- Page 1 DESIGNED FOR LIFE Assembly Instructions Model No. Little Tree by Tribesigns SideTable HOGA- SL0028 www.tribesigns.com...
-
Page 2: We're Here To Help You
DESIGNED FOR LIFE DESIGNED FOR LIFE Contact Us We're here to help you. support@tribesigns.com 1-424-220-6888 Contact us anytime except 12:00 AM to 8:00 AM EST. Your satisfaction is our top priority. If you encounter any issues with this product, such as missing or damaged parts, we're here to help. - Page 3 DESIGNED FOR LIFE We recommend using hand tools for assembly. AVOID SCRATCHES In order to avoid scratching, this furniture should be assembled on a soft surface, such as a rug. P-02...
- Page 4 DESIGNED FOR LIFE DESIGNED FOR LIFE Caution Make sure all parts are included. Most board parts are labeled or stamped on the raw edge. Contact us for a free replacement if you encounter any damaged or missing parts. P-03...
- Page 5 DESIGNED FOR LIFE Parts List 1 pc 1 pc 1 pc 8 pcs 1 pc Hardware List M6X20mm M6X35mm Ø15X12mm 32 PCS 32 PCS 4 PCS 4 PCS Ø6X30mm 1 PC 1 PC P-04...
- Page 6 DESIGNED FOR LIFE Installation of Cams and Pins Read each step carefully before starting. Each step of instruction should be performed in the correct order. If these steps are not followed in sequence, assembly difficulties may occur. No gap Screw the pin into the hole. Set the cams correctly by aligning the head of the cams with the lock pins.Lock the cam by turning the cam head with a screwdriver until it is tightened.
- Page 7 DESIGNED FOR LIFE M6x35mm 32 pcs Ø15X12mm 32 pcs Note: The circled hole of part #3 is on the same side as part #4. Ensure that the remaining seven #3 parts are installed accordingly. P-06...
- Page 8 DESIGNED FOR LIFE M6X20mm 4 pcs 4 pcs 100% P-07...
- Page 9 DESIGNED FOR LIFE Ø6X30mm 1 pc Please note the direction of installation of the double-ended bolt. The short-threaded end installs #1. The long-threaded end installs #2. P-08...
- Page 10 DESIGNED FOR LIFE Thank you for your support! Contact our customer service team 1-424-220-6888 support@tribesigns.com Contact us anytime except www.tribesigns.com 12:00 AMto 8:00 AMEST. Follow Tribesigns Instagram WhatsApp Facebook Pinterest Twitter YouTube TikTok...
