- Page 1 EN 36V 2-in-1 Brush Cutter ERT1026GBC ORIGINAL INSTRUCTIONS 5059340904771 IMPORTANT - These instructions are for your safety. (UK) Please read through them thoroughly prior to handling the product and retain them for future reference. 5059340904641 (EU) MNL_ERT1026GBC_EN_V01_240711...
- Page 2 EN Parts 02. x1 03. x1 08. x1 10. x1 11. x1 09. x1 05. x1 06. x1 12. x1 01. x1 07. x1 EN You will need...
-
Page 3: Table Of Contents
EN Contents Product description Safety Technical specification Before you start Functions & Settings Operation Care and maintenance Guarantee Declaration of conformity... -
Page 4: Product Description
EN Product Description 15 16 18 Coupler Motor shaft Speed Mode Switch Slot on backing flange Rear Handle Backing flange Wing Knob Flange Cover Lock-off Button Locking flange Variable Speed Trigger battery docking port Trimmer line Front-Assist Handle Trimmer head Barrier Trimmer guard Lower shaft... -
Page 5: Electrical Safety
EN Safety General power machine safety warnings WARNING! Read all safety warnings, instructions, illustrations and specifications provided with this machine. Failure to follow all instructions listed below may result in electric shock, fire and/or serious injury. Save all warnings and instructions for future reference The term “machine”... -
Page 6: Personal Safety
Avoid body contact with earthed or grounded surfaces such as pipes, radiators, ranges and refrigerators. There is an increased risk of electric shock if your body is earthed or grounded. Do not expose machines to rain or wet conditions. Water entering a machine will increase the risk of electric shock. - Page 7 Use personal protective equipment. Always wear eye protection. Protective equipment such as a dust mask, non-skid safety shoes, hard hat, or hearing protection used for appropriate conditions will reduce personal injuries. Prevent unintentional starting. Ensure the switch is in the off-position before connecting to power source and/or battery pack, picking up or carrying the machine Carrying machines with your finger on the...
- Page 8 Machine use and care Do not force the machine. Use the correct machine for your application. The correct machine will do the job better and safer at the rate for which it was designed. Do not use the machine if the switch does not turn it on and off.
- Page 9 Use the machine, accessories and tool bits etc., in accordance with these instructions, taking into account the working conditions and the work to be performed. Use of the machine for operations different from those intended could result in a hazardous situation. Keep handles and grasping surfaces dry, clean and free from oil and grease.
- Page 10 Do not use a battery pack or machine that is damaged or modified. Damaged or modified batteries may exhibit unpredictable behaviour resulting in fire, explosion or risk of injury. Do not expose a battery pack or machine to fire or excessive temperature.
- Page 11 Thoroughly inspect the area where the machine is to be used and remove all stones, sticks, wires, bones, and other foreign objects. Thrown objects can cause personal injury. Before using the machine, always visually inspect to see that the cutter or blade and the cutter or blade assembly are not damaged.
- Page 12 Always use two hands when operating the machine. Holding the machine with both hands will avoid loss of control. Hold the machine by the insulated gripping surfaces only, because the cutting line or blade may contact hidden wiring. Cutting line or blades contacting a “live” wire may make exposed metal parts of the machine “live”...
- Page 13 Do not operate the machine above waist height. This helps prevent unintended cutter or blade contact and enables better control of the machine in unexpected situations. When cutting brush or saplings that are under tension, be alert for spring back. When the tension in the wood fibers is released, the brush or sapling may strike the operator and/or throw the machine out of control.
- Page 14 When clearing jammed material or servicing the machine, make sure the switch is off and the battery pack is removed. Unexpected starting of the machine while clearing jammed material or servicing may result in serious personal injury. BLADE THRUST CAUSES AND RELATED WARNINGS Blade thrust is a sudden sideways, forward or backward motion of the machine, which may occur when the blade jams or catches on an object such as a sapling or a tree...
- Page 15 Do not use blunt or damaged blades. Blunt or damaged blades increase the risk of jamming or catching on an object, resulting in blade thrust. Always maintain good visibility of the material being cut. Blade thrust is more likely to occur in areas where it is difficult to see the material being cut.
-
Page 16: Vibration And Noise Reduction
d) Keep hands away from any sharp device intended to limit the length of the filament line. e) Once encountered blockage of the cutting accessory or cutting head, stop the motor and removed battery, inspect the cutting accessory or cutting head and clean all the foreign objects which cause blockage. - Page 17 2. Ensure that the product is in good condition and well maintained. 3. Use correct application tools for the product and ensure they in good condition. 4. Keep tight grip on the handles/grip surface. 5. Maintain this product in accordance with these instructions and keep it well lubricated (where appropriate).
-
Page 18: Residual Risks
Residual risks Even if you are operating this product in accordance with all the safety requirements, potential risks of injury and damage remain. The following dangers can arise in connection with the structure and design of this product: 1. Health defects resulting from vibration emission if the product is being used over long periods of time or not adequately managed and properly maintained. - Page 19 Symbols On the product, the rating label and within these instructions you will find among others the following symbols and abbreviations. Familiarise yourself with them to reduce hazards like personal injuries and damage to property. Volt, (direct current /min or min Per minute voltage) Milliampere per hour...
- Page 20 WARNING –Beware of blade thrust WARNING –Disconnect battery before maintenance WARNING – The distance between the machine and bystanders shall be at least 15 m Keep the pole mounted powered pruner a sufficient distance away from electrical power lines. Objects thrown by the product could hit the user or other bystanders. Always ensure that other people and pets remain at a safe distance from the product when it is in operation.
- Page 21 The product complies with the applicable Your product European directives and an evaluation method of conformity for these directives was done. UK Conformity Assessed Rating label explanation Cordless Brush Cutter: ERT1026GBC ER= Brand name( Erbauer) T=36V Lithium-Ion 1026=Serial number GBC=Garden brush cutter...
-
Page 22: Technical Specification
EN Technical specifications General: > Rated voltage Extension pole For Grass trimmer: Maximum speed n (two-speed 5000/6000/min switch): > Trimming line Non-mentallic(nylon),2.0mm > Cutting width 38cm > Total length of cutting line > Weight(without battery pack, cutting head ,cutting 4.45kg attachment cover and harness.) >... -
Page 23: Before You Start
> Measured sound power level L 91dB > Uncertainty K 1.1dB > Front handle vibration value a 4.23m/s > Rear handle vibration value a 4.74m/s Sound values (For brush cutter): > Sound pressure level L 82dB > Uncertainty K > Guaranteed sound power level Lwa >... -
Page 24: You Will Need
You will need (items not supplied) (items supplied) Suitable personal protective equipment Shoulder strap NOTE: The accessories required depend on the intended application. Ask your dealer for advice. EN Assembly WARNING! The product must be fully assembled before operation! Do not use a product that is only partly assembled or assembled with damaged parts! WARNING! Disconnect the battery pack from the machine before making any assembly, adjustments, changing accessories, or storing machine. - Page 25 Loosen the wing knob. The power head has two grooves on the coupler, ONLY the groove 1 is used to connect an attachment. Align the spring-loaded pin on the attachment shaft with the groove 1 on the coupler and push the attachment shaft into the power head shaft until the pin pops out of the groove and you hear an audible “click”...
-
Page 26: Shoulder Strap
WARNING! The front-assist handle should be positioned within the mounting zone, not exceeding the limit label, so that the distance between the center of the handles is at least 250 mm for safe operation. Tighten the wing nut to prevent the handle from rotating around the shaft. Shoulder strap The shoulder strap (27) helps the operator carry this product. - Page 27 MOUNTING THE GUARD (FIG. 5a&5b) Blade guard Align the blade guard mounting holes with the assembly holes on the lower shaft (10) and then lock it with the two screws (Fig. 5a) using hex key tool (26). Trimmer guard Use the same method to attach the trimmer guard (24) as above. Then attach the cover on the trimmer guard (24) with other two screws (Fig.
- Page 28 Place the locking flange (20) onto the cutting blade (14). Secure the cutting blade (14) with the nut (21) by using the multi-function wrench (25) (Fig. 6b). Remove the hex wrench (26). NOTE: Take off the blade cover before using and save it for storage. TRIMMING HEAD (FIG.
-
Page 29: Battery Pack
Lift the power head and turn upside down on a flat surface and loose the wing nut. Align the slot of the barrier (9) with the front assist handle (8), and then tighten the wing nut so that it cannot move during operation Battery pack Attaching / releasing the battery pack(Fig.9) Slide the battery pack into the battery docking port (7) until it is securely locked in... -
Page 30: Functions & Settings
EN Functions & settings Intended use You may use the brush cutter for the purpose listed below: With the blade attached, the product is intended to cut heavier weeds, brush and similar vegetation with a thickness of up to 20mm. With the trimming head attached the product is intended to cut smaller types of weed, lawn grass or similar soft vegetation in areas that are hard to reach, e.g. -
Page 31: Operation
EN Operation USING THE MACHINE WARNING! Never operate the tool without the guard and handle (8)(9) firmly in place. Failure to comply could result in possible serious personal injury. WARNING! To prevent accidental starting that could cause serious personal injury, always remove the battery pack from the tool when assembling parts or transporting the machine. - Page 32 NOTE: For best results, do not cut wet grass because it tends to stick to the trimming head and guard, prevents proper discharge of grass trimmings, and could cause you to slip and fall. NOTE: Pay special attention when performing the work close to trees and bushes. The trimming head could damage sensitive bark, and damage fence posts.
- Page 33 WARNING! The higher the cutting unit is off the ground, the greater the risk of injury from cuttings being thrown sideways. WARNING! When cutting young trees or other woody materials up to 2cm in situations. diameter, use the left side of the blade to avoid blade thrust not attempt to cut woody material with a larger diameter, since the blade may catch or jerk the brush cutter forward.
- Page 34 Follow the correct working posture as shown in the picture (Fig.14), Need rest and changing working positions regularly.
- Page 35 OVERLOAD, TEMPERATURE AND CHARGING PROBLEM TOOL / BATTERY Solution Problem Possible cause STATUS Overload Product Extremely high Relieve the load protection suddenlystops torque, binding and immediately, reset the tool stalling situations, by switching off and back overloading of the tool on again.
-
Page 36: Care And Maintenance
EN Care and maintenance WARNING! Always switch the product off, remove the battery pack and let the product cool down before performing inspection, maintenance and cleaning work! Only perform care and maintenance work according to these instructions! All further works must be performed by a qualified specialist! Improper maintenance can cause serious injuries. -
Page 37: Maintenance
Turn the bumper (23b) clockwise to wind the trimming line in (Fig. 15, step 3) until around 175 mm of trimming line remains on each side. Tighten the trimmer head anti-clockwise on the spindle and remove the locking pin afterwards. GUARD Keep the trimming guard (24) and blade guard (12) clean and free of debris. - Page 38 Spare parts / Replacement parts The following parts of this product may be replaced by the consumer. Spare parts are available at an authorised dealer or through our customer service. Description Model no. or Specification Trimmer head Non-metallic(nylon),2.0mm Brush cutter blade Ø250 x Ø25.4 x 2mm, 3Teeth Repair This product does not contain any parts that can be repaired by the consumer.
-
Page 39: Recycling And Disposal
Recycling and disposal Waste electrical products should not be disposed of with household waste. Please recycle where facilities exist. Check with your Local Authority or local store for recycling advice. For further information visit www.recycle-more.co.uk. The product comes in a package that protects it against damage during shipping. Keep the package until you are sure that all parts have been delivered and the product is working properly. -
Page 40: Guarantee
This guarantee is in addition to and does not affect your statutory rights relating to faulty goods as a consumer. Manufacturer: Kingfisher International Products Limited 1 Paddington Square, London, W2 1GG, United Kingdom www.kingfisher.com/products Distributor: B&Q plc Chandlers Ford, Hants, SO53 3LE, United Kingdom www.diy.com... -
Page 41: Availability Of Spare Parts
EN Customer care and technical helpline A better way to repair your tools Kingfisher takes special care in creating high-quality garden power tools that are designed to last. But if a fault develops with your garden power tool and you need to claim under the... -
Page 42: Declaration Of Conformity
• CORDLESS BRUSHCUTTER/ DÉBROUSSAILLEUSE SANS FIL/ BEZPRZEWODOWA PODKASZARKA/ COSITOARE PENTRU TUFIȘURI FĂRĂ FIR/ DESBROZADORA INALÁMBRICA/ ROÇADORA SEM FIOS • 85018.1/ ERT1026GBC • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Nom et adresse du fabricant ou de son mandataire: Nazwa i adres producenta lub jego upoważnionego przedstawiciela:... - Page 43 The object of the declaration described above is in conformity with the relevant Union harmonisation legislation: L’objet de la déclaration décrit ci-dessus est conforme à la législation d’harmonisation de l’Union applicable: Wymieniony powyżej przedmiot niniejszej deklaracji jest zgodny z odnośnymi wymaganiami unijnego prawodawstwa harmonizacyjnego: Obiectul declarației descris mai sus este în conformitate cu legislația relevantă...
- Page 44 Measured Sound Power Level Guaranteed Sound Power Level Le niveau de puissance acoustique mesuré Le niveau de puissance acoustique garant Zmierzony poziom mocy akustycznej Gwarantowany poziom mocy akustycznej Nivel de putere acustică măsurat Nivel de putere acustică garantat Nivel de potencia sonora medido Nivel de potencia sonora garantizado Nível de potência sonora medido Nível de potência sonora garantido...
- Page 45 și deținător al dosarului tehnic/firmante autorizado y titular del expediente tecnico/ signatário autorizado e detentor da ficha técnica Kingfisher International Products B.V., Rapenburgerstraat 175E, 1011 VM Amsterdam, The Netherlands...
- Page 46 (UK) DECLARATION OF CONFORMITY Product • CORDLESS BRUSHCUTTER • 85018.1/ ERT1026GBC • Serial number 00001-99999 Name and address of the manufacturer or his authorised representative: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom This declaration of conformity is issued under the sole responsibility of the manufacturer.
- Page 47 Authorised signatory and technical file holder: Kingfisher International Products Limited 1 Paddington Square London W2 1GG United Kingdom David Awe Group Quality Director On [30/07/2024]...
- Page 48 Manufacturer : EN www.diy.com UK Manufacturer: To view instruction manuals online, 1 Paddington Square, London, W2 1GG, United Kingdom EU Manufacturer: Rapenburgerstraat 175E 1011 VM Amsterdam The Netherlands...
