Summary of Contents for AQmatic F Series
- Page 1 F Series Inline Flow Meters Product Manual...
-
Page 2: Flow Performance
Specifications The core technology of the F Series inline flow meters is ultrasonic measurement. This eliminates internal moving parts and allows for a wider range of accuracy. The onboard integrated control within the meter sensor module calculates a “time of flight”... - Page 3 Dimensions and Identification On Power Up: LED flashes indicator of power applied and sequence to show how dip switches are set for meter size. 1 Flash F311 1” 2 Flashes F314 1 ½” 3 Flashes F315 2” 4 Flashes F317 3”...
-
Page 4: Application Guide
The meter sensor module can be aligned at any angle in the plumbing. The operation of the F Series meter requires that the “flow hoop” remain full without air bubbles at all times. Mounting the meter vertically with flow in the downward direction may not be advisable in some installations. -
Page 5: Parts And Accessories
Parts and Accessories Accessory... -
Page 6: Troubleshooting Guide
Troubleshooting Guide Problem Possible Solution Cause No signal communication Insufficient power When plugging in the wire harness, the LED should flash. This sequence of flashes will indicate the size meter the module is set for. If it does not, check for 5-24VDC on red (power) wire Cable connection not Verify that meter cable ends are properly connected at control and at properly made...
