SMART HUB

SMART CONTROLLER SERIES

#Smarthomehub

Table of Contents

Need help?

Do you have a question about the Smart Hub and is the answer not in the manual?

Questions and answers

Summary of Contents for hogar Smart Hub

Page 1 SMART HUB SMART CONTROLLER SERIES #Smarthomehub...
Page 3 & choosing Hogar Smart Hub. This manual is designed to help you install your Hogar Smart Hub in an easy and hassle-free manner. Please follow all the steps given below and experience the safety and comfort of your very own, personal smart space.
Page 4: Table Of Contents
SMART HUB TABLE OF CONTENTS USAGE NOTICE 1.1. Warnings and Considerations 1.2. Precautions PRODUCT DETAILS 2.1. Description 2.2. Features 2.3. Technical Speciﬁcations 2.4. App Registration/ Login 2.5. Conﬁguration Process WARRANTY...
Page 5: Usage Notice
Install this device by following the socket type mentioned. Using this product in any manner other than how it this document VOIDS your warranty is referred to in Further, Hogar Controls is NOT liable for any damage incurred due to the misuse of the product.
Page 6 Avoid pressing hard on the device body, reset button, and connecting ports. This is an electronic device with complex components. Handle and install with care! If you are not sure about any part of these instructions, please consult a Certiﬁed Electrician to perform the installation process.
Page 7: Precautions
1.2. PRECAUTIONS Ensure the below DOs & DON'Ts are followed to enjoy a seamless product experience: - TURN OFF the product before cleaning. - Clean the product with a soft dry cloth. DON'Ts - DON'T drop or disassemble the device. - DON'T touch the device with sharp or hard objects.
Page 8: Description
USAGE NOTICE 2.1 DESCRIPTION Hogar Smart Hub can connect devices to a network and control communication among them, it allows you to control your smart home devices which are connected either locally or from the cloud using Hogar Pro S mobile application.
Page 9 - It lets you monitor history of events. - It supports IR device control (TV/AC/Set-top box) - It can be accessed both locally and remotely. NOTE: For optimal performance, place Hogar Smart Hub ﬁve feet above the ground level vertically.
Page 10: Technical Specifications
2.3. TECHNICAL SPECIFICATIONS Model Number HC-01-SHT-IN Brand Name Hogar Power Requirement 5V DC Quad-core ARM® Cortex®-A9@1.2GHz RAM & ROM 512MB & 4GB eMMC v4.5 Setup Mobile Application Number of Z-Wave 230+ Devices supported per controller Encryption Security Level Multi-Controller Upto 9...
Page 11 Wi-Fi, Ethernet, Internet Connectivity 3G/4G USB Modem Wireless Range 50m outdoor - 30m indoor...
Page 12: App Registration/ Login
2.4. APP REGISTRATION / LOGIN Sign Up: - Open the Hogar Pro S App - You can either sign up with your mobile number or email id. - Enter a password of your choice and click “Register”. - You will receive an OTP which is valid for 10 mins. Enter the OTP and sign up.
Page 13: Configuration Process
2.5. CONFIGURATION PROCESS Adding Hogar Smart Hub to Hogar Pro S App: Conﬁguration of Smart Hub - Click on “Add Home” or Tap on the “ ” button on the top right corner of the screen. - Enter the following details: Home name, Domain (Unique without space &...
Page 14 “Continue”. - Connect your phone to the internet and go back to the mobile App, click on “OK”. - Wait until Hogar Smart Hub gets reboot. Choose LAN conﬁguration. Cerebro Pro does not support 3G/4G conﬁguration. - You can choose DHCP/ STACTIC IP conﬁguration.
Page 15 - Add the ‘Room details’ and type in the Room Name. - Assign a photo by allowing Hogar Pro S App to click pictures by tapping ‘’Allow’’. - The created Floors appear as a list.
Page 16 SETUP FOR YOUR FLOORS Adding Floors to your Hogar Pro S App: - Go to Settings → General → Conﬁg Room & Floor. Tap ‘ ’ button in the top right corner. - Name the “Floor”. - Tap “Done”. You can always edit the Floor details by tapping on the “Edit”...
Page 17 SETUP FOR MULTIPLE HCs Hogar Smart Hub allows multiple controllers on the same network. There is only one primary Home Controller which can act as Master and the rest as Slave controllers. Slave controllers also communicate with devices directly connected to it.
Page 18 ADDING/ DELETING SMART DEVICES TO YOUR HOGAR SMART HUB SETUP FOR Z-WAVE SMART DEVICES Adding Smart Devices: - Scroll through the Hogar Pro S App, choose Z-Wave to “Add” devices. - You will receive a pop-up notiﬁcation display stating “Device Added”...
Page 19 Set Timer for Rule: Enable Timer and Scroll through the timer, choose a time between 0 and 23 hours and 0 to 59 minutes and click on “Conﬁrm” to save. Add input/output devices: Add the input and output devices to Hogar Smart Hub.
Page 20 Normally, various smart sensors can be automated through scenes to trigger your smart switches. No manual intervention or internet connectivity is required once certain scenes are set by you on your Hogar Pro S App.
Page 21 Add a Scene: Go to scenes. Tap the “ ” button in the top right corner of the screen. Add scenes to the room by selecting the “Room” in the scene. Tap “Done” on the top right corner when you are done with creating the scene.
Page 22 Edit Existing Scene: Tap on a speciﬁc scene from the list, and change the data accordingly and tap “Done”. Delete a Scene: Go to Settings → General → Scene → Select the Scene → Scroll to bottom → Click on Delete Scene GROUPS Using this functionality, you can Group devices of the same type i.e Switches grouping, RGBW grouping, Light dimmer, Fan speed...
Page 23 Delete a Group: Go to Settings → General → Group → Select the Group → Scroll to bottom → Click on Delete Group SCHEDULE To view the list of schedules, go to Settings → General → Schedules Add a Schedule: Go to Settings →...
Page 24 RESETTING INFORMATION Network and Factory reset (Using reset button) LED Indication for Network reset: - Press and hold the reset button until the LED changes colors from red - yellow - white - magenta; release the button (Magenta blinks) - Press and hold the reset button until magenta becomes stable. LED Indication for Factory reset: - Press and hold the reset button until the LED changes colors from red - yellow - white - magenta;...
Page 25: Warranty
Warranty Hogar offers an Exclusive 18-Month Warranty on any product that covers defects in materials and quality under normal use of the Product. The Terms and Conditions of this 1.5 YEARS LIMITED WARRANTY can be viewed on www.hogarcontrols.com or scan...
Page 26 CONGRATULATIONS You've successfully installed & Conﬁgured Hogar TUBRO. Now you can experience seamless control of home with Hogar Pro S Application Add more smart home devices to your home from our range of smart home solutions and live a smart life.
Page 27 Hogar Controls Inc, 46040 Center Oak Plaza, Suite 125, Sterling, Virginia 20166 | Phone : +1 703 844 1160 INDIA Hogar Controls India Pvt. Ltd., Plot No. 3, support@hogarcontrols.com I.D.A-Uppal, Hyderabad, Telangana, India www.hogarcontrols.com Phone : +91 844 844 0789...
