Smoke and Heat Ventilation
Pneumatic - Electronic
Control Systems
Installation and Operation
Instructions
Version 3-1
SHEVS Control Centre
RWZ 5f-x.y-zz
K + G Tectronic GmbH • In der Krause 48
52249 Eschweiler • Deutschland / Germany
. +49 (0) 24 03 / 99 50 - 0 • ; +49 (0) 24 03 / 655 30
_ Info@kg-tectronic.de • # www.kg-tectronic.de
GRASL Pneumatic-Mechanik GmbH • Europastraße 1
3454 Reidling • Österreich / Austria
. +43 (0) 22 76 / 21 200 - 0 • ; +43 (0) 22 76 / 21 200 - 99
_ Office@graslrwa.at • # www.graslrwa.at
Advertisement
Table of Contents
Related Manuals for GRASL RWZ 5f 60 Series
Summary of Contents for GRASL RWZ 5f 60 Series
- Page 1 . +49 (0) 24 03 / 99 50 - 0 • ; +49 (0) 24 03 / 655 30 _ Info@kg-tectronic.de • # www.kg-tectronic.de GRASL Pneumatic-Mechanik GmbH • Europastraße 1 3454 Reidling • Österreich / Austria . +43 (0) 22 76 / 21 200 - 0 • ; +43 (0) 22 76 / 21 200 - 99...
-
Page 2: Table Of Contents
SHEVS Control Centre RWZ 5f-x.y-zz Contents Page Concept of Control Centre ..........................3 1.1 Options / Accessories ........................... 3 Technical Data ..............................4 2.1 Versions ................................ 4 2.2 Performance data and characteristics ......................4 ... -
Page 3: Concept Of Control Centre
● Internal service display for indicating the detailed status ● The use of K + G / Grasl actuators is recommended. When controlling 3rd party actuators, compatibility is to be checked. Also note section 2 „Technical Data“ for this ● Connectable actuators: 24 V actuators, travelling time for full stroke at rated load (total travelling time) <... -
Page 4: Technical Data
SHEVS Control Centre RWZ 5f-x.y-zz 2 Technical Data 2.1 Versions x = Number of SHE groups; y = Number of ventilation groups 24 V types RWZ 5f-x.y-60 RWZ 5f-x.y-80 Item number 8100 5660 20xy 8100 5680 20xy Total output current 60 A (24 V- / 1440 W) 80 A (24 V- / 1920 W) Current input... - Page 5 SHEVS Control Centre RWZ 5f-x.y-zz Actuator outputs 24 V types (RWZ 5f-x.y-zz) Rated voltage 24 V- (+6 V / -4 V) Operating mode / duty cycle S3 30 % Maximum cross-section of the supply line 4 x 10 mm² (rigid) Line monitoring (unbranched common line) wire-break, short-circuit Permissible current per output / permissible total current see sheet “Addendum to the Documentation”...
-
Page 6: Putting Into Service / Putting Out Of Service
SHEVS Control Centre RWZ 5f-x.y-zz 3 Putting into service / Putting out of service Work may be performed only by qualified personnel! Before starting any work, it is mandatory to deflect static charge! We do not assume any guarantee or liability for defects caused by faulty connection. i Planning and design of SHEVS require observation of the following rules, as far as applicable: National build- ing codes/model building code and regulations of local building and fire safety authorities, VDE regulations (particularly VDE 0100, 0108 and 0833), VdS Guidelines 2098 and 2221, DIN 18232, EN 12101, DIN 4102,... -
Page 7: Group Configuration And Selectable Functions On Master And Slave
SHEVS Control Centre RWZ 5f-x.y-zz − Button Test r: Switching to accumulator mode and running the alarm function of Master or Slave for maintenance purposes. PFC-r (PFC alarm) and buzzer S are not enabled. − Button µC-Reset: For service purposes only. 4.2 Group configuration and selectable functions on Master and Slave ●... -
Page 8: Alarm Functions
SHEVS Control Centre RWZ 5f-x.y-zz 4.4 Alarm functions During the execution of an alarm function the ventilation functions are disabled. i When configuring several SHE groups, the following description applies accordingly to each further group. ● Alarm function: Upon detecting an alarm, the actuators of the SHE group are fully extended. The indicator r lights up and manual call points with buzzer S emit a continuous tone. -
Page 9: Setting The Ventilation Time D
SHEVS Control Centre RWZ 5f-x.y-zz o Setting the travelling times for each ventilation group (Lx): i The setting of the button h for the ventilation group is shown on the sheet “Addendum to the Documentation”. − Briefly press the button h to enter programming mode for the respective ventilation group (display: ox) and then press the associated button D (display: Lx). -
Page 10: Maintenance
SHEVS Control Centre RWZ 5f-x.y-zz 5 Maintenance ● In the course of maintenance - unless other local regulations apply - check all the functions and displays of the device and the components at least once a year. This also includes checking the terminal points, connec- tion cables, indicators and fuses, and cleaning of various components, if necessary. -
Page 11: Service Display
SHEVS Control Centre RWZ 5f-x.y-zz 6.2 Service display ● Operating conditions can be accurately displayed on Master and Slave with the help of the service display. The display is switched off in normal condition. It can be switched on for 120 s by pressing the button Reset S for 4 s. - Page 12 SHEVS Control Centre RWZ 5f-x.y-zz System diagram (please consider local conditions / components) 1st SHE group / 1st ventilation group / 1st actuator output Example of connection on page A-2, detailed examples on the following pages. Run the supply line unbranched to under the roof.
- Page 13 SHEVS Control Centre RWZ 5f-x.y-zz Example of connection, Master Connection at slave is identical (except WRS and FACP which are not present there). Terminals X0.MS Connect resistor Rab to the last detector. Remove link when con- Mains Rend (2x10k) necting an external WRC. Rab (10k) Rab (10k) Rab (10k)
- Page 14 SHEVS Control Centre RWZ 5f-x.y-zz 24 V- Actuators, Master / Slave Run the supply line unbranched to under the roof (monitored common line). 1st actuator output X1.1 1st actuator Rend (2x10k) Connect resistors Rend to the last actuator. X1.2 2nd actuator 2nd actuator output The connection is made as shown for the 1st output,...
- Page 15 SHEVS Control Centre RWZ 5f-x.y-zz Automatic fire detectors, Fire Alarm Control Panel (FACP) 1st SHE group Automatic fire detectors RM 2 / TM 2 (terminals L1 in, L1 out and L2) or RM 3 / TM 3 (terminals 2, 3 and 5) Connect resistor Rab to the last detector.
- Page 16 SHEVS Control Centre RWZ 5f-x.y-zz Manual call point RT 4 1st SHE group Connect resistor Rab to the last detector. X4.1 (Master) Rab (10k) Rab (10k) Reset Line Reset Smoke Exhaust Smoke Exhaust Smoke Exhaust Smoke Exhaust Reset Reset Reset Reset RT 4-*-BS-AA RT 4-*-BS...
- Page 17 SHEVS Control Centre RWZ 5f-x.y-zz Ventilation button, external Wind and Rain Control 1st ventilation group X2.1 (Master) Å LT x-A LT x-A Further ventilation groups X2.x (Master / Slave) The connection is made as shown for the 1st group at terminals X1.x (setting Å...
- Page 18 SHEVS Control Centre RWZ 5f-x.y-zz Line voltage, Installation, Accumulators Installation: Terminals Line voltage: X0.MS 400 V~ / 50 - 60 Hz Accumulators: RWZ 5f-x.y-zz Insert the accumulators in the enclosure as illustrated and connect them. Logic board Logic board Terminals X0.MS Master Slave...
- Page 19 SHEVS Control Centre RWZ 5f-x.y-zz The mains voltage is connected to the terminals X0.MS (see A-8). Control centre overview The terminals X0.MS are connected ex works to the terminal X0 on master and slave. The power supply units are pre-wired ex works to the terminals Power supply 1 to 3 on master and slave.
- Page 20 Ventilation groups Actuator outputs Option WTM / PK-SA Option PK Option WRM SHE groups Logic board Main board DIP switch DIP switch for each SHE group DIP switch for each actuator output DIP switch Fuses Fault = Alarm Do not change the setting Alarm Close Do not change the setting Thermal alarm...
