Summary of Contents for Mega R01
- Page 1 OPERATING INSTRUCTION MEGA R01 Version: 01/2015 Version 07/2023 J:\MT\Anleitungen\650 KART\AB 2015\EN Bedienungsanleitung MEGA R01 RAIMUND +43 (0) 660 321 87 87 info@rs-motorentechnik.at ANDREAS Bahnhofplatz 3 SÖLLINGER 4631 Krenglbach, Austria...
- Page 2 Introduction We are pleased that you decided on a MEGA engine. The new MEGA engine is exclusively developed for kart application and it is only allowed to run those engines only on race tracks for kart usage. Warning: Before assembling and before starting the engine read the...
-
Page 3: Table Of Contents
Setting the gear ratio ................12 Changing the sprocket shaft ..............13 Starting the engine ................14 Clutch ....................15 MEGA Race clutch (part no. 650511802) ..........16 Deko-valve adjustment ................ 17 General operating information ............... 18 Turning off the engine ................18 First start of the engine ................ -
Page 4: Technical Data Mega R01
Operating Instruction MEGA R01 1. Technical data MEGA R01 General: 650 ccm liquid cooled single cylinder 2-stroke engine 48 kW / 65 hp at 6500 / minute – torque of 75 Nm at 5.750 /minute Bore 98,0 mm – stroke 86,0 mm ... - Page 5 Operating Instruction MEGA R01 Spark plug: Denso IW27 Battery: Banner YTZ10S 12V 190A 8,6 Ah maintenance free Weight: Engine: 26 kg Exhaust system: 7 kg Attach. parts: 1 kg Engine limits: Min. (on track) Max. (on track) Engine revolution 3.000 1/min...
-
Page 6: Fuel - Pre-Mix Ratio
Operating Instruction MEGA R01 2. Fuel – pre-mix ratio The pre-mix ratio: Ratio of 1 ltr 2-stroke oil : 40 ltr unleaded fuel Corresponding an oil-ratio of 2,5% The unleaded fuel must have a minimum octane rating of 98 ROZ. -
Page 7: Balancing Gear
Operating Instruction MEGA R01 4. Balancing gear 2 peaces of counter rotating balancing gears reduce engine vibrations. A check of oil level in the balancing gear box is not necessary. Replace oil, if it exits through the ventilation tube. Recommended oil: 0,05 ltr (50 ml) SAE 10W40 (engine oil) 5. -
Page 8: Carburetor
Operating Instruction MEGA R01 7. Carburetor Faulty carburetor diaphragm can cause lean operating conditions. The membrane and its associated seal must be replaced with new parts. The parts which have to be exchanged are situated between the nozzle chamber and nozzle chamber cover - see drawing. -
Page 9: Carburetor Jetting
Operating Instruction MEGA R01 8. Carburetor jetting This carburetor is executed as a membrane carburetor. The stock carburetor setting covers a wide range of air pressure and air temperature conditions. The carburetor setting has to be changed according to air pressure and air temperature. -
Page 10: Exhaust System
Operating Instruction MEGA R01 9. Exhaust system The exhaust systems consists of an exhaust manifold, spacer, pipe, muffler and has the correct setting for the engine. It is not allowed to make changes on the exhaust system – it can cause engine... -
Page 11: Battery - Charging
Operating Instruction MEGA R01 10. Battery - charging It should be noted that the battery should be charged at all times. For longer life, the battery should be charged in the meantime. The battery is only responsible for starting the engine. The charging coils of the ignition system are producing enough electrical power to run the engine. -
Page 12: Idle Speed
Operating Instruction MEGA R01 11. Idle speed By adjusting the idle screw on the carburetor the idle speed screw of the engine can be changed. To increase idle speed turn the idle screw clockwise. To reduce idle speed turn it counterclockwise. -
Page 13: Changing The Sprocket Shaft
Operating Instruction MEGA R01 Table of gear ratio 130,66 141,55 152,44 163,33 127,48 138,10 148,72 159,34 124,44 134,81 145,18 155,55 121,55 131,67 141,80 151,93 118,78 128,68 138,58 148,48 116,14 125,82 135,50 145,18 113,62 123,09 132,56 142,02 111,20 120,47 129,74 139,00... -
Page 14: Starting The Engine
Operating Instruction MEGA R01 14. Starting the engine Before starting the engine, following issues have to be checked: Fuel in fuel tank Correct choice of the carburetor jetting – see point 8 Battery fully charged and connected ... -
Page 15: Clutch
Operating Instruction MEGA R01 15. Clutch Please note the following points when operating or service: • Take care that the friction lining is not getting in contact with brake cleaner or similar solvent (no cleaning of the pads or the clutch with brake cleaner) because the pads are soft and the clutch starts to slip. -
Page 16: Mega Race Clutch (Part No. 650511802)
This clutch replaces the standard clutch shoes. The DLC-coated coupling bolts included, must be used. Available as MEGA Race Part or as an option on new engines instead of the standard coupling: Clutch shoes made out of high-quality steel ... -
Page 17: Deko-Valve Adjustment
Operating Instruction MEGA R01 17. Deko-valve adjustment If the deco-valve in actuated adjustment does not remain in his position, it can be adjusted: Loosen the lock nut Adjust adjusting screw with a screwdriver (clockwise: deko-valve is tight; counterclockwise: deko-valve is easier in the initial position) ... -
Page 18: General Operating Information
Operating Instruction MEGA R01 18. General operating information When operating the kart always suitable protective clothing has to be worn (helmet, overalls, gloves, shoes, neck and rib protection, etc.). Do not touch the engine, radiator and exhaust system during and after driving -... -
Page 19: Driving During Rain
Operating Instruction MEGA R01 21. Driving during rain Do not expose the air filter directly rainwater / splashing water (air filter cover). After driving operation warm up the engine (about 3 min. with new or dry air filter) to liberate the crankcase from water. -
Page 20: Cleaning The Engine
Operating Instruction MEGA R01 Every 20 hours racing operation and 30 hours normal operation: Engine revision Change of following components: - piston, piston pin, piston pin bearing, con rod, con rod bearing - big end bearing and oil seals of the crank shaft... -
Page 21: Trouble Shooting
Operating Instruction MEGA R01 26. Trouble shooting Electric starter does not move when pushing the start button Check all connections of engine harness Check battery for correct connection and charge condition Check starter ring gear for damage Electric starter turns without engaging ... -
Page 22: Notes
Operating Instruction MEGA R01 27. Notes Version 01.2015 page 22 / 22...
