- Page 1 SMITH MACHINE + RACK PLUS USER MANUAL EL-45LP...
- Page 2 Thank you very much for trusting us! With this purchase you are now part of the Titanium Strength Community. We hope that our products will help you gain the confidence you need to achieve all your goals. We guarantee you quality and safety.
-
Page 3: Before You Begin
ASSEMBLY INSTRUCTIONS BEFORE YOU BEGIN This exercise equipment is built for optimum safety. Be sure to read the entire manual before you assemble or operate your equipment. Please note the following safety precautions. SAFETY PRECAUTIONS Keep children and pets away from the equipment at all times. DO NOT leave children unattended in the same room with the equipment. - Page 4 PARTS IDENTIFICATION CHART Use the drawing below to identify small parts used in assembly. IMPORTANT: If you cannot find a part in the hardware kit, check to see if it has been reassembled. Extra hardware may be included. Follow us on: @titaniumstrengthofficial |...
-
Page 5: Parts List
PARTS LIST DESCRIPTION BASE FRAME 1SET MAIN FRAME 1SET MIDDLE CONNECTION TUBE REAR CONNECTION TUBE RIGHT FRAME LEFT FRAME BRACKET OLYMPIC PLATE BAR RETAINING RING SOCKET COUNTERSUNK HEAD SCREW M8*10 SOCKET COUNTERSUNK HEAD BOLT M8*25 SOCKET CAP BOLT M10*70 BOLT M10*25 BOLT M12*25 BOLT M12*35 BOLT M12*75... -
Page 6: Assembly Information
ASSEMBLY INFORMATION NOTE: It is strongly recommended that this equipment is assembled by two or more people to avoid possible injury. Tools Required for Assembling the Smith Machine + Rack Plus: Spanner 4mm Allen Key 5mm Allen Key and 6mm Allen Key. Ensure Carriage Bolts are inserted through the square holes on components that need to be assembled. - Page 7 PARTS IDENTIFICATION CHART STEP 1 Qty:8 M10*25 Qty:14 M12*25 Qty:10 Qty:2 Qty:2 M12*145 Qty:8 Follow us on: @titaniumstrengthofficial |...
- Page 8 PARTS IDENTIFICATION CHART STEP 2 Qty:2 M10*25 Qty:2 Qty:2 Qty:4 Qty:2 M10*25 Qty:2 M8*45 Qty:4 Follow us on: @titaniumstrengthofficial |...
- Page 9 PARTS IDENTIFICATION CHART STEP 3 M8*10 Qty:4 Qty:13 Qty:1 M10*70 Qty:1 M12*35 Qty:5 Qty:4 M12*75 Qty:4 Qty:1 Follow us on: @titaniumstrengthofficial |...
- Page 10 PARTS IDENTIFICATION CHART STEP 4 Follow us on: @titaniumstrengthofficial |...
-
Page 11: Warranty
WARRANTY We warranty this product to be free from defects in workmanship and materials under normal use and conditions for a period of 1 year FOR PROFESSIONAL USE and 3 years FOR DOMESTIC USE, from the date of original purchase, provided that the product remains in the possession of the original owner. - Page 12 SEE YOU SOON! WE HOPE YOU ACHIVE ALL YOUR GOALS. Share your experience and tag @titaniumstrengthofficial FOLLOW US Follow us on: @titaniumstrengthofficial |...
