Summary of Contents for Tangerine NetComm NL20MESH
- Page 1 NetComm NL20MESH Quick Start Guide This guide provides instructions for setting up, connecting, and configuring your NetComm NL20MESH. NetComm NL20MESH Quick-Start Guide tangerine.com.au...
- Page 2 Contents: Get to Know Your NetComm NL20MSH......................Setting Up Your NetComm NL20MESH......................Configuring Your NetComm NL20MESH....................... Other Important Information About Your NetComm NL20MESH..............Configuring your phone..........................Need Support?............................NetComm NL20MESH Quick-Start Guide tangerine.com.au...
- Page 3 Get to know your NetComm NL20MESH The NetComm NL20MESH delivers a new adaptive Wi-Fi experience to your home with improved Wi-Fi speed, performance, and efficiency. The NetComm NL20MESH’ s key features include: • Mesh-enabled for seamless connection to CloudMesh Satellites •...
- Page 4 Red = Disconnected ● Yellow/Amber = Connected ● but weak/moderate signal strength (enable but inactive) Back view of the device Power Supply Jack Reset VoIP USB 3.0 Ethernet WAN Port Button Port Port Port LAN Ports NetComm NL20MESH Quick-Start Guide tangerine.com.au...
- Page 5 Connect your ethernet based devices (e.g., desktop, computer, Ethernet LAN Ports laptop, and/or router). Connect network termination device (NTD) for highspeed WAN Port internet access. Fibre to the Premises (FTTP), Fibre to the Curb (FTTC), Hybrid Fibre Coaxial (HFC), Fixed Wireless (FW). NetComm NL20MESH Quick-Start Guide tangerine.com.au...
- Page 6 On/Off Button (3) seconds and toggle the LED WPS/LED Button Will trigger the Wi-Fi Protected Setup (WPS) function when held down for approximately three indicators on or off when held for approximately six (6) seconds. NetComm NL20MESH Quick-Start Guide tangerine.com.au...
- Page 7 Wait a few minutes for it to start up. Step 2: Connect your NetComm NL20MESH Depending on your nbn® technology type, your NetComm NL20MESH will connect differently. If you are unsure of your nbn® technology type, it is listed in your nbn® ordered email. Instructions: If your nbn®...
- Page 8 Instructions: Fibre to the Node (FTTN ) Connect the DSL cable from the DSL port on the NetComm NL20MESH to the wall socket. Connect Fibre to the Building (FTTB) or the power adaptor from the power supply jack to VDSL (over a traditional telephone line) the power outlet.
- Page 9 QR code. WIFI CARD Connecting a telephone to a NetComm NL20MESH Connect a regular telephone handset to the NetComm NL20MESH by connecting the cable from the VoIP port to the telephone handset. NetComm NL20MESH Quick-Start Guide...
- Page 10 If you have factory-reset your device or purchased from an alternative retailer, please follow these easy steps to access the configuration page of your NetComm NL20MESH. 1. Push the power button on the side of the NetComm NL20MESH to turn it on. Wait a few minutes for it to complete start up.
- Page 11 Hybrid Fibre Coaxial (HFC), Fibre to the Premises (FTTP), Fibre to the Curb (FTTC), Fixed Wireless (FW) 1. Push the power button on the side of the NetComm NL20MESH to turn it on. Wait a few minutes for it to complete start up.
-
Page 12: Need Support
2. At the login screen, type in ‘admin’ as your username and the password printed on the label on the bottom of the NetComm NL20MESH and login. 3. Select ‘Voice’ from the menu on the left-hand side of the screen and select ‘SIP Basic Setting’.
