- Page 1 210 No. Industrial Park Road Hastings, MI 49058 (269) 945-8257 Fax: (269) 945-9599 PAR-3 Preaction - Deluge Control System Instruction Manual Document 15181 10/01/2002 Rev: PN 15181:G0 ECN 02-...
-
Page 2: Fire Alarm System Limitations
While a fire alarm system may lower insurance Fire Alarm System Limitations rates, it is not a substitute for fire insurance! An automatic fire alarm system–typically made up of smoke Heat detectors do not sense particles of combustion and detectors, heat detectors, manual pull stations, audible warn- alarm only when heat on their sensors increases at a prede- termined rate or reaches a predetermined level. -
Page 3: Installation Precautions
Installation Precautions Adherence to the following will aid in problem-free installation with long-term reliability: WARNING - Several different sources of power can be con- Like all solid state electronic devices, this system may nected to the fire alarm control panel. Disconnect all sources operate erratically or can be damaged when subjected to light- of power before servicing. -
Page 4: Nfpa Standards
• Requirements of the Local Authority Having Jurisdiction • ADA - Americans with Disabilities Act Refer to "Appendix B: Compatible Devices" on page 41 for a listing of all compatible initiating, indicating and releasing devices. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 5: Table Of Contents
Control Panel ....................... 9 DIP Switch Functions....................10 Standard Board ......................10 Zone Relay Module - 4XZM (Viking p/n 07912) ..........10 Options ........................11 Transmitter Module - 4XTM (Viking p/n 07909) ..........11 Remote Annunciator - RZA-4X (Viking p/n 07911) .......... 11 LED Interface Module - 4XLM (Viking p/n 07910) .......... - Page 6 Local Energy Municipal Box..................48 Remote Station Receiver - RS82-9 ................49 Potter EFT-C McCulloh Transmitter ..............50 Appendix D: Testing & Maintenance Testing ........................51 Inspection ......................51 Alarm Test......................51 Maintenance....................... 51 Troubleshooting......................51 PAR-3 Instruction Manual PN 15181:G0 10/01/02...
-
Page 7: Product Description
1. Product Description Overview The PAR-3 Preaction - Deluge Control System has been designed as a control center for use in preaction and single- and dual-hazard deluge applications. The panel is a feature-packed control unit suitable to perform detection and control functions associated with the release of water-based fire protection systems. -
Page 8: Circuits
Switch 1 - Tone Silence Switch 2 - Alarm Silence Switch 3 - Alarm Activate Switch 4 - System Reset Suplemental Documentation The table below lists document sources containing additional information regarding the PAR-3: For information on... Refer to... Part Number Digital Alarm... -
Page 9: Control Panel
SYSTEM SILENCE SILENCE ACTIVATE RESET OPT2 PAR3-board.cdr SW1 - DIP Switch Battery Fail LED J4 - J5 - J7 - J8 Optional Module Micro Fail LED Ground Fault LED Connectors Figure 1 Control Panel PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 10: Dip Switch Functions
(face) of the module. This part number ends with the letter “B”. The completed assembly part number of the module is the same part number, but the letter “B” is replaced with the letter “M”. Example (4XZB = 4XZM). Zone Relay Module - 4XZM (Viking p/n 07912) The Zone Relay module provides Form-C contacts for the following: •... -
Page 11: Options
Two optional modules are available for use on the control panel. The control panel provides mounting slots for two module boards. Transmitter Module - 4XTM (Viking p/n 07909) The Transmitter Module provides a supervised output for a Local Energy Municipal Box transmitter and alarm and trouble reverse polarity circuits for Remote Station Service. -
Page 12: Led Interface Module - 4Xlm (Viking P/N 07910)
1. Product Description Options LED Interface Module - 4XLM (Viking p/n 07910) The LED Interface Module supports the RZA-4X Remote Annunciator Module. Annunciator wiring is supervised for open conditions by this module. The module mounts to the main board on the J8 option connector. -
Page 13: Specifications
Specifications 1. Product Description Specifications AC Power PAR-3 & PAR-3C: 110/120 VAC, 50/60 Hz, 1.2 amps PAR-3E: 220/240 VAC, 50/60 Hz, 0.6 amps Wire size: minimum #14 AWG with 600V insulation Battery (lead acid only) Maximum Charging Circuit: 27.6V, 1.5 amps Maximum Battery Capacity: 18 AH. - Page 14 1. Product Description Specifications Notes PAR-3 Instruction Manual PN 15181:G0 10/01/02...
-
Page 15: Installation
Determine the number of conductors required for the devices to be employed. Pull required conductors into the box through the knockouts provided. Note: All wiring should be in accordance with the National and/or Local codes for fire alarm systems, including "Power-limited Wiring Requirements" on page 19. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 16: Reinstallation Of Circuit Board
Reinstall the printed circuit board as follows: Step Action Position circuit board over stand-offs on backbox rail and secure with four (4) phillips screws. Tighten securely. Connect transformer wires to J1 connector on circuit board. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 17: Installing Optional Voltmeter/Ammeter
Connect meter cable P3 to connector J3 on the main circuit board. The figure below shows the mounting location and connections for the Voltmeter/Ammeter. ‘AMP’ Jumper DC VOLTS DC AMPERES Figure 3 Mounting and Connecting the Meters PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 18: Power Connections
Note: Refer to "Power-Up Procedure" on page 32 before closing AC breaker. Primary power required for the PAR-3 and PAR-3C control panels is 110/120 VAC, 50/60 Hz, 1.2 amps and for the PAR-3E is 220/240 VAC, 50/60 Hz, 0.6 amps. -
Page 19: Power-Limited Wiring Requirements
OPT1 TROUBLE Power-limited ZONE 3 CIRCUIT TROUBLE Circuits ALARM SILENCED ZONE 4 POWER TROUBLE TONE ALARM ALARM SYSTEM SILENCE SILENCE ACTIVATE RESET OPT2 Nonpower-limited Circuits DISABLE LATCH AC Power Figure 6 Power-limited Wiring Requirements PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 20: Initiating Device Circuits
(UL listed) Two-wire Smoke Detector Normally Open Normally Open Tamper or Waterflow Pressure Devices Switches Manual Pull Station Note: Silk screen printing on circuit board moved to bottom for clarity Figure 7 Initiating Device Circuits PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 21: Four-Wire Smoke Detector Connections
Power 24 VDC Four-wire Supervision Smoke Detectors Relay (A77-716B) IN #1 B+ A+ A– B– B+ A+ Control Panel Style B Power Circuit Initiating Device Circuit Figure 8 Typical Connection for Four-Wire Smoke Detectors PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 22: Output Circuits
(Class B) Viking PN 07913 (UL listed) Style Z (Class A) Polarized Bell Polarized Strobe Unused Style Y Circuit 4.7K, 1/4-Watt ELR Viking PN 07913 (UL listed) Polarized Horn Figure 9 Notification Appliance Circuits PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 23: Releasing Circuits
Wiring must be configured to maintain a minimum voltage of 20.4 VDC on releasing Circuits. Calculation of maximum allowable resistance: 20.6 VDC – 20.4 VDC Rmax = Where: Rmax = maximum allowable resistance of wiring Is = Solenoid current PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 24: Alarm Relay Circuit
Resettable Power - 24 VDC filtered, resettable power for four-wire smoke detectors can be obtained from these terminals. The combined current draws from the Resettable and Nonresettable outputs cannot exceed 200 mA. Figure 12 Power Terminals PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 25: Optional Modules
Note: The PAR-3 includes one (1) Zone Relay Module (4XZM). • The 4XZM Zone Relay and the 4XTM Transmitter Modules can be installed in either position. -
Page 26: Installation - Lower Position
IN #4 B– B+ A+ A– B– B+ A+ A– B– B+ A+ A– B– Install Stand-offs here OPT1 OPT2 - Cut prior to installation of module OPT2 Figure 14 Module Installation - Lower Position PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 27: Setup And Configuration
The wiring of this module must follow the requirements as specified under "Power-limited Wiring Requirements" on page 19. Remote Alarm (Power-limited) – Remote Trouble (Power-limited) – No Connection Municipal Box (Nonpower-limited) – TBL Jumper Disconnect LED Disconnect Switch Figure 15 4XTM Configuration PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 28: Zone Relay Module - 4Xzm
Optional Modules Zone Relay Module - 4XZM Note: The PAR-3 includes one (1) Zone Relay Module (4XZM). Relay #1 through #4 on this module will activate with outputs #1 through #4. For non-latching (silenceable) relay operation, cut the jumper “LATCH”. If this jumper is left intact, the relays will latch upon activation. -
Page 29: Led Interface Module - 4Xlm
Out #4 Sysyem Trouble Sound Resound Connect to corresponding terminals of the RZA-4X Remote Annunciator. Single-gang SYSTEM TROUBLE RE-SOUND TONE SILENCE FIRE ALARM ANNUNCIATOR Side View Front View Figure 18 Connection of 4XLM to RZA-4X PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 30: Setting Mode Of Operation
1 or 2. Output 4 - supervisory condition Activated by an on IDC 4. alarm on IDC 2. Note: Output 1 and 2 refer to Notification Appliance Circuits; Output 3 and 4 refer to Releasing Circuits. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 31: Discharge Timer
Note: Timer will always start at Zone 2 normal to alarm transition. Upon timeout, corresponding release circuits will shut off. Note: Zone 1 will always override timer shutoff (except for Mode #4 - Split Release). PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 32: Power-Up Procedure
Connect Secondary Power. Connect battery interconnect wire as shown below. • The trouble LED will clear. If the trouble light does not clear, refer to "Troubleshooting Table" on page 52. Battery Interconnect Wire Figure 20 Battery Connections PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 33: System Operation
Ground Fault ( ) - Yellow LED that illuminates steadily on motherboard during a ground fault EARTH condition. Micro Fail - Yellow LED that illuminates on motherboard when watchdog timer detects microprocessor failure. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 34: Control Switches
The alarm and/or trouble LED(s) will flash until the event(s) has been acknowledged (TONE or ALARM SILENCE), at which point the LED(s) will illuminate steadily. ZONE 1 Alarm LED ZONE 2 Trouble LED ALARM PRESSURE Not Used SUPERVISORY Figure 23 Zone Status LEDs PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 35: Piezo
To select the previous zone, press the ALARM ACTIVATE switch. When disable selections are complete, release the TONE SILENCE switch. If any zone has been disabled, the trouble relay will activate and System Trouble LED will flash. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 36: Last Event Recall
Trouble Relay Contacts will transfer. The piezo (local buzzer) will sound one second on, one second off, and repeating until silenced. Silence the piezo by pressing the TONE SILENCE switch. The panel will remain in the trouble state until the trouble condition has been cleared and the panel reset. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 37: Single Zone In Alarm (Cross Zone) Condition
When the AC voltage returns or increases above the brownout threshold, the green AC Power LED will illuminate. The power supply circuitry will return to primary power functions and begin to recharge the backup battery supply. PAR-3 Instruction Manual PN 15181:G0 10/01/02... - Page 38 3. System Operation System Events Notes PAR-3 Instruction Manual PN 15181:G0 10/01/02...
-
Page 39: Appendix A: Secondary Power Calculations
3. The total standby current must include both the resettable (TB1 - +24VR terminals) and nonresettable (TB2 - +24VNR terminals) power. Caution must be taken to ensure that current drawn from these outputs during alarm does not exceed maximum ratings specified. Table 1 Standby Battery Current PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 40: Calculating The Battery Capacity
Batteries larger than 12 AH will require a UL-listed battery cabinet (e.g. BB-17). Select a battery with an equal or greater AH rating than the value obtained in the table above. Note: Batteries must be lead-acid type. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 41: Appendix B: Compatible Devices
Hochiki SLK-24F HD-3 Photoelectric HS-22D HB-3 0.045 HS-2-RB HB-10 YBA-M22 HB-3 HSB-220 HB-56 HSB-224 HB-53 Hochiki SLK-24FH HD-3 Photoelectric HS-22D HB-3 0.045 HS-2-RB HB-10 YBA-M22 HB-3 HSB-220 HB-56 HSB-224 HB-53 Table 3 Two-wire Smoke Detectors PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 42: Four-Wire Smoke Detectors, Ul Listed
11596NO 24 VDC 10.0 416 mA 1/2” 9/16” Group K - 250 psi Viking 11601NO 24 VDC 338 mA 1/2” 3/4” Viking 11602NO 24 VDC 338 mA 1/2” 3/4” Table 5 Solenoid Release Valves PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 43: Notification Appliances, Ul Listed
System Sensor SP100W24LOC Ceiling Speaker/Strobe, 8” round grill System Sensor SP101R24LO Speaker/Strobe, 5” square grill (SP101W24LO- white) System Sensor SP101R24M Speaker/Strobe, 5” square grill (SP101W24M- white) System Sensor SP100W24MC Ceiling Speaker/Strobe, 8” round grill System Sensor V400R Speaker, 4” square grill PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 44: Door Holders, Ul Listed
Use only the Door Holders listed below. Product FM-980 Floor Mount, single FM-986 Surface Wiring FM-998 Concealed Wiring DH150A Floor Mount DH150N Floor Mount DH154A Flush Mount DH154N Flush Mount DH158A Surface Mount DH158N Surface Mount Table 7 Door Holders PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 45: Appendix C: Nfpa Standard-Specific Requirements
Station DACR. See "Universal Digital Alarm Communicator - 411UDAC" on page 47 for installation instructions for this unit. NFPA 72 - Proprietary Fire Alarm System • Potter EFT-C McCulloh Transmitter. See "Potter EFT-C McCulloh Transmitter" on page 50 for installation instructions for this unit. PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 46: Digital Alarm Communicator/Transmitter - Noti-Fire 911Ac
To Common OPT1 Terminal of Relay Jumper Place jumper over pins as shown when employing a DACT. This directs the control panel to transmit all trouble conditions except AC LOSS. Figure 24 DACT Connections PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 47: Universal Digital Alarm Communicator - 411Udac
(6.1 meters) in length in the same room. • The PAR-3 is non suitable for transmission of a supervisory signal to the DACT. • Any zone of the 411UDAC can be wired to function as alarm or trouble; the unit must be programmed accordingly. -
Page 48: Local Energy Municipal Box
• Maximum loop resistance allowed for wiring from control panel to Municipal Box is 3 ohms. FIRE Municipal Box Circuit – Local Energy Municipal Box 4XTM Transmitter Module (activated polarities shown) Figure 26 Municipal Box Connection PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 49: Remote Station Receiver - Rs82-9
• All connections are power-limited and supervised with the exception of the reverse polarity loop. • Supervision of the loop is the responsibility of the receiver. Fire•Lite RS82-9 Remote Station Receiver – – Remote Alarm Remote Trouble 4XTM Transmitter Module Figure 27 RS82-9 Connections PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 50: Potter Eft-C Mcculloh Transmitter
Potter EFT-C PAR-3 Terminal Blocks IN #1 IN #2 IN #3 IN #4 B+ A+ A– B– B+ A+ A– B– B+ A+ A– B– B+ A+ A– B– Figure 28 Potter EFT-C Connections PAR-3 Instruction Manual PN 15181:G0 10/01/02... -
Page 51: Appendix D: Testing & Maintenance
The procedures should be performed as required by the local authority having jurisdiction. Refer to NFPA for further details. Troubleshooting A troubleshooting table is included on the following page which provides for symptoms, problems and their solutions. PAR-3 Instruction Manual PN 15181:G0 10/01/02... - Page 52 Loss of main power 1. Check incoming power (TB5). System trouble LED ON Power Damaged circuit breaker 1. Replace circuit board. LED OFF Micro Fail yellow LED ON Microprocessor damaged 1. Replace circuit board. PAR-3 Instruction Manual PN 15181:G0 10/01/02...
- Page 53 Central Station 45, 46, 47 four-wire smoke detector 13, 34 charging current circuit Remote Alarm Remote Trouble General Alarm reverse polarity ground fault 33, 48 circuit board circuit breaker Combined Release Indicating Circuit #1 conductors PAR-3 Instruction Manual PN 15181:G0 10/01/02...
- Page 54 Maximum Battery Capacity Maximum Charging Circuit maximum resistance rail Meter Module rail, backbox 12, 17 15, 16 microprocessor red wire minimum clearance regulated power minimum voltage relay contacts module connectors Relay, System Alarm motherboard release PAR-3 Instruction Manual PN 15181:G0 10/01/02...
- Page 55 33, 35 Supervisory LED supervisory signal supplementary devices switch, disable system alarm System Alarm Relay System Trouble LED tag, “Out of Service” terminal identification label 25, 26 testing timer, watchdog PAR-3 Instruction Manual PN 15181:G0 10/01/02...
-
Page 56: Limited Warranty
This warranty replaces all previous warranties and is the only warranty made by the manufacturer on this product. No increase or alteration, written or verbal, of the obligation of this warranty is authorized. This product is manufactured by NOTIFIER for VIKING. 210 No. Industrial Park Road Hastings, MI 49058...
