sensorswitch PP5 SSA Installation Instructions

Relay pack power/relay pack family instruction

Advertisement

Quick Links

SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION
RATINGS
Electrical
Short circuit Current Rating (SCCR)
Mechanical
Environmental
Warrantied Operating Temperature
Contains FCC ID: 2ADCB-BMODIT
Contains IC: 6715C-BMODIT
Acuity Brands Lighting Inc.
In order to avoid the possibility of exceeding the FCC radio
frequency exposure limits, human proximity to the radiator
shall not be less than 20cm during normal operation.
NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC
Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. This
equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a
particular installation. If this equipment does cause harmful interference to radio or television reception, which can be determined by
turning the equipment off and on, the user is encouraged to try to correct the interference by one or more of the following measures:
SAVE THESE INSTRUCTIONS AND DELIVER TO OWNER AFTER INSTALLATION
• To reduce the risk of death, personal injury or property damage from fire, electric shock, falling parts, cuts/abrasions, and other hazards please read all warnings and instructions
included with and on the fixture box and all fixture labels.
• Before installing, servicing, or performing routine maintenance upon this equipment, follow these general precautions.
• Installation and service should be performed by a qualified licensed electrician.
• Maintenance should be performed by qualified person(s) familiar with the products' construction & operation & any hazards involved. Regular maintenance programs recommended.
• To be installed to a circuit with overvoltage control to Overvoltage category Cat.III or less, minimum suppression rating 6.0 kV for a 600 V ac rms system voltage
• DO NOT INSTALL DAMAGED PRODUCT! This product has been properly packed so that no parts should have been damaged during transit. Inspect to confirm. Any part damaged
or broken during or after assembly should be replaced.
CAUTION: RISK OF PRODUCT DAMAGE
√ Electrostatic Discharge (ESD): ESD can damage product(s). Personal grounding equipment should be worn
during all installation or servicing of the unit.
√ Do not touch individual electrical components, as this can cause ESD and affect product performance.
√ Do not stretch or use cable sets that are too short or are of insufficient length.
√ Do not tamper with contacts.
√ Do not modify the product.
√ Do not change or alter internal wiring or installation circuitry.
√ Do not use product for anything other than its intended use.
Acuity Brands | One Lithonia Way Conyers, GA 30012 Phone: 800.535.2465 www.acuitycontrols.com © 2019-2021 Acuity Brands Lighting, Inc. All rights reserved. Rev. 09/10/2024
PP5 SSA Relay Pack
POWER / RELAY PACK Family Instruction
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
Input Ratings
120-277VAC, 37.3mA @ 120VAC and 21.2mA @ 277VAC, 2.55W
10kA
120VAC, 800W, 6.7A Tungsten, Standard Ballast, Electronic Ballast
Maximum Load
277VAC, 1200W, 4.3A Tungsten, Standard Ballast, Electronic Ballast
Motor Load
1/2 HP
80
Dimming Load
Sinks
"D" 0-10V leads through chase nipple Class 1 or
"DS" 0-10V leads side output Class 2
Minimum Load
None
Mounting
1/2" Knockout (7/8" hole)
Wire Leads and Low Voltage Connector
Connection
-10°C to 50°C
Standards/ Ratings
RoHS, UL 916, UL 924 (optional), FCC / IC
This device complies with Part 15 of the FCC Rules. Operation is
subject to the following two conditions: (1) This device may not
cause harmful interference, and (2) this device must accept any
interference received, including interference that may cause
undesired operation.
La operación de este equipo está sujeta a las siguientes dos
condiciones: (1) es posible que este equipo o dispositivo no
cause interferencia perjudicial y (2) este equipo o dispositivo
debe aceptar cualquier interferencia, incluyendo la que pueda
causar su operación no deseada.
READ AND FOLLOW ALL SAFETY INSTRUCTIONS!
C
US LISTED
Full warranty terms located at: www.acuitybrands.com/CustomerResources/Terms_and_conditions.aspx
TITLE 20/24
√ Disconnect or turn off power before installation or servicing.
√ Verify that supply voltage is correct by comparing it with the
√ Make all electrical and grounded connections in accordance with
√ All wiring connections should be capped with UL approved
√ All unused connector openings must be capped.
mA; 0-10VDC dimmable ballasts or LED drivers
WHEN USING ELECTRICAL EQUIPMENT, BASIC SAFETY
PRECAUTIONS SHOULD ALWAYS BE FOLLOWED INCLUDING
• READ AND FOLLOW ALL SAFTEY INSTRUCTIONS
• DO NOT USE OUTDOORS
• SAVE THESE INSTRUCTIONS
• DO NOT USE THIS EQUIPMENT FOR OTHER THAN ITS
INTENDED USE
• DO NOT MOUNT NEAR GAS OR ELECTRIC HEATERS.
• EQUIPMENT SHOULD BE MOUNTED IN LOCATIONS AND AT
HEIGHTS WHERE IT WILL NOT READILY BE SUBJECTED TO
TAMPERING BY UNAUTHORIZED PERSONNEL.
• THE USE OF ACCESSORY EQUIPMENT NOT RECOMMENDED
BY THE MANUFACTURER MAY CAUSE AN UNSAFE
CONDITION.
Actual performance may differ as a result of end-user environment and application.
WARNING - RISK OF ELECTRIC SHOCK
product information.
the National Electrical Code (NEC) and any applicable local code
requirements.
recognized wire connectors.
2
,
IMPORTANT SAFEGUARDS
THE FOLLOWING:
WARRANTY
5-year limited warranty.
Note: Specifications subject to change without notice.
WARNING - RISK OF BURN or FIRE
√ Do not exceed maximum wattage, ratings, or published
operation conditions of product.
√ Do not overload.
√ Follow all manufacturer's warnings, recommendations
and restrictions to ensure proper operation of product.
CAUTION - RISK OF INJURY
√ Wear gloves and safety glasses at all times when
installing, servicing or performing maintenance.
1 of 3
