White Lightning BMC24 Operator's Manual

10-amp 24-volt aviation battery maintenance charger optional accessory for the smartgpu
Hide thumbs

Advertisement

Table of Contents

Operator's Manual
Model BMC24
10-Amp 24-Volt Aviation Battery Maintenance Charger
Optional Accessory for the SmartGPU
™
PLEASE READ AND SAVE THESE INSTRUCTIONS.
This charger is designed only for general
aviation
LEAD-ACID BATTERIES
ONLY.
Never use it for any other purpose, including powering a low voltage electrical system.
The BMC24 incorporates proprietary BatteryMINDer
®
operating logic by VDC Electronics. The BatteryMINDer
trademark is used with permission and registered to VDC Electronics, Inc., 155 W Carver St, Suite 2, Huntington, NY
11743 USA web:
www.batteryminders.com
email:
techsupport@vdcelectronics.com
White Lightning™ is a trademark and brand of Audio Authority
®
Corporation, Lexington, KY 40511.
1
