- Page 1 220-Lb. Steel Service Cart Owner’s Manual WARNING: Read carefully and understand all ASSEMBLY AND OPERATION INSTRUCTIONS before operating. Failure to follow the safety rules and other basic safety precautions may result in serious personal injury. Item #53414 SAVE THESE INSTRUCTIONS...
- Page 2 Thank you very much for choosing an Ironton™ product! For future reference, please complete the owner’s record below: Serial Number/Lot Date Code: ________________________________ Purchase Date: ____________________________________________ Save the receipt, warranty, and this manual. It is important that you read the entire manual to become familiar with this product before you begin using it.
-
Page 3: Table Of Contents
Table of Contents Intended Use ............................4 Technical Specifications ........................4 Important Safety Information ....................... 4 Specific Operation Warnings ....................... 5 Main Parts of Product ........................... 6 Assembly Instructions .......................... 6 Before Each Use ............................ 8 After Each Use ............................8 Parts Diagram ............................ -
Page 4: Intended Use
Intended Use Ironton’s Steel Service Cart has smooth, rolling 4’’ solid rubber casters, a 220 lbs. load capacity, a tubular steel handle, and a tough enamel finish. It’s easy to assemble and has two deep shelves for plenty of storage. -
Page 5: Specific Operation Warnings
children to handle the product. ⚠WARNING PERSONAL SAFETY Stay alert, watch what you are doing, and use common sense when operating the tool. Do not use the tool while you are tired or under the influence of drugs, alcohol, or medication. A moment of inattention while operating the tool may result in serious personal injury. -
Page 6: Main Parts Of Product
Main Parts of Product Reference Subassembly Tray Post Wheel Assembly Instructions 1. Attaching Posts to Bottom Tray Lay the Bottom Tray (2) (tray with four sets of four holes on the bottom) on the floor and attach the Posts (7) to the outside corners of the tray using sixteen Bolts (9), Washers (11), Lock Washers (10), and Nuts(8). - Page 7 3. Attaching Handle Assemble the Handle Brackets (6) onto ends of Handle (4) and attach Handle to end of Posts (7) using four Bolts (12), Washers (11), Lock Washers (10), and Nuts (8). See Figure 3. Attaching Wheels 1. Decide on which end of the cart to mount the pair of Fixed Wheels (5) and pair of Swivel Wheels (3).
-
Page 8: Before Each Use
2. Attach each Fixed Wheel to one end of the Bottom Tray using four Bolts (13), Lock Washers (14), and Nuts (15). 3. Attach each Swivel Wheel to the remaining end of the Bottom Tray using the remaining Bolts (13), Lock Washers (14), and Nuts (15). Before Each Use ⚠WARNING Inspect unit before every use. -
Page 9: Parts Diagram
Parts Diagram Parts List Reference Description Quantity Top Tray Bottom Tray Swivel Wheel Handle Fixed Wheel Handle Bracket Post Nut M6 Bolt M6 x12 Lock Washer Washer Bolt M6 x15 Bolt M8 x12 Lock Washer Nut M8 Page 9 of 12... -
Page 10: Replacement Parts
Replacement Parts For replacement parts and technical questions, please call Customer Service at 1-800-222-5381. Not all product components are available for replacement. The illustrations provided are a convenient reference to the location and position of parts in the assembly sequence. ... -
Page 11: Limited Warranty
Northern Tool and Equipment Company, Inc. ("We'' or '"Us'') warrants to the original purchaser only ("You'' or “Your”) that the Ironton product purchased will be free from material defects in both materials and workmanship, normal wear and tear excepted, for a period of one year from date of purchase. - Page 12 Distributed by: Northern Tool & Equipment Company, Inc. Burnsville, Minnesota 55306 www.northerntool.com Made in China Page 12 of 12...
