Bazooka BPB-KP7W-G3 Quick Start Manual

Volume Decrease
Song Reverse
Note:
The Master Power button on the BPB16-G3, BPB16-G3-BAT, and
BPB16-G3-BAT-WH is a MECHANICAL switch that kills all power
to insure there is no parasitic current draw (battery drain) while your
vehicle is in storage. The PWR button on the new dashboard remote
does NOT and cannot operate that Master Power button. The PWR
button on the dashboard remote will turn the internal Bluetooth module
ON/OFF as well as Pause/Play the music provided the Master Power
button on the unit is already ON.
Volume Decrease
Song Reverse
Note:
The Master Power button on the BPB16-G3, BPB16-G3-BAT, and
BPB16-G3-BAT-WH is a MECHANICAL switch that kills all power
to insure there is no parasitic current draw (battery drain) while your
vehicle is in storage. The PWR button on the new dashboard remote
does NOT and cannot operate that Master Power button. The PWR
button on the dashboard remote will turn the internal Bluetooth module
ON/OFF as well as Pause/Play the music provided the Master Power
button on the unit is already ON.
BPB-KP7W-G3
Power On/Off, Play/Pause: Press and hold turns bar on/off.
Click-press when music is playing causes music to pause.
Press again to play
LED: Press and hold turns led on/off. Click-press cycles the
sequence. Double-click turns beat to the music option on.
Party Button: Will illuminate for 10 seconds when any button is
pressed. Click-press cycles through the party modes. Party Button
On/Off, Play/Pause
on sound bar will change colors along with a voice prompt for that
mode. Party Button on remote will not change color.
Volume Increase
Modes below:
Party Button
Party Button on bar
Blue
Song Forward
Purple
Red
LED Button
BPB24-G3, BPB24-DS-G3, BPB36-G3
Pairing Instructions:
Unplug the power wire from the Party Bar hold both the volume
decrease and volume increase buttons down on remote until the
Party Button is blinking. Plug the Party Bar's power wire back in.
The remote will quickly blink 6 times, and then will be solid, indicat-
ing pairing was successful.
BPB16-G3, BPB16-G3-BAT, BPB16-G3-BAT-WH
Pairing Instructions:
Turn the master power button off on the bar. Hold both the volume
decrease and volume increase buttons down on remote until the
Party Button is blinking. Turn the master power button on. The
remote will quickly blink 6 times, and then will be solid, indicating
pairing was successful.
BPB-KP7W-G3
Power On/Off, Play/Pause: Press and hold turns bar on/off.
Click-press when music is playing causes music to pause.
Press again to play
LED: Press and hold turns led on/off. Click-press cycles the
sequence. Double-click turns beat to the music option on.
Party Button: Will illuminate for 10 seconds when any button is
pressed. Click-press cycles through the party modes. Party Button
On/Off, Play/Pause
on sound bar will change colors along with a voice prompt for that
mode. Party Button on remote will not change color.
Volume Increase
Modes below:
Party Button
Party Button on bar
Blue
Song Forward
Purple
Red
LED Button
BPB24-G3, BPB24-DS-G3, BPB36-G3
Pairing Instructions:
Unplug the power wire from the Party Bar hold both the volume
decrease and volume increase buttons down on remote until the
Party Button is blinking. Plug the Party Bar's power wire back in.
The remote will quickly blink 6 times, and then will be solid, indicat-
ing pairing was successful.
BPB16-G3, BPB16-G3-BAT, BPB16-G3-BAT-WH
Pairing Instructions:
Turn the master power button off on the bar. Hold both the volume
decrease and volume increase buttons down on remote until the
Party Button is blinking. Turn the master power button on. The
remote will quickly blink 6 times, and then will be solid, indicating
pairing was successful.
Voice Prompt
Single Listener Mode
DJ Broadcast Mode
DJ listening Mode
Voice Prompt
Single Listener Mode
DJ Broadcast Mode
DJ listening Mode
