Edison EC9103T-GS/WDG Instruction Manual

Hide thumbs

Advertisement

Table of Contents

GARMENT STEAMER
INSTRUCTION MANUAL
MODEL: EC9103T-GS/WDG
EC9103T-GS/WWG

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the EC9103T-GS/WDG and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Edison EC9103T-GS/WDG

  • Page 1 GARMENT STEAMER INSTRUCTION MANUAL MODEL: EC9103T-GS/WDG EC9103T-GS/WWG...

  • Page 3: Important Safeguards Warnings

    IMPORTANT SAFEGUARDS WARNINGS For safe use, please follow the following safety precautions to avoid danger. 1. This appliance is not intended for use by persons (including children) with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, unless they have been given supervision or instruction concerning use of the appliance by a person responsible for their safety.
  • Page 4 burnt. 4. The clothes can not be ironed at the same place for a long time to avoid causing damage to clothes. 5. This appliance is equipped with an independent water tank. The water must be filled through the water tank and there is no water-filling port on the main body for filling water manually. KNOW YOUR GARMENT STEAMER Support pole Coat rack...

  • Page 5: Installation Instruction

    Temperature indicator Steram outlet Power button Power knob Ironing soleplate Steram button DESCRIPTION FOR TEMPERATURE INDICATOR Status of Garment Steamer Status of Indicator Power on No indication, one beep can be heard. Preheating The indicator flashes. Finish preheating The indicator illuminates solidly. Power off The indicator turns off.
  • Page 6 Support base Fig.1 Fig.2 INSTALLATION OF COAT HANGER 1. Fix the ironing head support onto the third telescopic pole (see Fig.3). 2. Install the fourth telescopic pole onto the third telescopic pole (see Fig.4). 3. Install the coat hanger onto the fourth telescopic pole (see Fig.5). 4.
  • Page 7 Fig.3 Fig.4 Fig.5 - 5 -...
  • Page 8 Fig.6 Fig.7 INSTALLATION AND REMOVAL OF IRONING HEAD 1. INSTALLATION Put the ironing head into the ironing head support slowly (see Fig.8). - 6 -...
  • Page 9 Fig.8 2. REMOVAL Push the ironing head upwards from the bottom and then remove it upwards (see Fig.9). - 7 -...
  • Page 10 Fig.9 CAUTION: Please do not touch the ironing soleplate when installing or removing the ironing head to prevent from being burnt. ADJUSTMENT FOR THE HEIGHT OF TELESCOPIC POLE The height of telescopic pole can be adjusted by increasing or decreasing the number of telescopic pole according to the demand of users (see Fig.10).
  • Page 11 Fig.10 - 9 -...
  • Page 12 INSTALLATION OF WOOLEN GARMENT CLEANING BRUSH Grasp the handle of ironing head and install one slot at the inner side of cleaning brush onto the fastener under the ironing head (see Fig.11), and then press it to tighten until a sound of click is head, then the cleaning brush is installed well in position.

  • Page 13: Filling Water

    3. Please do not touch the ironing soleplate and steam hose to avoid any burn during using and when it is just out of use. 4. The ironing head must be placed on the ironing head support, and do not place it on the table or ironing board etc.
  • Page 14 IRONING OPERATION 1. Power on/Power off: After the appliance is powered on, one beep can be heard. Turn the Temperature knob clockwise to its end and then press the Power button, and the appliance starts to preheat. Turn the Temperature knob anticlockwise to its end and the appliance stops heating. The indicator keeps flashing, press the Power button to make the appliance turn off and the indicator be turned off.
  • Page 15 Fig.13 - 13 -...

  • Page 16: Cleaning And Maintenance

    CLEANING AND MAINTENANCE CAUTION: The appliance must be turned off and unplugged as well as cooled down completely before performing cleaning and maintenance. 1. Before using, please ensure that there is enough water in the water tank to prevent the appliance from being operated without water.
  • Page 17 Fig.14 - 15 -...

  • Page 18: Troubleshooting

    TROUBLESHOOTING The followings are for reference only. Please contact after-sales customer service if there are still problems after simple handling. CAUTION: Do not disassemble and repair the appliance by yourself to avoid causing danger or damage to the appliance. Problem Cause Solution The power plug is not...

  • Page 19: Environment Friendly Disposal

    intermittent or little, or wound. there is no steam released. There are foreign objects at the Remove the foreign objects at the water inlet. water inlet. The water tank is not installed Install the water tank well in well in position. position.
  • Page 20 Al Saif Stores for Development & Investment ALSAIF GALLERY P.O.BOX.10447, RIYADH 11626 Imam Saud road cross of Othman ben Affan street, next to al Rajhi bank TEL.: +966115620779 - FAX.: +966114530392...
  • Page 21 瑳Ϯ瑡 瑡e ‫ﺺ‬Ϯ敬 瑡e 댳 Ϯ ϳ Ϯ ϳ Ϯ 䳌 䳌 Ϯ Ϯ τ᐀ Ϯ Ȁ 晦 Ϯ 晦 ϳ Ϯ Ϧ Ϯ Ϯ ‫واالستثمار‬ ‫ر‬ ‫للتنمية‬ ‫ر ر‬ ‫السيف‬ ‫ر ر ر‬ ‫متاج‬ ‫ر‬ ‫كة‬ ‫ش ر‬ ‫ي ر‬ ‫ي...
  • Page 22 Ϯ Ϧ Ϯ Ϯ Ϯ Ϯ Ω Ϯ Ω ᛈ Ϯ Ϧ ϳ 䁢Ϯ Ϯ ㌳ Ϯ ϳ Ω ᐀ Ω ϳ Ϯ Ϯ ᐀ Ω Ϯ τ Ϯ Ϯ Ϯ ϳ Ω τ Ϯ ΩϮ Ϯ Ϯ 䳌 Ωϳ ΩϮ...
  • Page 23 祴 彣e ᐀ 䳌 ᛈ Ϯ 䳌 Ϯ ᐀ ᐀Ϯ ϳ ⺅ ᐀ Ϯ 䁢Ϯ Ϯ Ϯ τ Ϯ Ϯ ᐀ Ϯ ㌳ 晦 Ϯ τ Ϯ ϼ ϼ 瑳쥀̀ ‫ﺤ‬瑡e 瑳 瑡e Ϯ毸 瑡e τϮ ᛈ τϮ ϼΩ ϳ Ϯ ᐀...
  • Page 24 ⺅...
  • Page 25 祴 瑡e 祴 쥀瑡e Ϯ Ϯ Ϯ ϳ ϳ 䳌 τϮ Ϧ Ϯ ㌳ 晦 Ϯ ϳ 瑳쥀̀ ㌳ 晦 Ϯ 䁢ᛈ Ϯ Ϯ 䳌 Ω Ϧ ㌳ 晦 Ϯ 䳌䁢 1 ϼΩϳ Ϯ Ϯ Ϯ Ϯ ϳ ϳ 2 ㌳...
  • Page 26 ⺅...
  • Page 27 ᜐ Ϯ Πήe Ῑ ᜐe ΩϮ 瑡 . ᘇ ϳ 瑡e Ϯ 敬 瑡e Ῑ 祴 ήe ϳ 祴敬瑳瑡e . Steam ᜐ ‫ ̀ﺤ‬ϳ 祴敬瑳瑡e ᘇ Π . e Π祴ϳ 祴敬瑳瑡e ‫ ﺤ‬瑡 Ϯ . 祴 ‸ 瑡 Ϯ ̀ 瑡...
  • Page 28 祴 瑡e 瑳 ̀ ᛈϮ Ϯ Ϯ Ϧ Ϯ Ȁ Ϯ Ϯ Ϧ Ϯ Ϯ ㌳ Ϯ Water-filling hole Water inlet 12 ⺅ 毸瑡e Ϯ Ϯ 댳 ᐀ 祴 瑡e 祴 祴ᜐ̀e e ‫ﺤ‬瑡e 祴 Ῑ 祴  祴 Π 毸 ㌳...
  • Page 29  ᘇ 瑡e ϳ 瑡e  쥀̀ 祴  ̀ Ϯ Ω Ω Ϯ Ϯ Ϯ ⺅ Ϯ Ϯ Ϯ Ϯ ᛈ Ϯ ⺅ ⺅ τ Ωϼ ϳ ϳ ᛈ Ϯ 晦 䁢 ⺅ 11 ᛈϮ Ω Ϯ 11 ⺅ ϳ...
  • Page 30 10 ⺅...
  • Page 31 ϼ 쥀ᜐ 瑡 瑡eᜐ 毸瑡e  ̀ 쥀 毸瑡e 祴 瑡 Ω Ϯ τ Ϯ Ῑ 敬 瑡e Ϯ 瑡 祴 Ϯ ̀ 祴 ᜐ ϳᘇ毸 Ϯ 瑡e 瑡e 祴 ̀ e 瑳ᜐ 毸 Ω Ϯ τ . ‸ 毸 瑡e...
  • Page 32 >8 ᛈϮ Ϯ Ϯ 8 ⺅ 瑡e ᛈϮ 晦 ⺅ Ϧ Ϯ ᛈϮ...
  • Page 33 ⺅ ⺅ 毸瑡e  ̀ 䳌 Ϯ...
  • Page 34 ⺅ ⺅ ⺅...
  • Page 35 Ϯ Support base 1 ⺅ 2 ⺅ 祴 瑡e 祴  ̀ ᛈϮ Ϯ Ϯ Ω Ϯ τ Ϯ Ϯ ⺅ ᛈϮ Ϯ Ϯ Ω Ϯ τ Ϯ Ϯ Ω Ϯ τ Ϯ ᛈϮ Ϯ Ω Ϯ Ω ᐀Ϯ τ᐀ Ϯ ⺅...
  • Page 36 Ϯ Ϯ ⺅ Ϯ Temperature indicator Steram outlet τϮ ㌳ Power button Power knob Ironing soleplate Steram button Ϯ ㌳ e ‫ﺤ‬瑡e 瑡  ⺅ Ϯ Ϯ ϳ Ϯ Ϯ Ω Ϯ Ϯ ϼ Ωϼ Ϧ ϳ ⺅ Ωϳ 䁢ᛈ τϮ...
  • Page 37 祴敬瑡e 祴敬瑳瑡e ϳ 瑡e eᘇ毸Ῑ Ϯ ̀ Ω Support pole Coat rack ᐀ Ϯ Coat hanger τ᐀ Ϯ Telescopic pole Ω Ϯ τ Ϯ Brush Ironing head support Ironing head Steam hose Small bracket ⺅ Ϯ Water tank Ϯ Main body Power cord ϳ...
  • Page 38 Ῑ 祴 e Ā‫̀ﺤ‬ τ Ϯ Ϯ Ϯ Ϯ Ϯ ϳ Ϧ ϣ Ϯ ᐀Ϯ Ϯ ϳ Ϯ Ϯ ᐀ Ϧ Ω ᐀ϳ Ϧϳ Ϯ Ϯ ⺅ Ϯ Ϯ ⺅ ϳ ⺅ 晦 Ϧ Ϯ ᛈϮ Ϧ ϳ Ϯ ㌳ 晦 Ϯ ᐀...
  • Page 40 祴敬瑳瑡e eᘇ毸Ῑ e 祴 e 瑡 EC9103T-GS/WWG EC9103T-GS/WDG ϳ Ω Ϯ Ϯ Ϯ Ω Ϯ Ϯ ϳ Ϯ Ϯ...
