2BN009906-说明书-A1

印色：单黑

材质：80g书写纸

尺寸：100*140 mm

Guangdong Transtek Medical Electronics Co., Ltd.

Zone A, No.105, Dongli Road, Torch Development

District, 528437 Zhongshan, Guangdong, China

MDSS GmbH

EC REP

Schiffgraben 41, 30175 Hannover, Germany

User Manual

ARM BLOOD PRESSURE MONITOR

Model: TMB-2288-B

Thank you very much for selecting ICONIC_A ARM Blood Pressure Monitor

TMB-2288-B.

Please read the user manual carefully and thoroughtly so as to ensure the

safe usage of this product, keep the manual well for further reference in

case you have problems.

Version: A/1

Table of Contents

Need help?

Do you have a question about the TMB-2288-B and is the answer not in the manual?

Questions and answers

Summary of Contents for Iconic TMB-2288-B

Page 1 材质：80g书写纸尺寸：100*140 mm Version: A/1 User Manual ARM BLOOD PRESSURE MONITOR Model: TMB-2288-B Thank you very much for selecting ICONIC_A ARM Blood Pressure Monitor Guangdong Transtek Medical Electronics Co., Ltd. Zone A, No.105, Dongli Road, Torch Development TMB-2288-B. District, 528437 Zhongshan, Guangdong, China...
Page 2: Table Of Contents
CATALOGUE Table of Contents INTRODUCTION........................2 General Description Indications for Use Measurement Principle Receiving and Inspecting your Monitor Safety Information Display and Symbols Name of Each Part Contents/Product Includes BEFORE YOU START......................9 Choice of Power Supply Installing and Replacing the Batteries Setting the Date and Time Setting a user ID Pair a smart device with the monitor...
Page 3: Introduction
Thank you for selecting ICONIC_A arm type ARM blood pressure monitor The symbols below might be in the user manual, labeling or other (TMB-2288-B). The monitor features blood pressure measurement, pulse component. They are the requirement of standard and using.
Page 4 INTRODUCTION INTRODUCTION Precaution Warning * This device is intended for indoor, home use and is not intended for self-use in public areas. * Do not apply the cuff on an arm that has an intravenous drip or a blood transfusion attached. * This device is portable, but it is not intended for use during patient transport.
Page 5: Display And Symbols
INTRODUCTION INTRODUCTION Display and Symbols SYMBOL EXPLANATION Pulse display Pulse rate appears after the measurement. Warning Messages Refer to page 30 for more information. Blood Pressure Trends Appears when viewing the blood pressure trends of the specified period of the past 7 days under the memory mode.
Page 6: Name Of Each Part
, “ bAt Lo” & Contents/Product Includes then power off automatically after about 5 seconds. • ARM Blood Pressure Monitor (TMB-2288-B) • Cuff (Type BF applied part) Replace the batteries: Upper arm cuff:22-32cm or • When the low battery symbol appears.
Page 7: Setting The Date And Time
BEFORE YOU START BEFORE YOU START Setting the Date and Time 3. Press the “START/STOP” button to confirm the date format, then the It is important to set the date and time before using your ARM blood [Month] will flash. Repeat the same steps to set the [Month] and [Day]. pressure monitor for the first time, so that a correct time stamp can be assigned to each record that is stored in the memory.
Page 8: Setting A User Id
BEFORE YOU START BEFORE YOU START Setting a user ID 6. After confirming the [Minute], the LCD will display all the settings you have done, and then it will display “do nE” and the device There are 3 user ID available.
Page 9: Pair A Smart Device With The Monitor
2. Interference may occur in the vicinity of equipment marked with the following symbol And TMB-2288-B may interfere the vicinal electrical equipment. When the monitor is off, press and hold the “MEM” button to start 3. Keep the monitor at least 20 centimeters away from the human body (especially the pair-up, the bluetooth symbol will flash.
Page 10: Applying The Cuff
MEASUREMENT MEASUREMENT Applying the cuff Start a measurement Only use a cuff that has been approved by the manufacturer for this device model. Before use, please confirm if it fits your arm circumference. You can use your monitor without pairing to a smart device. To pair your Remove all jewelry, such as watches monitor with a smart device refer to the foregoing chapters.
Page 11: Measurement
MEASUREMENT MEASUREMENT Note 4. About the irregular pulse rate and excessive body motion during the Any time, to stop the measurement, press the “START/STOP” button. If you don’t pair with the device or don’t keep the app ON, the bluetooth measurement.
Page 12: Data Management
DATA MANAGEMENT DATA MANAGEMENT Recall the Records When the maximum average systolic pressure is higher than 170mmHg or the maximum average diastolic pressure is higher than 110mmHg, the 1. When the monitor is off, press the “MEM” button, the LCD will display symbol“...
Page 13: Delete The Records
DATA MANAGEMENT DATA MANAGEMENT Delete the Records B: Delete all records (Example shown below for User 1) Delete the records by following the steps below. 1. Enter the memory recall mode as described in the previous section A: Delete one record (Example shown below for User 1) "Recall the records".
Page 14: Data Management
DATA MANAGEMENT INFORMATION FOR USER Tips for Measurement 4. Once deleted, your readings cannot be restored. The LCD will display “---” like the following picture. Measurements may be inaccurate if taken in the following circumstances. Press the “START/STOP” button to turn off the monitor, otherwise it will power off automatically within 1 minute.
Page 15: Maintenance
ABOUT BLOOD PRESSURE INFORMATION FOR USER What are systolic pressure and diastolic pressure? Maintenance When ventricles contract and pump blood out of the heart, the blood In order to get the best performance, please follow the instructions pressure reaches its maximum value in the cycle, which is called systolic below.
Page 16: Why Do I Get A Different Blood Pressure At Home Compared To The Hospital
ABOUT BLOOD PRESSURE ABOUT BLOOD PRESSURE Why does my blood pressure fluctuate throughout the day? Blood Level Optimal Normal High-normal Mild Moderate Severe Pressure (mmHg) 1. Individual blood pressure varies multiple <120 120-129 130-139 140-159 160-179 ≥180 times everyday. It is also affected by the <80 80-84 85-89...
Page 17: Troubleshooting
TROUBLESHOOTING SPECIFICATIONS External dimensions Approx.178 mm × 101 mm × 42.89 mm If any abnormality arises during use, please check the following points: Digital LCD V.A.124 mm × 76 mm Display mode PROBLEM SYMPTOM CHECK THIS REMEDY Approx.343 g (Excluding the batteries and cuff) Weight Replace with new batteries.
Page 18: Authorized Component
Pressure: ±3 mmHg / 0.4 kPa Accuracy Pulse: ±5% Adapter Type: BLJ06L050100U-V The Basis Safety of the ARM Blood Pressure Monitor (TMB-2288-B) is as BLJ06L050100U-S following: BLJ06L050100U-B Deviation from normal operation that poses an unacceptable risk to the patient or Input: 100-240V, 50-60Hz, 0.2A max...
Page 19 EMC GUIDANCE EMC GUIDANCE Table 2 Technical description： Guidance and manufacturer’s declaration – electromagnetic Immunity 1. All necessary instructions for maintaining BASIC SAFETY and ESSENTIAL PERFORMANCE with regard to electromagnetic disturbances for the expected IEC 60601-1-2 Immunity Test Compliance level lifetime.
Page 20 EMC GUIDANCE Table 3 Guidance and manufacturer’s declaration - electromagnetic Immunity Compliance Radiated RF Test Band Service Modulation Distance Maximum 60601-1-2 level IEC61000-4-3 Frequency (MHz) Power Test Level (V/m) (MHz) (Test (V/m) specifications 380-390 Pulse TETRA modulation ENCLOSURE 18 Hz PORT IMMUNITY to 430-470...
