Summary of Contents for Alarm ADC-S40-W
- Page 1 Water Sensor Installation Guide ADC-S40-W...
- Page 2 In the box • ADC-S40-W Water Sensor • Installation guide • Mounting bracket • Screw (x2) • CR123 battery • Cable tie ❶ ❷ Water Sensor Mounting bracket ❶ ❷ Network LED Alert LED NOTE: The rope attachment and probe attachment are sold separately.
-
Page 3: Installation
Installation Installing the Water Sensor ❶ Place the bottom of the Water Sensor on the ground. • The Water Sensor will detect when water touches the metal pins at the same time on the top or bottom of the device. ❷... - Page 4 Optional - Installing the Water Sensor with rope attachment (sold separately) ❶ Connect the rope attachment to the Water Sensor. ❷ Remove the battery tab from the Water Sensor. ❸ Mount the Water Sensor to a wall or pipe near the desired monitoring area using the mounting bracket or cable tie provided.
- Page 5 Optional - Installing the Water Sensor with probe attachment (sold separately) ❶ Connect the probe attachment to the Water Sensor. ❷ Remove the battery tab from the Water Sensor. ❸ Mount the Water Sensor to a wall or pipe near the desired monitoring area using the mounting bracket or cable tie provided.
- Page 6 Connect to the network using Z-Wave SmartStart Connect to the network manually NOTE: An Alarm.com account is required for this process. TIP: For best results, we recommend having the Hub in Power on and add devices one at a time.
-
Page 7: Troubleshooting
Troubleshooting If the Water Sensor is not communicating Deleting the sensor from the network with the Hub TIP: For best results, we recommend having the Hub ❶ Press the button on the sensor. The network LED in the same room as the Water Sensor. should turn on and then turn off within a few seconds. - Page 8 Notices • Reorient or relocate the receiving antenna. • Increase the separation between the equipment and receiver. • Connect the equipment into an outlet on a circuit different from that This device complies with part 15 of the FCC rules. Operation is subject to to which the receiver is connected.
- Page 9 L’antenne(s) utilisée pour ce transmetteur doit etre installé pour fournir une distance de séparation d’au moins 20 cm de toutes les personnes et ne doit pas être co-localisés ou fonctionner en conjunction avec une autre antenne ou transmetteur. Questions? Visit answers.alarm.com or contact your service provider.
- Page 10 Notes...
- Page 11 8281 Greensboro Drive 210823 Suite 100 © 2021 Alarm.com. Tysons, VA 22102 All rights reserved.
