E-Jet EIR070 Assembly Instructions Manual

Double shot basketball arcade light-up

Download this manual

148MM

MODEL: EIR070

NAME: DOUBLE SHOT BASKETBALL ARCADE

LIGHT-UP

ASSEMBLY INSTRUCTIONS

Need help?

Do you have a question about the EIR070 and is the answer not in the manual?

Page 1 148MM MODEL: EIR070 NAME: DOUBLE SHOT BASKETBALL ARCADE LIGHT-UP ASSEMBLY INSTRUCTIONS...
Page 2: Assembly Tips
ASSEMBLY TIPS: 1 - Please read the instructions carefully, and follow all assembly, operation or safety instructions properly in order to avoid damage or injury. 2 - Some figures or drawings may not look exactly like your product. Please read and understand the text before beginning each assembly step.
Page 3: Parts List
PARTS LIST For FIG. 1,5,8 For FIG. 1 For FIG. 2 For FIG. 6 Tube -1 (Ø25.4x698mm) Tube -2 (Ø25.4x514mm) Tube -3 (Ø25.4x584mm) Tube -4 (Ø25.4x610x610mm) (6pcs) (4pcs) (2pcs) (2pcs) For FIG. 2 For FIG. 5 For FIG. 5 For FIG. 3 Tube -5 (Ø25.4x464mm) Tube -6 (Ø25.4x349mm) Tube -7 (Ø25.4x206mm)
