ITW VORTEC 611 Operation & Safety Instructions

Adjustable frost free cold air guns
Hide thumbs
1
2
3
4
5

Advertisement

Table of Contents

OPERATION & SAFETY
INSTRUCTIONS
ADJUSTABLE FROST FREE
COLD AIR GUNS
Models 611, 611-1, 621, 621-1, 631, 631-1
(Includes all BSP versions of models listed above)
I M P O R T A N T
Please read all instructions BEFORE attempting to use this product
10125 Carver Road, Cincinnati, OH 45242
Phone: 513-891-7474 • Fax: 513-891-4092
Toll Free: 800-441-7475
www.vortec.com • techsupport@vortec.com
