Summary of Contents for CHARGETRONIX ECA-NC3202S-XYZC
- Page 1 48A Flux AC Charger U s er Man u al © Copyright 2024 ChargeTronix. All rights reserved...
- Page 2 RELATED TO RISK OF FIRE OR ELECTRIC SHOCK WARNING: When working with electrical products, basic precautions should always be followed. This manual contains important instructions for ECA-NC3202S-XYZC, ECA-NC4002S-XYZC and ECA-NC4802S-XYZC models, needs to be observed during installing, operating and maintaining.
-
Page 3: Table Of Contents
48A Flux AC Charger - User Manual Contents Abbreviations......................................4 Safety Instructions.....................................4 Compliance with Standard................................5 Safety Standard....................................5 Charging Modes and Connections............................5 1. Product Information..................................6 1.1. Type........................................6 1.1.1. Shape and Size.....................................6 1.1.2. Block Diagram....................................7 1.1.3. Model Definition..................................8 1.2. Empty Seat.......................................9 1.3. Specifications....................................10 2. -
Page 4: Abbreviations
48A Flux AC Charger - User Manual ABBREVIATIONS Abbreviations Description EV/PHEV Electric vehicles, either BEV (battery electric vehicles) or PHEV (plug-in hybrid electric vehicles) EVSE Electric Vehicle Supply Equipment Kilowatt Ampere (unit of current) Volts (unit of voltage) Hertz (unit of frequency) RFID Radio Frequency Identification SAFETY INSTRUCTIONS... -
Page 5: Compliance With Standard
48A Flux AC Charger - User Manual STANDARD Safety Standard UL 2594 UL 2231 UL 1998 UL991 Radio Frequency Standards 47CFR Part 15 (2020) ANSI C63.4 (2014) ICES-003 Issue 7: October 2020 Energy Star Standard ENERGY STAR® Program Requirements for Electric Vehicle Supply Equipment (EVSE) Version 1.0 and 1.1 Charging Connection The charging connection method is shown in the figure below... -
Page 6: Product Information
48A Flux AC Charger - User Manual 1 PRODUCT INFORMATION 1.1 Type Welcome to our AC EVSE 1.1.1 Shape and Size The shape and size of the AC EVSE is shown in the figure below: 173.5 mm (6.831") 285.5 mm (11.24") 157.5 mm (6.201") -
Page 7: Block Diagram
48A Flux AC Charger - User Manual 1.1.2 Block Diagram The block diagram of EVSE is as follows CT1 for on - board Meter Relay DIN rail Meters Fuse Power Switch Filter on - board Meter Control pilot R eserve _ AI AD / DC CT2 for CCID -12V... -
Page 8: Model Definition
1.1.3. Model definition 240 1 # of Connectors Max Voltage Max Current Commercial Company Description of Model Number 1. Represents the company, Chargetronix 2. Represents charger type Residential Fleet Power Output Type Commercial Code 3. Represents product power output specifications. -
Page 9: Empty Seat
48A Flux AC Charger - User Manual 1.2 Empty Seat • AC EVSE is equipped with an American standard car-side charging connector. • When the EVSE is in standby mode, insert the car end charging connector into an empty seat to protect the car end charging connector. -
Page 10: Specifications
48A Flux AC Charger - User Manual 1.3 Specification RD10 American Standard AC EV Charging Specifications Specifications & Parameters Category Option Charge Rated Input/ Rated Rated Model Number Part Number Max Power Coupler Output (v) Input (A) Output (A) Level 2, SAEJ1772 CTX-C32- 208/240VAC... - Page 11 48A Flux AC Charger - User Manual Flash rom (32M bit) Memory TF card memory expansion (No TF card) Coin Cell Battery Optional RealTime clock Supercapacitor CCID20 Over Voltage Protection Under Voltage Protection Over-current protection Over Load Protection Protection Function Short Circuit Protection Ground Protection Over-temp Protection...
-
Page 12: Operation
48A Flux AC Charger - User Manual 2 OPERATE 2.1 Switch 1. Check and make sure the mainboard power switch is off and that the fuse is there and installed. As shown below. 2.2 About the interface 2. Turn off the power of this product, turn on the power switch of the mainboard; observe whether the boot interface of the product is normal. - Page 13 48A Flux AC Charger - User Manual Name Functions Specification Fuse Safety Protection 5*20， 250VAC， 10A Debug serial port Not open Download interface Not open 485 interface Undeveloped CAN interface Undeveloped USB interface Undeveloped Coin cell battery Clock power supply storage CR1220 See picture 1 for setting method, See picture 1 for setting method,...
-
Page 14: Features
48A Flux AC Charger - User Manual 3 FEATURES 3.1 User Interface & Control 3.1.1 User Interface & Control Take the ready state screen as an example to illustrate the meanings of common elements in the user interface interaction interface. 1. - Page 15 48A Flux AC Charger - User Manual 5. The main interface displays different content under each status. 6. Charging pile SN code -the unique code assigned at the time of delivery. The client can modify it through the server, but the uniqueness of the modification cannot be guaranteed. 7.
- Page 16 48A Flux AC Charger - User Manual Status Display Description LED Description Current Status Interactive Functions 1. After the charging is completed normally, enter the Purple is Complete charging completion settlement page; always on 2. Unplug the plug and return to the standby screen. 1.
-
Page 17: Configure Wifi Network (Currently No App)
48A Flux AC Charger - User Manual Status Display Description LED Description Current Status Interactive Functions 1. Perform remote OTA in standby state, in this state, there will be a percentage figure to show upgrading process. Download the firmware until complete, then it will confirm and check the content of the upgrade package;... - Page 18 Keep your laptop in a state where it can connect to a Wi-Fi hotspot. Turn on the charger, find the hotspotnamed "CHARGETRONIX", and connect to it without a password. (If you do not find a hotspot named "CHARGETRONIX", please restart the power of the charging station).
- Page 19 48A Flux AC Charger - User Manual EVSE CONFIGURATION Advanced Options User Options 3885233376195 Serial Number: WiFi SSID: OCPP Version: OCPP1.6-J WiFi Password: 12345678 OCPP Server: Plug and Play: wss://centralsystem.ampup.io/ocpp/longt Disable OCPP AuthPass: Share Current: Connect Altemative Server: Modbus Address: New password: Enter a new password of 1 to 9 characters Advanced Options...
-
Page 20: Operation Guide
48A Flux AC Charger - User Manual 3.2 Operation Guide 1. Charging Preparation: A. Find the charging pile product in B. If choose to use APP: You can C. If choose to use an RFID card: the idle standby state, park the car, download the APP according to the Contact the operator to obtain an turn off the vehicle, and make the... - Page 21 48A Flux AC Charger - User Manual 5. End Charging: A. Through charging, the car owner B. After the car is fully charged, it C. After the charging is completed, can take initiative to end the charging can automatically end the charging. please pull out the charging coupler through tap RFID card or stop on APP and put it back to the empty...
-
Page 22: Troubleshooting
48A Flux AC Charger - User Manual 3.4 Troubleshooting When a fault occurs, the charger will automatically protect. The fault information and processing methods are as follows. Handling Method Fault Code Code 11: Check that the adapter is properly connected to the electric CP failure vehicle, pull and plug the adapter and try charging again. -
Page 23: Installation
48A Flux AC Charger - User Manual 4 INSTALL 4.1 Label On the EVSE shell, there is a nameplate identifying the charger model and specifications, the con- tent of which is as follows. 4.2 Package 4.2.1 Packing List Torx self-tapping AC charger RFID card Coupler holder... -
Page 24: Check And Confirm
48A Flux AC Charger - User Manual 4.2.2 Check and Confirm When unpacking, please confirm the following points carefully: • According to the packing list, whether the accessories are complete. • Whether there is any damage during transportation. • Whether the model and specification on the nameplate of the machine are consistent with the order requirements. -
Page 25: Installation Steps
48A Flux AC Charger - User Manual 4.4 Installation Steps 4.4.1 Mount the EVSE on the Wall as Follows Location Requirements Children are not allowed to touch 11.81" 7.87" 7.87" 11.81" 19.69" Aaltitude 2000mm(78. 74" From the ground 1150mm(45.28 ) "... - Page 26 48A Flux AC Charger - User Manual Wall-mounted Installation Steps Install Wall Mounts, Install the wall-mounted Punch holes in the wall. Hanging Plates and version and trace holes Empty Blocks. on the wall. Schematic diagram of Install piles on the wall. Set screw.
-
Page 27: Pedestal Mount
48A Flux AC Charger - User Manual Tighten the screws of the Lock wire cover. Reinstall the trim case. decorative cover. 4.4.2 Column installation Schematic Diagram of Column Decomposition Column cap Silica gel Column Boom AL6063-T6+Oxidation 1 Hook up SGCC+baking paint M5*12 combination Stainless steel screw... - Page 28 48A Flux AC Charger - User Manual Schematic diagram of column installation Pull wire. Fixed column. Cement foundation size chart. 1 70 1 70 230. 64 230. 64 303. 4 303. 4 Install empty seat. Install the hanging board. Fixed base cover. The input surface mounting Install wall panel.
- Page 29 48A Flux AC Charger - User Manual Input line terminal crimp- Concealed hole installa- The input line passes Lock the seal. ing tube type terminal. tion three-hole water- through the three-hole proof connector. waterproof connector. Product wiring Remove the decorative Remove the wiring Wiring.
-
Page 30: Grounding Instructions
48A Flux AC Charger - User Manual After installation 4.5 Grounding Instructions This product must be connected to a grounded, metallic, permanent wiring system, or an equipment ground wire must be run with the circuit conductor and connected to the equipment ground terminal or conductor on the product. -
Page 31: Warranty Agreement
48A Flux AC Charger - User Manual WARRANTY 1. The scope of the warranty refers to the product itself. 2. The warranty period is 24 months. During the warranty period, if the product fails or is damaged under normal use (determined by the company's technicians ), the company will repair it free of charge. 3. - Page 32 48A Flux AC Charger - User Manual For Both FCC & IC application: This device complies with Part 15 of the FCC Rules / Industry Canada licence-exempt RSS standard(s). Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
