Summary of Contents for CONVECTAIR LEGATO
- Page 1 LEGATO Split-Type Room Air Conditioner REMOTE CONTROL GUIDE To be read and kept by the user. 7217030200R00...
-
Page 2: Table Of Contents
Contents Quick Start Guide Handling the Remote Controller Buttons and Functions Basic Functions Basic Functions How to Use Advanced Functions... -
Page 3: Quick Start Guide
Quick Start Guide AUTO COOL HEAT SELECT TEMPERATURE FIT BATTERIES SELECT MODE PRESS POWER BUTTON POINT REMOTE SELECT FAN SPEED TOWARD UNIT NOT SURE WHAT A FUNCTION DOES? Refer to the How to Use Basic Functions and How to Use Advanced Functions sections of this manual for a detailed description of how to use your remote with your ductless split room air conditioner SPECIAL NOTE... -
Page 4: Handling The Remote Controller
Handling the Remote Controller NOTES FOR USING REMOTE CONTROL Inserting and Replacing Batteries The device could comply with the local national Your air conditioning unit may come with two regulations batteries Put the batteries in the remote control • In Canada, it should comply with CAN ICES-3(B)/ before use NMB-3(B) 1 Slide the back cover from the remote control... -
Page 5: Buttons And Functions
Buttons and Functions Before you begin using your split room air conditioner, make sure to familiarize yourself with its remote control The buttons on your remote may differ slightly from the example shown MODE ON/OFF Turns the unit on or off Scrolls through operation modes as follows: AUTO ›... -
Page 6: Basic Functions
Basic Functions Information are displayed when the remote controller is powered up The display on your unit may differ slightly from the example shown Breeze Away display Active clean feature display Fresh/UV-C lamp feature display Sleep mode display Follow me feature display Wireless control feature display Transmission Indicator Low battery detection display (Flashes) -
Page 7: Basic Functions
Basic Functions Before operation, please ensure the unit has power ATTENTION FAN Mode Set your desired temperature Select AUTO mode Turn on the air conditioner MODE NOTE: 1 In AUTO mode, the unit will automatically select the COOL, FAN, or HEAT function based on the set temperature 2 In AUTO mode, fan speed cannot be set Cool or Heat Mode... - Page 8 Setting the timer TIMER ON/OFF - Set the amount of time after which the unit will automatically turn on/off TIMER ON setting Press TIMER button Press up or down button for Point remote to unit and wait to initiate the ON time multiple times to set the desired 1 second, the TIMER ON will sequence...
-
Page 9: How To Use Advanced Functions
How to Use Advanced Functions Swing function Press Swing button Swing Swing The horizontal louver will swing up and down Keep pressing this button more than 2 automatically when pressing Swing button seconds, the vertical louver swing function is Press again to make it stop activated (For the units with vertical louver swing feature) Airflow direction... - Page 10 ECO/GEAR function Press this button to enter the energy efficient mode in a sequence of following: ECO > GEAR (75%) > GEAR (50%) > Previous setting mode ECO Note: This function is only available under COOL mode ECO Operation: Under cooling mode, press this button, the remote controller will adjust the temperature automatically to 24°C/75°F, fan speed of Auto to save energy (only when the set temperature is less than 24°C/75°F) If the set temperature is above 24°C/75°F, press the ECO button, the fan speed will change to Auto, the set temperature will remain unchanged...
- Page 11 FP function Press this button 2 times during one second under HEAT Mode and setting temperature of 16°C/60°F The unit will operate at high fan speed (while compressor on) with temperature automatically set to 8°C/46°F Note: This function is for heater setting only Press this button 2 times under HEAT Mode and setting temperature of 16 C/60 F to activate the FP function Press On/O ff, Mode, Fan and Temp button or start sleep feature while operating will cancel this function...
- Page 12 Turbo Function Press Turbo button When you select Turbo feature in COOL mode, the unit will blow cool air with strongest fan setting to jump-start the cooling process Turbo When you select Turbo feature in HEAT mode, the unit will blow heat air with strongest fan setting to jump-start the heating process For units with electric heat elements, the electric heater will activate and jump-start the heating process...
- Page 13 SET Function • Press the SET button to enter the function setting, then press SET button or up or down button to select the desired function The selected symbol will flash on the display area, press the OK button to confirm •...
