Ikon IK-WS28 User Manual

User Manual
2.01'' Full touch Smart Watch
Bluetooth Call /
Wireless chraging
Bluetooth Earbuds
OWS style, touch controls
Power bank
5000 mAh
Charging Cable
Type-C + Type-C
100cm / Fast Charging For
Power Bank & Earbuds
- Smart Watch -
Adapt to platform requirements:
Android 5.0 and above mobile phones
Support Bluetooth BT 3.0
IK-WS28 APP download method：
● IOS/Android phone users: scan the above QR code to download
and install the application.
● Android: Search for "HryFine" through the software application
store to download and install the application.
● Apple: Search for "HryFine" through the App store to download and
install the app.
● WeChat: Follow the official account "Deer Enjoy Planet", you can
get the download link to download on the official account.
Initial use
●
To ensure the normal use of the smart watch, please charge it first.
●
Before charging, make sure the charging pot is clean and dry.
● Using other companies 'chargers may result in slow charging and
Step 1: Place the charging contact of the smart watch onto the USB
charging dock (Concave side)
Step 2: Connect the USB end of the charging cable into an USB
Power source. When connected successfully, you will see the
charging indication on the watch screen.
1
Download applications:
Charging dock
Magnetic
Charging
contact
Download applications:
Charging time: It takes about 2.5 hours to fully charge your Smart
Watch. Remove the watch once it is fully charged.
● WARNNING：Do not place metal between the smart watch & the
charging pot ,including but not limited to metal brackets for magnetic
mounts , magnets ,phone grip rings, keys/key rings, coins &
paperclips.
Watch +APP +Smart Phone Pair
●
The watch and the smart phone must be connected via Bluetooth,
after the APP Hryfine downloaded into the phone , to guarantee all
● functions performance.
Pair between smartphone and watch via APP : After switch on
the Bluetooth setting menu on your smartphone , activate APP
Hryfine , it will remind you to enable the notification point to confirm.
Click to add a device, search for the device name "IK-WS28 "and
● click Connect to pair the watch device.
Connect BT3.0 Bluetooth for audio play: Enter the Bluetooth
terminal of the mobile phone and search for another Bluetooth point
"Hry3.0" in case you need audio broadcast via watch including call
● and music play.
How to verify that the Bluetooth connection is successful: The
Bluetooth icon in the the watch main menu indicates the Bluetooth
connection status. Also you can click "find the phone "or enter the
APP to " find the watch". If there is vibration on the watch or the
phone warns, it means both devices are connected successfully via
the APP.
Operation instructions for keys & screen：
● Rotary key (up):
1. Rotate to switch the watch faces
2. Rotate to switch the main menu items
3. Short press to enter the main menu
● Power / Off screen key ( down) :
1. Short press to make off -screen, or back to watch face.
2. Long press to power on/off.
Speaker
● Screen Touch Gestures:
1. Swipe left: to switch the watch faces.
2. Swipe right: to enter half screen home menu.
3. Swipe up: to enter message bar.
4. Swipe down: to enter shortcut setting menu
Main functions
Calling pad: Make a call on the watch side , in case audio Bluetooth
●
point Hry 3.0 is connected with the phone.
● Contact: After the contact from your smart phone successfully
added to the watch via APP , the phone book of the watch will be
IOS 9.0 and above mobile phones
displayed synchronously. Click the contact in the phone book on the
watch to make a call
● Call record: The call history of watch can be displayed, just click
the phone number to dial directly.
Notice: For any call making action, the audio Bluetooth point
Hry3.0 must be paired between the phone and watch.
● Messages: The content of the message push can be displayed,
such as: QQ, WeChat, etc. (The system above IOS12 will block
SMS reminders by default).
Notice : When the watch has an incoming call, there is no
notification reminder on QQ or WeChat, you need set the
phone settings-"notification settings",
corresponding and notification application
information notification.
●
Sports:
1. Enter the sports mode (running, walking, cycling, climbing)
selection. interface, click again to start the corresponding sport data
monitoring, such as exercise time, distance, calories burned and
heart rate data.
2. Record: record all exercise data
● Pedometer: Calculate your step count data for the day, it will
automatically clear the data at 00:00 in every morning, you can view
the historical steps record in the APP.
● Sleep monitoring: Turn on sleep detection to monitor the quality of
sleep.
● Sedentary reminder: Set the sedentary time, when the time is up,
the watch will vibrate, and there will be a prompt remind on the
interface too.
● Heart rate: Put the watch close to your wrist, the real-time heart rate
can be measured. Reference value is 60-100 beats/min.
● Blood pressure: Put the watch close to your wrist, the real-time
blood pressure can be measured. Reference value:
adult diastolic blood pressure: 60~80 (mmHg)
adult systolic blood pressure: 100~120 (mmHg).
● Blood oxygen monitoring: The watch is tightly attached to the
2
wrist, the real-time blood oxygen value can be measured.
Reference value is 95% to 100%.
NOTICE: For health monitor including heart rate / Blood
Pressure / Blood Oxygen , we strongly recommend to wear the
watch on the wrist bone and above the arm.
● BT camera: The camera app in the watch allows you to remotely
take photos through your phone's camera.
1. Open the Hryfine app in your phone.
2.Open the BT camera menu in the watch , tap the screen or shake
the watch to take photos from your phone remotely .You can view
the photos in your phone.
NOTICE: Please make sure the watch has been successfully
●
paired with your phone and Hryfine App , and keep your phone
in the Hryfine App Screen.
● Bluetooth music: Control the playback of music in the phone.
When the "Hry3.0" blue point is connected, the watch could also
play music via its built-in speaker.
● Find the phone: Long press the icon on the watch, the Bluetooth
connected mobile phone will ring.
● Weather: Display the weather conditions and temperature in the
current day.
Stopwatch: start stopwatch timing and end timing.
●
● Alarm bell: When set a custom alarm clock on the APP, the watch
will vibrate to remind you when time up.
● Style: You can set and change the UI style.
● About: Display the MAC serial code, Bluetooth name, and version
number of the watch.
● Brightness: can adjust the brightness of screen by swiping the +/-
bar.
● QR code: Scan the built in QR code to download associated APP
to your smartphone and bind the watch.
● Reset: Let your device reset and clear data, such as pedometer
record and messages, etc.
● Torch: Turn on the function, the screen of the watch will light up in
white for long time as a Torch.
● Calculator: easy to make calculation by the watch
● Siri: to enable Siri voice control in your phone.
● Password lock: four-digit password can be set to unlock the dial
● Time setting: Time can be set manually.
● Do Not Disturb mode: You can set the Do Not Disturb time period
in the APP, and you will not receive any message prompt, after it is
turned on
● Settings: make various settings for the watch , you can also swipe
the screen to enter setting short cut menu.
● Raise your hand to brighten the screen: When you wear the
watch, the screen will light up when you raise your wrist.
● Changing watch face on the smart watch : You can change by
below methods:
Rotary key
1.Turn the rotary key on the watch to navigate through the watch
MIC
Power / face pictures , select your desired picture the change as you like .
Off Screen key
2.Open the Hryfine App=>Dail menu, select your desired pictures
and install to change the watch face in the smart watch .
●
Language:
1.For watch: You can manually set from the language bar in the
watch, or u can set by Hryfine App – language setting.
Multi-language choices for you .
2.For APP : You must adjust as per your phone setting .
- Bluetooth Earbuds -
Basic Features
● Bluetooth Signal distance：≥10 meters (without any large obstacles
in an ideal environment)
● Battery specifications: headset 3.7V/35mA,charging
3.7V/200mA
● Music Play time: about3.5 hours
● Talk time: about 3.5hours
● Charging time: For the charging base about 1.5 hours, For the
headset about 1 hour
Key Operating instructions
1. Power on: take out the headset from the charging base, it will turn
on automatically.
2. Power off: put the headset into the charging base, it will power off
automatically.
to open the 3.Previous song: double-click the left headset
4. Next song: double-click the right headset
to receive
5. Volume plus: three strikes on the left headset
6. Volume reduction: three strikes in the right headset
7. Pause/Play: Click once the left headset or the right one.
8. When call comes in, answer/hang up: Click once the left or the right
headset to answer/hang up the phone
9. Reject the call: Long press the left or the right headset arbitrarily for
1 second.
10. Siri: Press the left or the right headset for 3 Seconds.
11.Bluetooth pairing: the main and auxiliary machines are
automatically paired after starting.
12. Bluetooth connection: Open the Bluetooth device (phone, tablet,
etc.), find the Bluetooth pairing name "IK-EBW24", and click to
connect. After successful connection, the light on the headset will
disappear.
ATTNTION:
1. When the charging base fully charged, please disconnect it from
the charging cable, to avoid damage caused by charging
compartment.
2. When plays music, please adjust the music to the appropriate
volume, in order to avoid noise harm to your ears.
3. Do not use this product in places with interference sources.
Otherwise, it may affect the Bluetooth signal.
4. Do not use this product in corrosive environment to avoid affection
to the functions.
- Power Bank -
Li-Polymer Battery: 3.7V, 5000mAh, 18.5Wh
USB-C Input: DC 5V 3A, 9V 2.2A, 12V 1.67A
USB-C Output: DC 5V 3A, 9V 2.2A, 12V 1.67A
Wireless Output: 15W Max.
USB-C Output + Wireless Output: 15W Max.
Max. Output: 20W
- Type-C Cable -
Type-C+Type-C / 100cm length / Fast charging
base
