Thank you for purchasing a
6x9 Sunflower Playhouse.
Please take the time to
identify all the parts prior
to assembly.
Safety Points and Other Considerations
Our products are built for use based on
proper
installation
residential use, on level ground. Please
follow the instruction manual when
building your shed and retain the manual
for future maintenance purposes.
Some of the safety and usage measures you may wish to consider include:
-Snow load ratings vary by geographical location. If heavy or wet snowfall occurs, it is advisable to sweep
the snow off the roof(s).
-If the product is elevated, any structural and building code requirements are solely the customer's
responsibility, and should be abided by.
-In high or gusty wind conditions it is advisable to keep the structure securely grounded.
-Have a regular maintenance plan to ensure screws, doors, windows and parts are tight.
Customers agree to hold Outdoor Living Today and any Authorized Dealers free of any
liability for improper installation, maintenance and repair of any products sold by Outdoor
Living Today.
In the event of a missing or broken piece, simply call the Outdoor Living Today Customer
Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our
commitment to you to courier replacement parts, free of charge, within 10 business days of
this notification. Replacement parts will not be provided free of charge after the 30 day grace
period.
Toll Free 1-888-658-1658
6x9 Sunflower Playhouse - T&G
and
normal
www.outdoorlivingtoday.com
Outdoor Living Today
Assembly Manual
sales@outdoorlivingtoday.com
Page 1
Revision #1.3
September 17, 2022
Advertisement
Related Manuals for Outdoor living today Sunflower Playhouse
Summary of Contents for Outdoor living today Sunflower Playhouse
- Page 1 Outdoor Living Today. In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier replacement parts, free of charge, within 10 business days of this notification.
-
Page 2: Parts Lists
Thank you for purchasing a 6x9 Sunflower Playhouse. Please take the time to identify all the parts prior to assembly. Parts Lists: D. Porch Section 2 - 3 1/2” x 3 1/2” x 58 7/8” Porch Posts (long) 1 - 3 1/2” x 3 1/2” Deck Post (short) A. - Page 3 6X9 SUNFLOWER HARDWARE PACKAGE Hardware Kit (Provided) 410 pcs 1 1/2” Finishing 2 1/2” 198 pcs 50 pcs 1 1/2” Shingle 2” 170 pcs 1 pc Square Drive Bit 212 pcs 1 1/4” 3/4” 30 pcs Single Rafter 3/4” Double Rafter 38 pcs Bracket x 4 Bracket x 2...
-
Page 4: Floor Section
A. Floor Section 17 1/2” Floor Joist Frames require one interior Floor Joist attachment each. Center Floor Joist (17 1/2” from outside of Frame to center of Floor Joist) and attach with 2 - 2 1/2” screws per end. You can find the Square Drive Bit for the screws in with the Hardware Kit Bag. Pieces: Hardware: - 3x Floor Joint Frames... - Page 5 Flush with Floor Framing Attach Floor Runners to completed Floor Joist Frames. There are two Floor Runners per 105” side and three completed Floor Runners in total. Use 6 - 2 1/2” screws per Runner to secure. Pieces: Hardware: - 3x Floor Runners - 12x 2 1/2’’...
- Page 6 plywood pushed together at seam. Hint: Use a chalk line to mark location of floor joists to determine screw placement. When Plywood Floor is correctly positioned, attach with 1 1/4” screws. Use screws every 16”. flush Front Make sure deck boards are flush to the front and sides of the floor frame.
- Page 7 Important: Pilot hole ALL 2x3 Wall Studs with 1/8” drill bit prior to screwing. Pilot This will make it much easier to Hole first. attached together. Wall Plate Starting with Solid Wall Panels, carefully lay panel face down. Position and attach Wall Plate to bottom of wall studs of each Panel with 3 - 2 1/2”...
- Page 8 11a. Position Window Trim around window doing a dry run first and attach with 4 - 1 1/2” finishing nails per piece. The window kit trim pack = 1x 24 1/16” = top / 3 x 23” = sides and bottom. Window trim has a small dado on reverse face.
- Page 9 The Side Wall Panels will sit flush at the end of the Plywood Floor with the front and rear panels sandwiched between them. NOTE: Siding will overhang the floor by approx. 1/2”. Position Rear Solid Wall on floor in corner and attach vertical wall studs together with 3 - 2 1/2” screws. Pieces: Hardware: - 1x Solid Wall Panel...
- Page 10 To attach the Door, first position the 10” wide Narrow wall Narrow Wall next to the Window Wall and screw into adjoining wall stud with 3 - 2 1/2” screws. Pieces: Hardware: Pilot - 1x Narrow Wall Panel - 3x 2 1/2’’ Screws Hole first.
- Page 11 Angle screws into perimeter Pilot Floor Joists. Hole first. Wall Plate Optional - Caulking seams will help prevent moisture from entering your shed. Caulking not included in kit. When all walls are attached together, check alignment with the floor. Bottom Wall Plates should sit Advice: Prior to fastening walls and installing rafters, take flush with outside of Floor Framing.
- Page 12 Attach Door Handle and Interior Silver Barrel Bolt Hardware. Use 3/4” Black Headed Screws to secure the Door Handle. Important: Drill shallow Pilot Holes to prevent wood from splitting. Align male and female Barrel Bolt to Door Framing. Attach with 3/4” Black Headed Screws.
- Page 13 . Position the Front Top Plate on top of Door and Front Wall Panel. Front Top Plate is straight cut on the ends and is 70” long. Once again, the Top Plate will be flush with inside of Top Wall Plate. Attach with 4 - 2”...
- Page 14 Complete the 2 Porch Rail Sections, following steps A through D. Note: Sections differ - see step B for orientation. Top Plate Front Extension Corner Bracket Exploded View of Porch Rail Section Front Porch Wall Trim Supports 4x4 Porch Post with Filler Strip attached.
- Page 15 B. Attach 1x4 1/2” Wall Trim/ Supports to Front Extension using 2 - 2” screws. Make sure Front Extension is Flush to back of wall trim and centered 1/2” on each side. Note: there are 2 different wall supports for left & right. See diagram for proper orientation. Door Way Window Side...
- Page 16 When both Porch Rail Sections are complete, lift into place on Playhouse Deck and beneath the Side Top Plate. (Window Side section will have Narrow Filler Trim). Position so Post is flush with Tack in place - refer to Step 57. Decking on the side and recessed 1/2”...
- Page 17 Notch C. Rafter and Roof Section Exploded view of all parts necessary to complete the Roof Section. Identify all parts prior to starting. (Roof Filler Shingles Missing) Outside Roof Outside Roof Middle Roof Panels (2) Panels (2) Panels (2) Roof Rafters (9 per side) 18 Total Soffits (4)
- Page 18 2 1/2” Screws Ridge Board into Doubled up Rafters 2 1/2” Screws Soffits into Doubled up Rafters Important: Pilot Hole Ridge Board to prevent splitting! 105” 15 1/4” 15 1/4” Connector 15 1/4” 35” Plate to inside 35” 35” 52 1/2” Important: Pilot Hole Soffit...
- Page 19 Gable Notch Rafters sit on Rear Rafter Middle Gable flush against Wall framing Gable with a slight overhang in front. Soffit should sit against Wall Panel (slight gap may be present) Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 19...
- Page 20 Rafter overhangs post To aid in securing Ridge Boards, place 4 - 1 1/4” Offsetting Steel screws into any of the remaining Metal Ridge Board Connector Plates Connector holes. Complete both sides. 2 1/2“ screw Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 20...
- Page 21 Shingles overhang plywood on outside panels Roof facing shingles and plywood down flush on middle panel Roof Plywood flush with rafter end. Middle Roof Panel Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 21...
- Page 22 Lift up, position and attach Front Outside Roof Panel on Rafters as per Step 42- 44. Continue and place opposite Rear Outside Roof To confirm, Middle Roof Panel will have Panel on Rafters. roof plywood flush with outside of shingles. Place on Middle Rafters and align panel as per Step 44.
- Page 23 Attach above the exposure line. Exposure Line Roof Filler Shingles are included to Screw first filler shingle down to rafters cover roof seams. Starting at the using 1 - 2 1/2” screw per panel (2 in total). bottom, slide the first Long Filler Shingle Make sure to screw into both rafters.
- Page 24 Attaching the Decorative Front Gable is next. Place the Decorative Front Gable underneath porch roof, tight against roof rafter. Be sure to center gable evenly from side to side and place tight up to roof plywood. Outdoor Living Today Inc. www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 25 With Decorative Gable correctly positioned, fasten to rafters with 4 - 2” screws (2 per side). Drill 1/8” pilot holes first to avoid splitting the decorative shingles. D. Porch Section To complete your porch, attach Front Porch Rail Section to Short Deck Post and position on Deck. Screw completed Front Porch Section to Porch Post with 3 - 2”...
-
Page 26: Miscellaneous Section
Attach Post Base Trims to bottom of Porch Posts. Attach with 1 1/2” finishing nails. Center a Rail Support Block (1 1/2” x 3 1/2” x 3 1/2”) under each Handrail Section and secure from top down with 2 - 2 1/2” screws. Complete each Handrail Section. - Page 27 2 pieces Attach Bottom Skirting around the base of the playhouse. There are two Front Skirting pieces that are 38” long that will overlap the Side Skirting. There are eight remaining Bottom Skirting pieces that are 35” long. Attach with 4 - 1 1/2” finishing nails per piece. Gaps will appear in the rear corners but will be covered by trim later.
- Page 28 Attach Back Wall Wide Corner Trims (4 1/2” wide) tight to Narrow Trim and flush at bottom. Use 6 - 1 1/2” finishing nails to secure. Complete both sides. Attach Horizontal Gable Trim under Rear Gable (2 1/2” wide) Use Back Wall Wide Corner Trims to confirm positioning. Using 8 - 1 1/2”...
- Page 29 Attach Side Facia to Roof Rafter Ends. There are two Side Facia pieces per side. Secure with 8 - 1 1/2” finishing Nails per piece. 9” from end Important - Butt (thick) end of Ridge Cap will be facing towards the outside of shed.
- Page 30 8” 8” Place 3rd Ridge Cap 8” back from 2nd (enough to cover shingle nails). Attach 3rd Ridge Cap down as per Step 66. Continue to position and attach Ridge Caps until half the roof is complete. From opposite side, position and attach Ridge Caps as described above.
- Page 31 2 - 2” screws Front Wall Porch and Door Trim 1/2” overhang Above Door Filler Trim Toll Free 1-888-658-1658 www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 31...
- Page 32 Outdoor Living Today Flower Box Assembly Instructions Exploded Parts Lists: Side Trims (D) View Front Trim (C) End Caps (B) A - Base, Rear & Front Box Frames (3pcs) 3/4” x 5 1/2” x 23” 1 1/4” B - End Cap Frames (2pcs) 3/4”...
- Page 33 Congratulations on completing your 6x9 Sunflower Playhouse! We hope your experience assembling your Sunflower Playhouse has been both positive and rewarding. Note: Our Sheds are shipped as unfinished products. If exposed to the elements, the western red cedar lumber will weather to a silvery-gray color. If you prefer to keep the cedar lumber looking closer to the original color, we suggest that you treat the wood with a good oil base wood stain.
