  • Page 2 PREFACIO Gracias por elegir una bomba de agua Mpower, una herramienta que te ayudará en diferentes actividades como la jardinería, la agricultura, la construcción y más. Nuestra bomba de agua combina la mejor tecnología nacional y extranjera, y se destaca por su diseño moderno, su estructura compacta, su gran potencia, su fácil servicio, su bajo consumo de combustible y su poco ruido.

  • Page 3: Important Notices

    IMPORTANT NOTICES Please pay special attention to statements preceded by the following words: WARNING: A warning is used to alert the user to fact that hazardous operating and maintenance procedures may result in injury to or death of personnel if not strictly observed. CAUTION: A caution is used to alert the user to fact that hazardous operation and maintenance procedures may result in injury to or death of personnel if not strictly observed.

  • Page 4: Table Of Contents

    CONTENTS 1. Safety General Rules ........................2. Parts Description ........................... 3. Pre-Operate Preparation ..................................................4. Operation ............................5. Stopping Maintenance................................................7. Starting up in plateau regions 8. Transportation and Storage ......................9. Troubleshooting .......................... 10. Specifications ..........................

  • Page 5: Safety General Rules

    1. SAFETY GENERAL RULES Before operating, read the manual carefully and be sure to become familiar with it, otherwise personal injury of death as well as severe parts damage may occur. ● Before operating, perform the pre-operation inspection to make your operation on the water pump safer.
  • Page 6 WARNING ● Gasoline is extremely inflammable and explosive in certain conditions. ● Filling gasoline in a well-ventilated place with engine stalled. In gasoline filling and storage sites, be sure there are no smoking and fire resources such as flame, fire spark and so on. ●...

  • Page 7: Parts Description

    2. PARTS DESCRIPTION (Fig.1)

  • Page 8: Pre-Operate Preparation

    3. PRE-OPERATION PREPARATION 3.1 Connecting water inlet pipe Use commercially available hose, hose joint and clamp. The water inlet hose must be of continuous structure and be non-folded. The length of the hose should be as the same as or not more than that required.
  • Page 9 CAUTION ● Before pumping, install the filter securely to the end of the water inlet hose. The filter filtrates any impurity, which may produce passage jam to damage impellers. ● Be sure to install the hose joint and clamp well so as to prevent from air leaks and pumping performance drop;...
  • Page 10 Oil velocity varies with average temperature, so select engine oil with proper velocity in accordance with your region temperature. ▲ ENGINE OIL ALARM SYSTEM The engine oil alarm system is intended to avoid (Fig.3) engine damage due to too less engine oil in the crankcase. Before the engine oil level in the crankcase drops down below the safety line, the alarm system will tall the engine automatically (while the engine switch keeps at ON).
  • Page 11 CAUTION Runs with insufficient engine oil can damage the engine severely. 3.4 Check fuel level Remove the fuel tank cap and check the fuel level, If the fuel level is too low, refuel more. Only use specified gasoline in the manual (Recommend to use unleaded gasoline). Do not use the combination of engine oil and gasoline or filthy gasoline.
  • Page 12  When refueling, be careful not to spill gasoline. Spilled gasoline and gasoline vapor may ignite. If there is spilled gasoline, be sure to wipe it dry before starting the engine.  Avoid repeated or sustained breathing and touch with skin. ...
  • Page 13 3.6 Water capacity check in the pump Before operating the pump, make sure to fill the pump with enough water. CAUTION Do not try to run the engine without water inside, otherwise the pump will become overheated. Prolonged running of the pump without water will damage the pump gasket. If the water in the pump is used up, stall the engine at once and fill the pump once it cools down.

  • Page 14: Operation

    4. OPERATION 4.1 Before operation For your safety, and to maximize the service life of your equipment, it is very important to take a few moments before you operate the pump to check its condition. Be sure to take care of any problem you find, or have your servicing dealer correct it, before you operate the pump.
  • Page 15 4.1.2 Check the Suction and discharge Hoses Check the general condition of the hose. Be sure the hoses are in serviceable condition before connecting them to the pump. Remember that the suction hose must be reinforced construction to prevent hose collapse. Check that the sealing washer in the suction hose connector is in good condition.
  • Page 16 4.2.4 Move the throttle valve level away from the LOWER position, about 1/3 of the way toward the UPPER position. 4.2.5 Turn the engine switch to the ON position. 4.2.6 Pull the starter handle lightly until resistance is felt, then pull it briskly. Do not allow the starter handle to snap back against the engine.

  • Page 17: Stopping

    5. STOPPING To stop the engine in an emergency, simply turn the engine switch to the OFF position. Under normal conditions, use the following procedure. 5.1 Move the throttle valve lever to the LOWER position. 5.2 Turn the engine switch to the OFF position. 5.3 Turn the fuel cock to the OFF position.

  • Page 18: Maintenance

    6. MAINTENANCE To keep the water pump at optimal performance, check and adjustment on it periodically is necessary. Regular maintenance and service may extend its service life obviously. The Maintenance Schedule below specifies how often you should have your water pump served, and what things need attention.
  • Page 19 Maintenance Schedule Frequency Before First month First 3 month First 6 month First year Item each use or 20 Hrs. or 50 Hrs. or 100 Hrs. or 300 Hrs. ○ Oil level Engine oil ○ ○ Oil change ○ Check Clean cleaner ○⑴...
  • Page 20 WARNING Before maintenance and service, stall the engine. If maintaining when the engine runs, make sure to perform any check in a well-ventilated area. Exhaust emissions from the engine contains toxic carbon monoxide (CO), which may cause loss of consciousness and even life. 6.1 Engine Oil Replacement A warm-up engine can assure quick oil draining.
  • Page 21 NOTE Handing discarded engine oil in accordance with relative environmental protection rules. It’s better for you to take it in a sealed container and take to local recycling station. Do not pour at will. 6.2 Air Cleaner Maintenance A filthy air cleaner will decrease airflow quantity through the carburetor. To avoid troubles of the carburetor, clean the air cleaner regularly.
  • Page 22 6.3 Spark Plug Maintenance Recommended spark plug 50ZB20-2.9Q…………NHSP LD F6TC 50ZB26-4Q…………NHSP LD F6TC 80ZB30-4.8Q…………NHSP LD F6TC 100ZB26-5.8Q…………NHSP LD F7TC. To keep the engine in good condition, there must keep proper spark plug clearance and no accumulated carbon. 6.3.1 Dismantle the spark plug cap. WARNING When the engine is running, the exhaust muffler is very hot, be careful not to get burns.

  • Page 23: Starting Up In Plateau Regions

    NOTE Installing a new spark plug, after it touch and oppress the gasket, twist 1/2 more turns; as to a used one, twist 1/2～1/4 more turns. CAUTION Be sure to tighten the spark plug securely, otherwise it may become very hot and possibly damage the engine.

  • Page 24: Transportation And Storage

    CAUTION Use the water pump in regions with lower altitude than that the carburetor spray nozzle is applicable, the engine performance will decrease and become overheated, and over-thin combination of fuel and air produce may cause sever damage of the engine. 8.
  • Page 25 WARNING Gasoline is extremely inflammable and explosive in certain conditions. a.Turn the fuel cock to OFF position, drive off the fuel drain plug of the carburetor floater room, drain out the fuel in the carburetor. Hold drained gasoline in proper container. b.Turn the fuel cock to ON position.

  • Page 26: Troubleshooting

    9. TROUBLESHOOTING 9.1 Engine cannot start Check according to the following: 9.1 Check if there is enough fuel; 9.2 Check if the fuel cock is turned on; 9.3 Check if the fuel enters the carburetor; In the case that the fuel cock is turned on, check through dismantle the fuel drain plug at the bottom of the carburetor.
  • Page 27 d.Earth the side electrode by touching the engine, pull the kick-starter to check if there is spark. e.If no spark, please start the engine according to “Starting the Engine” in the manual. 7.If the engine still cannot start, contact your dealer for help. 9.2 Water pump cannot pump Check according to the following: 1.Check if there is enough water;...

  • Page 28: Specifications

    10. SPECIFICATIONS MODEL 50ZB20-2.9 50ZB26-4Q 80ZB30-4.8Q 100ZB26-5.8Q 100ZB26-7.5Q Model 160F 168F-2 168F-2 177F 188F Type 4-stroke OHV single cylinder with force air-cooled Displacement 118 cm 196cm 196cm 270cm 338cm Engine Bore×Stroke 60×42mm 68×45mm 68×54mm 77×58mm 88×64mm Power 2.9kW/3600r 4.0kW/3600rpm 4.8kW/3600rpm 5.8kW/3600rpm 7.5kW/3600rpm Ignition system...
  • Page 29 MODEL 100ZB20-5Q Model 170F Type 4-stroke OHV single cylinder with force air-cooled Displacement 212cm Engine Bore×Stroke 70x55mm Power 4.5kW/3600rpm Ignition system Non-contractor transistorized ignition（TCI） Inlet/Outlet dia. 100mm(4in) Rotation velocity 3600r/min Water Self-suction head Pump Pump lift Pump output 100m Duration of runs 2.0h Length 670mm...
