Summary of Contents for Inex IZ600F
- Page 1 Documents IZ600F User Guide Bullet ALPR Camera CAUTION Inex products must be mounted as described in their Installation Guides. If not, moisture problems may occur - which are not covered by the warranty.
-
Page 2: Table Of Contents
8.1. Determining the IP Address of the RoadView Computer with IZ Discovery 8.2. Logging In 8.3. Logging Out 9. Maintenance 9.1. Checking Mounting Screws 9.2. Cleaning the Camera 10. Notices 10.1. Inex Technologies End User Agreement 10.2. Safety Precautions 10.3. Regulatory Notices 10.4. Documentation Notices... -
Page 3: Related Documents And Software
1. Related Documents and Software Table 1. Related Documents and Software Doc. No. Title IZ600F-MAN-002b IZ600F Installation Guide IZ600F-TECH-004 IZ600F Quick Start Guide IZ600F-REV-x-TDSHEET IZ600F Technical Data Sheet IZ600F Camera Mount Installation MOUNT-IZ600F-PRSNT-010 documentation IZ Discovery Utility IZ Discovery Utility software components... -
Page 4: Applicability
Later versions may require changes to this document. 3. Training and Support 3.1. Training This document does not take the place of training by Inex Technologies' certi- ed specialists. Contact Inex Technologies to schedule training. 3.2. Support If you have any questions, please contact our support team via our Inex Technologies Website. - Page 5 3 mm Allen/hex key for pan/tilt/roll adjustment Screws and anchors to attach the camera to a wall or surface NOTE If any parts are missing or damaged, please contact Inex Technologies.
-
Page 6: Dimensions
4.3. Dimensions Figure 1. IZ600F Dimensions (mm) -
Page 7: Speci Cations
4.4. Speci cations The following Figure illustrates the distances and resulting plate images men- tioned in the speci cations table. Table 2. Technical Specifications Item Speci cation... - Page 8 (EU style plates) (When installed at the recommended height and Camera to Road Edge distance) Vehicle Speed Range Up to 60 mph (0-97 km/h) IZ600F-IR: 4 Power Infrared LEDs Built-in Illuminator IZ600F-DR: 4 Power Deep Red LEDs Illumination Beam Angle 60°x60°...
- Page 9 Item Speci cation Day/Night Mode Day/Night/Auto Day/Night Switch IR Cut Filter with auto switch Image Sensor 1/2.8", 3.21M, Progressive Scan CMOS Sensor Model Sony IMX123 Rotate Mode, Saturation, Brightness, Contrast, Image Setting Sharpness Image Max. Resolution 2065 (H) × 1553 (V) (approximately 3.21 MP) Min.
- Page 10 Item Speci cation HTTP, RTP/RTSP(Uni/Multicast), TCP/IP(v4/v6), Supported Protocols UDP, FTP, Telnet, HTTPS, RARP, PPPoE, SNMP, PAP, CHAP, DHCP, NTP, SMTP client, uPnP Network Dynamic IP Dynamic DDNS Support IP ltering, HTTPS, Encrypted and Basic Security Authentication Ingress Protection IP67 Operating Environmental -4 °F to 140 °F (-20°C to 60 °C) Temperature...
- Page 11 Item Speci cation 12 VDC (male barrel connector required) or Power Supply PoE+ (802.3at) Power Color mode - 5 Watts Power Consumption B/W mode with LED on - 10-12 Watts Camera mount, 3x axes Accessories Included Sunshade, adjustable Junction Box POE Injector Network Switch Accessories Available...
-
Page 12: Connectors And Wiring Assignments (Pinout)
4.5. Connectors and Wiring Assignments (Pinout) Table 3. Connectors Connectors Power input (for 12 VDC) - fe- male barrel connector 5.5 mm outer diameter, 2.1 mm inner pin diameter RJ-45 network input connection Multi-wire cable (not used) Analog video output (BNC connector) -
Page 13: Required/Optional Accessories (Not Included)
Windows 10 or above - with .NET 4.5 enabled in "Windows Features" Chrome or Microsoft Edge browser A list of accessories that can be supplied by Inex can be found at the end of the Speci cations (see Section 4.4). -
Page 14: Optional Accessories
Mount illuminators at an appropriate distance away from their associ- ated camera(s), according to the objectives of your project. Contact Inex for guidance/training. Position the illuminator so you can aim it at the place where vehicles pass for recognition - while minimizing the glare into drivers' eyes. In most cases, however, white illuminators are mounted to be aimed at the rear of vehicles. -
Page 15: Using Roadview
8. Using RoadView RoadView is advanced ALPR software that reads license plates using sophisti- cated image recognition algorithms, and creates LPR Events. 8.1. Determining the IP Address of the RoadView Computer with IZ Discovery See the IZ Discovery User Guide (see Section 1). 8.2. -
Page 16: Maintenance
10. Notices 10.1. Inex Technologies End User Agreement Be sure to read the following document that explains important information about your agreement with Inex. Inex Technologies End User Agreement 10.2. Safety Precautions CAUTION WHEN INSTALLING THE UNIT IN YOUR SYSTEM, BEWARE OF RISK OF ELECTRICAL... -
Page 17: Regulatory Notices
Keep this guide for future reference. Do not disassemble the camera. Repair or replacement of parts for this camera should be supplied by Inex Technologies, and installed by quali ed service personnel. Handle and store the camera with care. Do not drop the camera or subject it to physical shock. - Page 18 FCC Conformance: This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful inter- ference, and (2) this device must accept any interference received, includ- ing interference that may cause undesired operation. EU Conformity Statement: This product and - if applicable, the supplied accessories - are marked with "CE"...
-
Page 19: Documentation Notices
10.4. Documentation Notices Inex Technologies reserves the right to improve and enhance its product offer- ings. Thus, the illustrations and descriptions presented in this manual may dif- fer in some respect from the products you receive. Technical speci cations are subject to change without notice.
