TERKKIN Intelligent Plastic Shed 6x8 ft Manual

Hide thumbs

Advertisement

Quick Links

Download this manual
MANUAL
6x8ft
Intelligent Plastic Sheds
Thank you for your purchase of the TERKKIN
shed.If you want to know more, please visit our
website.

Advertisement

loading
Need help?

Need help?

Do you have a question about the Intelligent Plastic Shed 6x8 ft and is the answer not in the manual?

Questions and answers

Related Manuals for TERKKIN Intelligent Plastic Shed 6x8 ft

Summary of Contents for TERKKIN Intelligent Plastic Shed 6x8 ft

  • Page 1 MANUAL 6x8ft Intelligent Plastic Sheds Thank you for your purchase of the TERKKIN shed.If you want to know more, please visit our website.
  • Page 2 • Keep the roof clear of accumulated snow and leaves. Large amounts of snow on the roof can damage the shed, making it unsafe to enter. Thank you for your purchase of the TERKKIN • Wind direction is an important factor to consider when determining the location of the shed.If you want to know more, please visit our...
  • Page 3 Installation precautions 1、 Site preparation Leveling the ground. 2、 Set up the base It is recommended to build a wooden base or concrete base.
  • Page 4 3、 Leave enough space 5、 Parts are placed after unpacking Operating space shall be reserved for external installation work. 4、 Tools required for installation Note: Installation requires two people to work together.
  • Page 5 contents Ⅰ.Product Introduction Ⅱ.Accessory & Parts Ⅲ.Installation guide...
  • Page 6 Ⅰ.【6x8ft Product Introduction】 Model：DBB_SSP_KC_SA05_0608DB Intelligent Plastic Storage Shed Size：96.93*74.21*89.21 in Color：Grey Base size：91.97*71.53 in Area covered：45.68 aquare feet 【No. 1 Intelligent Plastic Storage Shed_6x8ft】...
  • Page 7 Ⅱ.Accessory & Parts (1) KCP1.F1x3 KCP1.F2x1 KCPC1.Fx3 KCFTSx1 KCFB.B1x4 KCFB.B2x1 KCFB.U1x2 KCFB.U2x2 KCFB.U3x1 KCFB.U4x1 KCFB.U5x1 WPC.R x2 KCP1.W1 x3 KCP1.W2 x1 WPC.L x2 KCP2.W1 x2 KCP2.W2 x2 KCPC1.W1 x4 PC2.W3 KCP2.W4 x2 PC2.W2 KCP2.W3x2 PC2.W1...
  • Page 8 Ⅱ.Accessory & Parts (1) KCP2.Dx2 KCRBLx4 KCRBH.Bx4 KCRBH.Cx4 KCP1.R1x4 KCP1.R2x4 KCFFB.L6 x1 KCFBC x2 KCRBLC x2 KCRR x2 KCFFB.R6 x1 KCFRC x2 KCRRH x2 KCRBC.L x2 KCRBC.R x2 KCRRC x1 WIR2.OUTx1 WIR2.INx1 WIR2.PCx1...
  • Page 9 Ⅱ.Accessory & Parts (2) KCRSH x2 KCRSB x4 VNR2.OUT x2 VNR2.IN x2 KCRST x1 KCRPB x6 顶 顶 KCD1x4 KCD2 (x2x1) KCWST x1 KCWSC x4 KCRS2 x1 KCWSS x2 板 KCDMU x1 DPL x2 KCDBP x1 kcDMR x1 KCDML x1 DH1.H x2 KCD3 x1 门...
  • Page 10 Ⅱ.Accessory & Parts (3) Rubber sealing strip Flat Rubber sealing Flat Rubber sealing stripe x1 stripe x1 2mm*20mm 2mm*12mm 2mm*5mm kcPR x1 紧 x190 x164 ST5x14 ST3.9x12 ST2.9x20 ST4x14 ST3.9x30 ST2.9x8 M6×40 固 件 Install the guide piece M6x16 M8x80 x STICKER x2 PADSx2 x6 x2...
  • Page 11 Ⅲ.Installation guide (Base) PART kcFRC kcFB.B1 kcFFB.L6 kcFFB.R6 地 kcFTS 板 kcFBC 安 装 kcFB.B2 【Front view of base】...
  • Page 12 Ⅲ.Installation guide (Base) PART ST5x14 ST3.9X30 ST3.9x30 ST5x14 ST3.9x30 【Back view of base】 ST3.9x30...
  • Page 13 Ⅲ.Installation guide (Wall) 三、【安装指导过程详细说明】 PART kcWPC.L kcWPC.R WPC.L no strip inside 墙 板 安 装 strip outside 【Corner plates】 WPC.L and WPC.R same folding method...
  • Page 14 Ⅲ.Installation guide (Wall) P2.W1 PC1.W1 WPC.L P1.W1 P1.W2 ST2.9x8（8） WIR2.OUT WPC.L WIR2.PC WIR2.OUT ST2.9x20（12） WIR2.IN Install the guide piece KCP1.W2...
  • Page 15 Ⅲ.Installation guide (Wall) PART kcWPC.R PC2.W1 kcP2.W2 kcPC2.W1 P2.W2 P2.W2 PC2.W1 WPC.R...
  • Page 16 Ⅲ.Installation guide (Wall) PC1.W1 WPC.L P1.W1(x2) P2.W2 P2.W2 墙 WPY.W1 P1.W1 板 PART 安 kcWPC.L WPC.R kcP1.W1 装 kcP2.W1 WPC.R kcPC1.W1 kcWPC.R Insert the wall panels to the bottom...
  • Page 17 Ⅲ.Installation guide (Wall) WPC.R 墙 板 安 PART kcPCH 装 kcDMR kcDML Insert the wall panels to the bottom...
  • Page 18 Ⅲ.Installation guide (Wall) ST5x14 PART ST5x14 墙 ≈450mm 板 安 装 300~400mm ST5x14 FB.U5...
  • Page 19 Ⅲ.Installation guide (Vent) PC2.W2 ST3.9x12x6 PC2.W2 P2.W3 P2.W3 P2.W4 出 PC2.W3 VNR2.IN VNR2.OUT 风 口 墙 PART kcP2.W3 板 kcPC2.W2 kcPC2.W3 安 kcP2.W4 装 VNR2.OUT VNR2.IN ST3.9X12 kcDMU...
  • Page 20 Ⅲ.Installation guide (Vent) 出 风 ST4x14(x8 口 墙 PART ST4X14 板 kcDPL 安 装...
  • Page 21 Ⅲ.Installation guide (Roof ) M6×16（4） RSH x1 RSB x1 RSB x1 M6（4） 顶 RSB x1 板 RST x1 PART 安 kcRSB kcRSH 装 RSB x1 kcRST RSB x1 M6X40 M6 （8） M6X16 RSB x1 M6×40（8）...
  • Page 22 Ⅲ.Installation guide (Roof) RBL x2 RSH x2 KCRBLC x1 RBL x2 ST3.9x12 (10) ST3.9x12 (8) 顶 板 PART 安 kcRBL RBH.B x2 装 kcRBLC kcRBH.B ST3.9x12...
  • Page 23 Ⅲ.Installation guide (Roof ) P1.R2 Note: KCP1.R2 is aligned with 顶 KCRBH.B, KCRSB edges. 板 P1.R2 安 RBH.B PART 装 kcP1.R2 kcRPB...
  • Page 24 Ⅲ.Installation guide (Roof ) PART kcRBH.C ST3.9×12（4） ST3.9x30 ST3.9x12 顶 ST3.9x30 板 安 RBH.C 装...
  • Page 25 Ⅲ.Installation guide (Roof ) P1.R1 PART kcP1.R1 kcP1.R2 kcRPB P1.R2 P1.R1 P1.R1...
  • Page 26 Ⅲ.Installation guide (Roof) PART ST3.9x12 Note: Lock the screws after the top plate is flush with the U-shaped top. ST3.9x12...
  • Page 27 Ⅲ.Installation guide (Roof ) RBH.C(3) ST3.9x30(6) RBH.C RBH.B WSC(4) PART ST3.9x30 kcRBH.C ST3.9x12 kcWSC ST3.9x12(6) ST3.9x12(4)
  • Page 28 Ⅲ.Installation guide (Roof) PART kcRS1 KCRS1 ST3.9x12 顶 板 安 装 ST3.9x12(4) 【 RBH.C x2 】...
  • Page 29 Ⅲ.Installation guide (Roof ) 加 强 筋 安 PART 装 kcPR ST3.9x12 kcRS2 ST3.9x12(2) ST3.9x12(2) Note: The kcRS2 needs to be lifted and then the screws on both sides need to be tightened to lock. If the tie rod kcPR is too tight, you can turn the nut in the middle to adjust...
  • Page 30 Ⅲ.Installation guide (Roof ) Rubber sealing strip （X4 ） 顶 ST3.9x12(8) 板 PART 安 kcRR kcRRC 装 ST3.9x12 Rubber sealing strip 【 】 RR x2...
  • Page 31 Ⅲ.Installation guide (Roof ) RRHx2 ST3.9x30(x10) Note: Press down both 顶 ends of the daylighting ridge, lock both ends ST3.9x12(2) 板 first and then lock the PART middle. 安 kcRRH ST3.9x30 装 ST3.9x12 【 】 RRH x2 ST3.9x12(8)
  • Page 32 Ⅲ.Installation guide (Roof) RBC.L RBC.R PART kcRBC.L kcRBC.R ST3.9x12 顶 板 ST3.9x12(8) 安 装 【 】 RBC.L x2 RBC.R x2...
  • Page 33 Ⅲ.Installation guide (Floor) PC1.F(x3) P1.F1(X2) P1.F2 P1.F1 【Base front】 PART kcP1.F1 kcPC1.F kcP1.F2...
  • Page 34 Ⅲ.Installation guide (Floor) ST5x14 PART ST5X14 kcFB.U1 kcFB.U2 kcFB.U3 kcFB.U4 kcFB.U5 ST5x14 we have 7 KCFB.U,they are around the base. FB.U3 FB.U1 FB.U2 ST5x14 FB.U1 FB.U2 FB.U5 FB.U4 【Install the edge strip】...
  • Page 35 Ⅲ.Installation guide (Roof) PART WSU x1 kcWSU kcWSE.S1 kcWSD M6×40 顶 ST3.9x12(6) M6 x2 ST3.9X12 板 M6×40 x2 安 WSE.S1 装 M6 x2 M6×40 x2 ST3.9x12 ST3.9x12 x2 WSD x1 ST3.9x12...
  • Page 36 Ⅲ.Installation guide (reinforcing rib) PART kcWSE.S2 ST3.9x12 kcWST WSE.S2 ST3.9x12 ST3.9x12 加 M6X40 强 kcWSD 筋 M6×40 安 ST3.9x12 WSE.S2 装 WSE.S2 ST3.9x12 M6×40 ST3.9x12 WSD x1...
  • Page 37 Ⅲ.Installation guide (Left Door ) ST4x14 PART kcD2 kcP2.D kcDBP kcDBV kcDBH ST4X14 M4X6 kcD4 P2.D x1 ST4x14 M4X6 【Door Inside】 Install KCD2 x2 KCD4 X1...
  • Page 38 Ⅲ.Installation guide (Left Door ) PART DH1.H kcD1 ST3.9X30 ST3.9X12 ST4X14 ST4x14 左 门 DH1.H 板 D1 x2 ST3.9x12(2) 组 装 【Door Outside】 【KCD1 x2 】 ST3.9x30(2 )
  • Page 39 Ⅲ.Installation guide (Right Door ) ST4x14 右 门 P2.Dx1 板 PART ST4x14 组 kcP2.D 装 kcDBV 【Door Inside】 kcDBH ST4X14 kcD4 kcD4...
  • Page 40 Ⅲ.Installation guide (Right Door ) PART DH1.H Door DH1.H Inside ST3.9x12(2) kcD1 ST3.9X30 ST3.9X12 ST4X14 右 ST3.9x30(2) 门 D1x2 板 组 装 ST4x14 【Door Outside】 【 D1x2】...
  • Page 41 Ⅲ.Installation guide (Door ) 门 板 PART 安 ST4X14 装 ST4x14（4） ST4x14（4） 【 】 【 】 D1 x2 D1 x2...
  • Page 42 Ⅲ.Installation guide PART ST5X14 kcD2 ST5x14（2） 磁 吸 KCD2 开 关 安 装...
  • Page 43 Ⅲ.Installation guide (Door ) PART Wedge shaped cushion block 门 板 安 装 【When the door is not closed smoothly, it needs to be leveled or adjust by tighten or loosen the hinge.】...
  • Page 44 Ⅲ.Installation guide (Anchor bolts) PART M8X80 M8x80 (x2) M8x80 (x3) （X2）...
