XTM 693632 Instruction Manual

+ TYRE INFLATE/DEFLATE
DIGITAL GAUGE
Instruction Manual
.
TYRE INFLATE/DEFLATE DIGITAL GAUGE
PSI
BAR
KPA
KG/CM 2
UNIT
+ WARNING
• Read and follow instructions before use.
• Do not use this product for activities outside its intended use. Do not use
this product if found as defective.
• Keep this product out of children's reach. Do not expose this product to rain
or water.
• Keep this product away from fire, corrosive liquids and magnetic substances.
• Do not exceed the maximum pressure of the device.
• Remove the battery if not in use for extended periods of time.
+ DIAGRAM
LIGHT
Valve Trigger
Air Bleed Valve/Reset Button
Male Connector
Interchangeable Brass Chucks
Rubber Hose
PLU: 693632
.
TYRE INFLATE/DEFLATE DIGITAL GAUGE
PSI
BAR
KPA
KG/CM 2
UNIT LIGHT
Power/Unit Button
Backlight Button
Digital Gauge Display
Battery Compartment
+ SPECIFICATIONS
Pressure Range 0-200 PSI
Hose Length 32CM
Pressure Unit PSI, BAR, KPA, KG /CM²
0-100psi Accuracy ±1PSI
Over 100psi Accuracy ±2PSI
+ OPERATION INSTRUCTIONS
Connect the tyre inflate/deflate digital gauge to an air
compressor with the quick-connect air fitting.
Turn the inflator gauge on by pressing the power/unit button.
Press it again to select the unit you would like to measure in.
Press the air bleed valve to ensure the gauge is set to zero.
Use the chuck to connect to the tyre valve by pressing the
tyre's valve stem into the mouth of the chuck.
For the locking chuck, press the trigger while placing it
onto the valve stem and release it once there is a strong seal. It should
lock in place.
Fill by pressing the valve trigger until your desired pressure
is reached.
Note: While inflating the tyre, the pressure reading will not
indicate the exact pressure of the tyre. To check on the tyre's current
pressure, release the valve trigger and the display will instantaneously
show your tyre's pressure.
.
TYRE INFLATE/DEFLATE DIGITAL GAUGE
BAR PSI
KG/CM KPA 2
UNIT LIGHT
