Revision #1.5
Feb 3, 2025
If you purchased an 8'x12' Deer Fence Option go to Page 2 for Assembly Manual.
If you purchased an 8'x16' Deer Fence Option go to Page 9 for Assembly Manual.
8'x12' Deer Fence Option - Base Kit + 1 Extension 8'x16' Deer Fence Option - Base Kit + 2 Extensions
If you ordered an 8'x12' Deer Fence Option, you will receive 1 - 4ft Extension Box.
If you ordered an 8'x16' Deer Fence Option, you will receive 2 - 4ft Extension Boxes.
The Base Kit (8'x8') is contained in Boxes 1 & 2.
In the event of a missing or broken piece, simply call the Outdoor Living Today
Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your
purchase. It is our commitment to you to courier replacement parts, free of charge,
within 10 business days of this notification. Replacement parts will not be
provided free of charge after the 30 day grace period.
Outdoor Living Today
8'x12' Deer Fence Option
8'x16' Deer Fence Option
Assembly Manual
Licensed under US PATENTS 7,424,787; 7,490,435
IMPORTANT
www.outdoorlivingtoday.com
Page 1
and
sales@outdoorlivingtoday.com
Advertisement
Summary of Contents for Outdoor living today Deer Fence Option
- Page 1 If you purchased an 8’x16’ Deer Fence Option go to Page 9 for Assembly Manual. 8’x12’ Deer Fence Option - Base Kit + 1 Extension 8’x16’ Deer Fence Option - Base Kit + 2 Extensions If you ordered an 8’x12’ Deer Fence Option, you will receive 1 - 4ft Extension Box.
-
Page 2: Safety Equipment Required
Work Gloves Safety Glasses In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier replacement parts, free of charge, within 10 business days of this notification. -
Page 3: Hardware Kit
Exploded View and Parts List for 8x12 Raised Bed Deer Fence Option Kit Parts List Part 1 8 pcs - Side/Rear Deer Fence Panels (46”wide x 33 5/8”high) Part 2 3 pcs - Front Deer Fence Panels (30 5/8”wide x 33 5/8”high) Part 4 4 pcs - Corner Brackets (angle cut ends) (1 1/2”... - Page 4 Hold both rear deer fence frames together and starting at the top, screw together with 4 - 2” screws as shown above. Screw bottom of frame down to raised bed frame with 4 - 2” screws. Complete remaining side and rear panels attachments following Steps 2 and 3. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 5 Attach Corner Brackets with angle cut ends - (4) on the inside frames at the top. Use 2 - 2 1/2” screws per bracket. Screw on an angle. Pre-drill ends with 1/8” drill bit to prevent wood splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 6 Attach Black Barrel Bolt to door and panel frame using 6 - 3/4” black screws. Note how female part of Barrel Bolt is positioned higher than male. Do a dry run first to position Barrel Bolt correctly, then attach. Pre-drill with 1/8” drill bit to prevent wood from splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 7 Install the Door Stop at the top of interior panel frame as shown above. We hope your experience assembling our 8’x12’ Raised Garden Bed Deer Fence Option Kit has been both positive and rewarding. We value your feedback and would like to hear back from you on how well we are doing in the following areas: 1.
- Page 8 8’x16’ Deer Fence Option Assembly Manual on Next Page Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 8...
- Page 9 Work Gloves Safety Glasses In the event of a missing or broken piece, simply call the Outdoor Living Today Customer Support Line @ 1-888-658-1658 within 30 days of the delivery of your purchase. It is our commitment to you to courier replacement parts, free of charge, within 10 business days of this notification.
- Page 10 Exploded View and Parts List for 8x16 Raised Bed Deer Fence Option Kit Parts List Part 1 10 pcs - Side/Rear Deer Fence Panels (46”wide x 33 5/8”high) Part 2 3 pcs - Front Deer Fence Panels (30 5/8”wide x 33 1/2”high) Part 4 4 pcs - Corner Brackets (angle cut ends) (1 1/2”...
- Page 11 Hold both rear deer fence frames together and starting at the top, screw together with 4 - 2” screws as shown above. Screw bottom of frame down to raised bed frame with 4 - 2” screws. Complete remaining side and rear panels attachments following Steps 2 and 3. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 12 Attach Corner Brackets with angle cut ends - (4) on the inside frames at the top. Use 2 - 2 1/2” screws per bracket. Screw on an angle. Pre-drill ends with 1/8” drill bit to prevent wood splitting. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 13 4 - 2” screws. Offset the screw to either side of the support to ensure bottom. you contact the heart of the bed frame. Even. Position and attach short Vertical Panel Support using 3 - 2” screws as per Step 8. Complete remaining rear and side walls. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com Page 13...
- Page 14 The Door Stop (I) and screws were included with your 8x16 Raised Garden Bed Kit. See Step 21 of that manual. Install the Door Stop at the top of interior panel frame as shown above. Outdoor Living Today www.outdoorlivingtoday.com sales@outdoorlivingtoday.com...
- Page 15 We hope your experience assembling our 8’x16’ Raised Garden Bed Deer Fence Option Kit has been both positive and rewarding. We value your feedback and would like to hear back from you on how well we are doing in the following areas: 1.
