Summary of Contents for multiCLASS MCC16BAC
- Page 1 Trolleys for storage and recharging of IT equipment User manual Model: MCC16BAC / MCC16GAC User Manual v.1.3 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com...
-
Page 3: Table Of Contents
Supported (on the floor or on a cabinet) ..............5 With wheels ........................ 5 Stacking ........................7 Electrical System ......................8 Smart Ventilation System ....................9 Security lock ........................9 Details ........................... 10 Certifications ........................ 12 Page 1 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com... -
Page 4: Features
Features multiCLASS Cart is a trolley for the transport, safe storage and recharging of IT equipment. Measurements: 67,3 x 63,3 x 46cm Weight: 25 Kg. Equipment space (max.): 2,8 x 37 x 27 cm Max. capacity: 16 units Carry handles... -
Page 5: How To Use
Then place each charger and connect them to the power strip. Finally, let the connectors out of the front holes so that they hang down enough to be able to connect them to the devices. Page 3 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com... -
Page 6: Mounting Options
Wheels Stacking Wall hung In order to be able to hang the multiCLASS trolley, drill 4 holes according to the following diagram WARNING: Improper installation may result in serious personal injury and/or equipment damage. It is the installer's responsibility to ensure that the structural strength of the wall and wall plugs used is sufficient to support the weight of the trolley (25Kg) with all equipment inside. -
Page 7: Supported (On The Floor Or On A Cabinet)
The wheels are placed at the bottom of the trolley and can support 50Kg each. The two front wheels have brakes to block them and prevent unwanted movements. Wheel Assembly Page 5 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com... - Page 8 And leave the two wheels with brakes at the front. 5. Screw on the handle and fit the trims. 4. At the top of the trolley, remove the two protectors so that the handle can be fitted. Page 6 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com...
-
Page 9: Stacking
When stacking, you must also remove the drawer with the sockets from the bottom trolley in order to attach it to the top trolley with 3 screws. Page 7 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com... -
Page 10: Electrical System
Electrical System The multiCLASS Cart trolleys are equipped with overload and short-circuit protection, which protects the equipment by cutting off the power supply. To reactivate the power strips, follow the steps below: 1. Disconnect the trolley from the power supply. -
Page 11: Smart Ventilation System
The intelligent system turns the fan on and off depending on the internal temperature of the trolley. Security lock Three-point security lock. Optionally, it can also be locked with a padlock (not included) for added security. Page 9 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com... -
Page 12: Details
There are slots on both sides of the loading cabinet, making it possible to lift and transport with both hands. Warning: Heavy equipment! Move between 2 people to avoid muscle damage. Page 10 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com... - Page 13 • Keep away from moisture. Do not place any objects filled with liquids near the charging station. • Do not operate in extreme temperatures. For indoor use only. • Do not obstruct any ventilation openings. • Do not sit or stand on the station Page 11 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com...
-
Page 14: Certifications
Certifications multiCLASS as responsible for the product certifies that it has evidence that the product complies: • Council Directive 89/336/EEC • EN 55013 : 2001+A1 : 2003 • EN 61000-3-2/ -3 • EN 55020 : 2002+A.1 : 2003 + A2:2005 •... - Page 15 Page 13 multiCLASS – “The power of simplicity” www.multiclass.com Info@multiclass.com...
- Page 16 (+34) 876 664 905 Ctra. de Cogullada, 20 - Parque Tecnológico Cogullada, Nave 23B – 50014 – Zaragoza - SPAIN...
