Philips HSB2313 Service Manual
Hide thumbs
Also See for HSB2313:
- Service manual (32 pages) ,
- User manual (21 pages) ,
- Specifications (2 pages)
Table of Contents
Advertisement
Quick Links
SoundBar System
TABLE OF CONTENTS
Location of PC Boards .................................................... 1-1
Electronic Specification ................................................... 1-2
Measurement Setup ....................................................... 1-3
Service Aids ................................................................... 1-4
Items Of Safety Attention ......................................1-5 to 1-6
Instruction On CD Playability .................................1-7 to 1-8
Software Version Check & Upgrade .............................. 2-1
Malfuction Check Chart .................................................. 2-2
...................................................3-1
Block Diagram ................................................................. 4-1
Wiring Diagram................................................................. 4-2
Display Board .....................................................................5
Circuit diagram ........................................................... 5-1
Layout diagram ........................................................... 5-2
Small Board ........................................................................6
Circuit diagram ...........................................................
Layout diagram ...........................................................
HDMI Board ........................................................................7
Circuit diagram ...........................................................
Layout diagram ...........................................................7-2
2011
LX 1119
Version 1.2
Terminal Output Board ....................................................... 8
Circuit Diagram ...........................................................8-1
Layout Diagram ..........................................................8-2
Decoder Board .....................................................................9
Circuit diagram ..................................................9-1 to 9-4
Layout diagram ............................................................9-5
Power Board ........................................................................9
Circuit diagram ..............................................10-1 to 10-2
Layout diagram ..........................................................10-3
Explode View ....................................................11-1 to 11-2
Service Partlist ....................................................12-1 to 12-2
Factory Partlist ....................................................13-1 to 13-4
.
6-1
.
6-1
.
7-1
HSB2313
3141 785 32522
Advertisement
Table of Contents
Related Manuals for Philips HSB2313
Summary of Contents for Philips HSB2313
-
Page 1: Table Of Contents
HSB2313 SoundBar System TABLE OF CONTENTS Location of PC Boards ............ 1-1 Electronic Specification ........... 1-2 Terminal Output Board ............8 Measurement Setup ............1-3 Circuit Diagram ............8-1 Service Aids ..............1-4 Layout Diagram ............8-2 Items Of Safety Attention ........1-5 to 1-6 Decoder Board ..............9... -
Page 2: Location Of Pc Boards
Location of PC Boards Decoder Board SP Connect Board HDMI Board Display Board Terminal Out-put Board VERSION VARIATIONS : Type /Versions: HSB2313 Service policy Board in used: USB BOARD DISPLAY BOARD HDMI BOARD RADIO TRANSMIT BOARD DECODER BOARD OUTPUT BOARD... -
Page 3: General Information
AMPLIFIER Rated Output Power ..120W+(45W+45W) x 2RMS Speaker Impedance ..........Signal-to-noise ratio Speaker Driver, base Frequency response Speaker Driver, tweeter Aux Input kohm Frequency Response DISC GENERAL INFORMATION Laser Type ............NA Total Output power ........2 0 0 W RMS Disc Diameter .............NA AC Power ............. -
Page 6: Items Of Safety Attention
Items of Safety Attention Maintenance Attention Common Soldering Rules Use only grounded low-voltage soldering iron, and proper size and Attention: Please read <Items of Safty Attention> carefully. If shape which can sustain the temperature of soldering horn to there are unexpected conflicts between safefy attention and range from 350 to 390. - Page 7 Items of Safety Attention Unsolder/replace diode After unsoldering the unusable diode, nip its body and take it out. Bend the two pins and the diode is vertical to circuit board. Check the polarity of the diode, then place its pins to the correct location.
-
Page 8: Software Version Check & Upgrade
Softwaer Version Check & Upgrade Upgrade software 1.Downloading the software form Philips support website http://www.philips.com/support 2.Insert the Software USB device,when it is loading , VFD display showing as below: Upgrading Waiting a minute,till the VFD display as below: Read USB Software upgrade finish. - Page 9 Malfunction Follow Check Chart Not power Not sound Time/Clock does not work No display Not picture on HDMI connection Replace a new Check if the HDMI cable Check if the Power Cord Adjust the volume Plug in the power cord Check the files or folders in HDMI cable is faulty...
-
Page 10: Disassembly Diagram
Disassembly Diagram Losen these screws to remove HDMI board Use thin screwdriver to unclench clasp Losen these Screws(both sides) Losen these Screws Losen these screws to remove Main Board Losen these screws to remove Display Board Losen these screws to remove Decoder Board unclench clasp Losen these screws to remove Output Board... -
Page 11: Block Diagram
Block Diagram MCU5V VFD Display VFD_3280 -24V MCU5V VFD Driver PT16311 ECO POWER MP3 LINE IN POWER SUPPLY -24V DISPLAY BOARD AV1 IN AV OUT V_12V 34.5V Video Switch 2244 JRC TRE SPK MID SPK1 MID SPK2 MID SPK3 LM358 V_12V 3.3V (3 Ohm 45W at 15%) * 4... -
Page 12: Wiring Diagram
Wiring Diagram HDMI BOARD TERMINAL OUT-PUT BOARD MAIN DECODER BOARD CONNECT BOARD CONNECT BOARD VFD DISPLAY BOARD HEADPHONE BOARD... - Page 13 Display Board -- Circuit Diagram 35-HSB2303-03A1 VFD301 NE-3280-1.GBY MCU+5V R348 IR301 AD_KEY SW301 SW302 C301 SOURCE POWER R311 R310 R349 IR VCC VFD1 -27V R346 R350 CE301 C305 2.2 1/2 47u/16 S DZ303 VFD2 CE310 R347 A+5V 4.7u/35 S SW304 SW305 SW307 SW309...
-
Page 14: Layout Diagram
Display Board -- Layout Diagram... -
Page 15: Small Board
Small Board -- Circuit-Layout Diagram 35-HSB2313-07A1 35-HSB2313-08A1 35-HSB2313-05A1 USB/HEADPHONE BOARD SP CONNECT BOARD LAMP BOARD J501 CN502 CN702 AUX3_L USB501 TRE+ USB 5V AUX3_R CN501 TRE- AGND R502 CN701 USBP R503 HP-JACK6 CVBS3 TRE- 2.0/2P LED801 USBM R504 TRE+ CN703... - Page 16 HDMI Board -- Layout Diagram HDMIA_5V R145 NC/0 VDD_9950 R146 NC/0 HDMIC_5V VDDH HDMI TYPE-A RXA2+ FB/600 VDD_9950 TDA9950TT/C3 RXA2- VDDH TDA9950TT-TSSOP20 RXA1+ VDD1V8 R116 RXA1- CB39 CEC_POL RXA0+ VDDH 0.1u I_00 RXA0- RXAC+ HPD_C R114 MCU_SDA I_01 CEC_OUT ONT_POL VDDC1V8 VDDC1V8 RXAC-...
- Page 17 HDMI Board -- Layout Diagram...
-
Page 18: Circuit Diagram
Terminal Out-put Board -- Circuit Diagram PVDD32V PVDD32V 3.3V +12VA FB/600 +CE1 3.3V VDDI3.3V 0.1u 47UF/10v CVBS_OUT_DVD NC/33 PVDD32V AUIN1_L AUIN2_L +12V 0.1uF CON2.0-8 0.1uF 100uF/16V AUIN3_L 2244 220uF/16V DC-023 AUIN4_L AUX1_AV 100uF/16V CVBS_OUT 2.2u/16V IN-1 AD_INL FB/600 FB/600 VADC3.3V AUIN1_R AUX2_AV 100uF/16V... - Page 19 Terminal Out-put Board -- Layout Diagram...
-
Page 20: Decoder Board
Decoder Board -- Circuit Diagram JITFO 1000pF JITFN DV33 750k ADACVDD 150uH APLLVDD3 47uH RFV33 RFV33 RFVDD3 DACVDD3 1.8uH 100uF/6.3v 10uF/10v 10uF/16v R184 0.1uF CAP-4X7MM 0.1uF 0.01uF 2200pF 0.1uF 75 1% 470uF/10v 47pF 47pF 0.1uF RFV18 4.7uF PLLVDD3 0.1uF 10uF/10v 0.1uF DV33 0.1uF... - Page 21 Decoder Board -- Circuit Diagram DV33 89_SD33 89_DQ[0..15] 89_DQ[0..15] 89_MA[0..11] 89_MA[0..11] DRAM 89_BA[0..1] 89_BA[0..1] 89_DQM[0..1] 89_DQM[0..1] 89_DCLK 89_DCLK CE13 CB29 CB30 CB31 CB32 CB33 CB34 CB35 89_DCKE 89_DCKE 89_AD[0..7] 89_CAS# 100uF/10v 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 0.1uF 89_AD[0..7] 89_CAS# 89_RAS# 89_RAS# FLASH...
- Page 22 Decoder Board -- Circuit Diagram MCU+5V CPU5V L32 FB PCF8563 AD_KEY NC/10K STANDBY MSDA 2328_DET 2328_DET MCU+5V NC/10K ECO_POWER 3.3K MSDA MSCL PWM_SW+ PWM_SW+ VFD_CLK MSCL PWM_SW- PWM_SW- VFD_DATA R162 DVD_ON OSCO VFD_STB 24C02 R163 XOUT 1N4148 SSDA SSDA REMOTE MSDA R164 CPU5V...
- Page 23 Decoder Board -- Circuit Diagram PWM_SW+ PVDD32 R268 PWM_SW- 22UH/3.2A AVDD3.3V R269 PVDD32 R270 AVDD3.3V R101 R100 R102 3.3R CE60 10uF/16V CB123 CB124 3.3R CE22 CB71 CB72 2.7K 1U/50V 0.1uF 0.1uF + CE23 R104 3.3R R271 CB75 100uF/50V 104/50V 104/50V 220uF/50V CON2.54-2 TAS5508B...
- Page 24 Decoder Board -- Layout Diagram...
-
Page 25: Power Board
10-1 10-1 Power Board -- Circuit Diagram H_VCC MOS3 EI33 STTH2003 CT CON_VCC 68UF/400V 103/1KV 471/400V 103/630V 100K/1W 7UH/4A &' GBU4J 1000 U/35V 68UF/400V FR157 471/400V 1000 U/35V R88-R91 102/1KV 100R MOS2 FR104 8N60 221/1KV 5.6K 150K 0.22U/275V TL431 EL817 47UF/50V T68-26A 100K... -
Page 26: Circuit Diagram
10-2 10-2 Power Board -- Circuit Diagram CE21 470UF/25v Vfan CE24 CE26 470U/25V 470U/25V 4.7K 2P/2.5 BAND 470uf/16v CE18 CE19 220uf/16v CE27 470U/25V 103/50V 4.7K CE25 9014 CE14 470U/25V CE11 1uf/25V 4.7uf/50v CE28 103/50V 9014 100U/25V 2.2K 8550 470R 4.7K IN1+ 0.15R 2W OUT1+... -
Page 27: Layout Diagram
10-3 10-3 Power Board -- Layout Diagram... -
Page 28: Explode View
11-1 11-1 Explode View... - Page 29 11-2 11-2 Subwoofer Box -- Exploded View SUBW2 SUBW1...
-
Page 30: Service Partlist
Service Part List ACCESSORIES PARTS LIST HSB2313/12 GIFT BOX REMOTE CONTROAL (YKF223-013) AV WIRE 1.5m/RCA JACK(YELLOW)/BLACK AV WIRE 1.5m 3P RED/WHITE/YELLOW HSB2313/12 MAIN SPEAKER BOX HSB2313/12WOOFER SPEAKER BOX MACHANISM & MISCELLENOUS PARTS LIST S120 HSB2303 BACK OUT-PUT PC SHEET S101... - Page 31 12-2 Service Part List ELECTRICAL PARTS LIST -- COMPONENT REPAIR SW302 TACT SWITCH 6X6X5 250g SW303 TACT SWITCH 6X6X5 250g SW304 TACT SWITCH 6X6X5 250g SW305 TACT SWITCH 6X6X5 250g SW306 TACT SWITCH 6X6X5 250g SW307 TACT SWITCH 6X6X5 250g SW308 TACT SWITCH 6X6X5 250g SW309...
-
Page 32: Factory Partlist
13-1 Factory Part List HSB2313/12 MAIN PARTS ASS'Y CE303 ELECTROLYTIC CAP.47 35V L-5 105 6.3X7 3 3024BCS01-217 BLUE TRANSFORMER EPC13 5V 14X11X7... - Page 33 DVD DISPLAY PCB 35-HSB2303-03A1 225X50 BLACK SPONGE 15X10X2.5 40° BLACK SPONGE 10X10X8 75° < < — 0.6X40mm (375m=1kG) USB PCB 35-HSB2313-05A1 51X23 CONNECT PCB 35-HSB2313-07A1 40X32.5 HSB2313/12 SOFTWARE HSB2313/12 MCU SOFTWARE HSB2313/12 MIAN SOFTWARE DVD DECODER EJS89H2313-12 MICA INSULATION SHEET 15.5X11...
- Page 34 MINI FAN RDM4010S/DC12V/0.07A SCREW 3 X 18 PTH (PLATING) HSB2313/12WOOFER SPEAKER BOX CASING HSB2313/12 WOOFER LAMP BOARD 3 3024BCS01-217 BLUE WOOFER LAMP PCB 35-HSB2313-08A1 22X21 SUBWOOFER 6 1/2" 3 150W 90 HSB2303 SUBWOOFER METAL BOTTOM HSB2303 WOOFER TOP COVER(HIPS) HSB2303 WOOFER GRILLE(ABS)
- Page 35 PLASTIC BAG(PE) 23X14cm HSB2313/12 PACKING PARTS HSB2303 POLYFOAM HSB2313/12 GIFT BOX PASSED LABEL HSB2313/12 GIFT BOX LABEL HSB2313/12 MAIN SET LABEL 45X13 HSB2313/12 SPECIAL LEBEL HSB2313/12 MAIN SERIAL NO LABEL HSB2313/12 MAIN MODEL LABEL HSB2313/12 POS BILLBOARD PLASTIC BAG(PE) 56X21cm...
