Ya-man Medi Lift EPM-18-G User Manual

Electrical muscle stimulation (ems) mask
Hide thumbs Also See for Medi Lift EPM-18-G:
Table of Contents

Advertisement

Quick Links

Download this manual
Medi Lift Essential
Electrical Muscle Stimulation (EMS) Mask
EPM-18-G
USER MANUAL
Please read all instructions carefully for safe and proper use.
Use only as directed
—improper use may cause injury or malfunction.
Immediately discontinue use if any malfunction or unusual reaction to treatment occurs.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Medi Lift EPM-18-G and is the answer not in the manual?

Questions and answers

Related Manuals for Ya-man Medi Lift EPM-18-G

Summary of Contents for Ya-man Medi Lift EPM-18-G

  • Page 1 Medi Lift Essential Electrical Muscle Stimulation (EMS) Mask EPM-18-G USER MANUAL Please read all instructions carefully for safe and proper use. Use only as directed —improper use may cause injury or malfunction. Immediately discontinue use if any malfunction or unusual reaction to treatment occurs.

  • Page 2: Quick Start

    QUICK START CHARGING THE ATTACH THE TWO GENEROUSLY FIT THE SILICONE LEFT AND RIGHT CONTROLLERS TO WET YOUR MASK TO YOUR CONTROLLERS THE SILICONE MASK CHEEKS FACE Magnetic connector AC adapter Charging pins USB terminal Check the left/right attachment EMS will NOT be delivered to skin Look for the “L”...

  • Page 3: Turn Off The Device

    PLACE THE TURN ON SELECT YOUR MOST TURN OFF THE ADJUSTABLE BAND IN A EACH OF THE COMFORTABLE LEVEL DEVICE POSITION AS SHOWN CONTROLLERS OF EMS INTENSITY Pull the band over the top of your Press the +/ON button for 2 You can change the intensity of the The device will automatically turn head to secure the mask in place.

  • Page 4: Table Of Contents

    Table of Contents Intended Use –––––––––––––––––––––––––––––– Getting To Know Your Device –––––––––––––––– Contraindications ––––––––––––––––––––––––– How To Use –––––––––––––––––––––––––––––––p12 Possible Side Effects –––––––––––––––––––––––– Storing the Device –––––––––––––––––––––––––p21 Intended User Population ––––––––––––––––––– Maintenance and Disposal ––––––––––––––––– WARNINGS ––––––––––––––––––––––––––––––– Troubleshooting –––––––––––––––––––––––––– Precautions ––––––––––––––––––––––––––––––– Specifications ––––––––––––––––––––––––––––...

  • Page 5: Intended Use

    „ Intended Use This device is intended for facial stimulation and indicated for over-the-counter cosmetic use. „ Contraindications Do not use this device if: You have an implanted pacemaker or other electronic implanted devices. You have an arrhythmia or any other known heart disorder. You have epilepsy, multiple sclerosis, phlebitis, varicose veins, cancer, or a tendency to hemorrhage.

  • Page 6: Possible Side Effects

    „ Possible Side Effects Skin irritation, affected fillings/toothache, and burns beneath the electrodes have been reported when using powered muscle stimulation devices on the face. If you experience such side effects, please discontinue use of the device. MedWatch is the Food and Drug Administration's (FDA) program for reporting serious reactions, product quality problems, therapeutic inequivalence/ failure, and product use errors with human medical products, including drugs, biologic products, medical devices, dietary supplements, infant formula, and cosmetics.

  • Page 7: Intended User Population

    „ Intended User Population The Medi Lift is intended for persons 22 years of age and older. Do not use on children. Keep out of the reach of children. WARNINGS „ This device is not intended for use by persons with reduced physical, sensory or mental capabilities, or lack of experience and knowledge. Apply the silicone mask with the controllers ONLY as instructed in this manual Only use the provided controllers with the mask.

  • Page 8: Precautions

    Do not use the Medi Lift while driving, operating machinery, cycling or any activities which involuntary muscle contractions may endanger the user or others. Do not use the device if you are connected to high frequency surgical device. It may result in burns at the site of the electrodes and possible damage to the controllers.

  • Page 9: Getting To Know Your Device

    „ Getting To Know Your Device Controllers For left side of the cheek For right side of the cheek       Front               ...
  • Page 10 Controllers generate electrical current. Description of the controller Name Description  Electrode Delivers electrical current to the face. Pink light when the device is turned on. The pink LED is turned off when the device is turned off.  LED Signals Blinks blue when the device is charging.
  • Page 11 Silicone mask Front       Seam line for the hook  and loop fastener  Loop Back     ’      Hook 10 10...
  • Page 12 The controllers are attached to the silicone mask. The mask holds the controllers in place during the facial stimulation from the device. Description of the silicone mask Name Description  ’ Hook and loop fastener Secures the mask on user’s head. ...

  • Page 13: How To Use

    How To Use CAUTION Before each use, check the device components and parts for any cracks, deformation, or other damage. Do not use if you see any sign of damage to avoid injury or malfunction. Do not use the device in humid places such as in a bathroom, in or near water, or outdoor to avoid injury or failure of the device. Charging the device Let the device sit at room temperature for 60 minutes.
  • Page 14 Plug the AC Adapter into a wall outlet. Check that the LED light is flashing in blue. Charge the device until the LED light has turned solid blue or turned off. When the device is fully charged, blue LED lights up for one minute, then the light turns off. Unplug the AC adapter and the USB cable after the battery is fully charged. Magnetic connector AC adapter Charging pins...

  • Page 15: Preparation Of The Device

    Preparation of the device Place the back side of the silicone mask face-up on a table or flat surface. The back side of the mask has a slip resistance sheet at the left tip and marks for the controllers. Check the controllers for placement on the mask. The back of each controller is labeled either “R”...
  • Page 16 First, attached the Left side controller to the Left side of the mask. Adjust the position of the controller with grooves and holes in the mask and press the controller down until the controller is attached to the mask. CAUTION Do not use the excessive pressure when attaching the controllers to the silicone mask.
  • Page 17 Preparing for a muscle toning session Tie your hair back if it is long to avoid catching the hair between the mask and your skin. Wash your face to remove make-up, oils, creams and lotions. Use the device only on clean skin. Note: Some cosmetics may enhance friction between the electrodes and your skin during EMS treatment and transferring black colorants of the electrodes to your skin.
  • Page 18 Applying the silicone mask to your face Sit in front of the mirror. Place the back side of the silicone mask with the controllers face-up on the flat surface. Hold the mask with both hands and place the mask on your face. Adjust the mask under your eyes, the nose guide on your nose, and the mouth opening on your mouth.
  • Page 19 Pull the tab under your chin and adjust the mask so that it covers your lower jaw line. If the mask does not cover your lower jaw line, the mask is not worn correctly. If such case, detach the mask form your face and return to step 13.

  • Page 20: Turning Off The Device

    Treatment Turn the power ON by pressing +/ON buttons on left and right controllers for at least one second simultaneously. Note: A long beep will sound and the lamp will light in pink when the device turns on. Note: When the power turns on, no current is generated. Select EMS intensity by pressing +/ON buttons to increase the intensity or -/OFF buttons to decrease the intensity.
  • Page 21 Cleaning your device Note: Clean the mask after every use. Detach the controllers from the silicone mask. Wipe off any dirt on the controllers and electrodes using a damp with water soft cloth. CAUTION To avoid an electrical shock, short circuit or a fire, ensure to turn off the controllers before detaching form the mask. Do not immerse the controllers and electrodes in water or other liquid.

  • Page 22: Storing The Device

    „ Storing the Device The device can be stored in a place that is -25°C (-13°F) to 5°C (41°F). It can also be stored in 5°C (41°F) to 35°C (95°F) as long as the humidity is no more than 90%, non-condensing. >35°C (95°F) to 70°C (158°F) at a water vapor pressure up to 50hPa. Do not use, charge, or store if the device is hot.

  • Page 23: Maintenance And Disposal

    This appliance contains batteries that are non-replaceable. Do not attempt to replace the battery yourself. Please contact YA-MAN USA if there are any issues with your device or if you need a replacement battery. The battery can be charged approximately 300 times. The rechargeable battery is a consumable item and is not covered under the warranty. Do not use the device if the battery powers the device for an extremely short period of time after charging.

  • Page 24: Troubleshooting

    „ Troubleshooting If you need help setting up, using, or maintaining the device, please contact YA-MAN USA. To avoid fire, electrical shock, or injury, do not disassemble, attempt to repair, or modify this device in any way. Issue Possible cause and solutions Raise EMS intensity with +/ON button (P.19).
  • Page 25 Low battery. Remove the device from your fare and charge the battery (P.12, 13). for a few minutes even The battery life has ended. Contact YA-MAN USA for a new battery. after charging Battery is not properly charged. Be sure that the blue lamp is blinking when charging.

  • Page 26: Frequently Asked Questions

    Frequently Asked Questions We recommend using the device once a day for 10 minutes. How often should I use the Note: The device will automatically turn off 10 minutes after the EMS intensity is device? selected. Moisten your cheek but do not apply so much water so that it is dripping. How much water should be The controllers are not waterproof.
  • Page 27 What should I do if I feel physical Immediately stop using this device and consult a physician. discomfort and fatigue? You may feel tooth pain when you are undergoing dental treatment or having What should I do if I feel silver-crowned tooth.

  • Page 28: Specifications

    „ Specifications Model Number EPM-18-G Dimensions Silicone mask: W580×H170 (mm) Controller: W90×H55×D20 (mm) (one piece) Weight Silicone mask: 120g Controller: 28g (one piece) Input of AC Adaptor 100-240Vac 50/60Hz 0.3A Output of AC Adaptor 5Vdc 0.6 A Power consumption 1W (AC input, When the device charging with AC adaptor) Classification Internally powered equipment, Class II charger, Type BF applied parts.
  • Page 29 Electromagnetic Information Test Standard Class/Test conditions Test result Emission (IEC60601-1-2:2014 Clause7) Conducted disturbance at mains terminals CISPR11 Group1, Class B on AC120V, 60Hz Pass Radiated disturbance CISPR11 Group1, Class B on AC120V, 60Hz Pass Harmonic current emissions IEC61000-3-2 Not applicable Voltage fluctuations and flicker IEC61000-3-3 Not applicable...

  • Page 30: Labeling And Signs

    „ Labeling and Signs Controller’s sign example Symbol Number of Standard Meaning IEC60417-5031 Direct current (DC) IEC60529 Solid particle protection is class 2, and Liquid ingress protection is class 2. IEC60417-5333 Type BF applied part Waste electrical and Electronic Equipment (WEEE) Disposal Waste BS EN 50419:2005 electrical and electronic equipment must not be disposed of as unsorted municipal waste and must be collected separately.
  • Page 31 AC adaptor’s sign Symbol Number of Standard Meaning IEC60417-5172 Class II equipment IEC60417-5957 Marking to identify electrical equipment designed primarily for indoor use. The device complies with regulations established by the Federal FCC mark Communications Commission relating to the amount of radio frequency emissions allowed such that other device are not adversely affected.
  • Page 32 San Diego, CA 92121 https://www.mediliftbeauty.com/ USA Call 877-231-9074 International: hello@mediliftbeauty.com Designed by YA-MAN in Tokyo, Japan Controllers Made in Japan Silicon Mask, Extender Belt, Magnetic USB Cable and AC Adapter Made in China EPM18G-1-004E © 2025 YA-MAN All Rights Reserved.
