾...
- Page 75 －AEC-1021E ＾...
