Summary of Contents for Tytus TDT-GHS-GPZA

  • Page 1: Table Of Contents

    USER MANUAL Gas Pizza Oven Model: TDT-GHS-GPZA CONTENTS Safety Warnings Installing Batteries Package Contents Assembling Your Pizza Oven Using Your Pizza Oven Converting Your Pizza Oven to Natural Gas Use & Care Instructions Frequently Asked Questions Specifications Parts Diagram & List...
  • Page 2: Safety Warnings

    SAFETY WARNINGS IMPORTANT NOTE: Keep this manual with your TYTUS Gas Pizza Oven for future reference. RECORD YOUR SERIAL #: [Serial # located on the bottom of the pizza oven leg.] WARNINGS This instruction manual contains important information necessary for the proper assembly and safe use of the appliance.
  • Page 3 WARNINGS The outdoor cooking gas appliance must be Before each use of your pizza oven, inspect isolated from the gas supply piping system the stone and turntable, flame tamers and by closing its individual manual shut-off the inside of the pizza oven to be sure there valve during any pressure testing of the gas is no excessive grease and debris buildup.
  • Page 4 SAFETY WARNINGS CAUTION Failure to comply with these instructions may result in a hazardous situation which may result in injury. Spiders and small insects can spin webs and nest in the grill burner tubes during transit and warehousing which can lead to a gas flow obstruction, resulting in a fire in and around the burner tubes.
  • Page 5 Allow the pizza oven to cool before moving or storing. TYTUS. Contact TYTUS Customer Support at (855) 969-5185 for more information. DO NOT use your pizza oven as a heater. NEVER light your gas pizza oven with the...
  • Page 6 SAFETY WARNINGS WARNING A. DO NOT store a spare propane gas tank under or near this appliance. B. NEVER fill the tank beyond 80 percent full. C. If the information in “(A)” and “(B)” are not followed exactly, a fire causing death or serious injury may occur.
  • Page 7: Installing Batteries

    INSTALLING BATTERIES INSTALLING (4) AA BATTERIES With the lid latched and secure, place the pizza oven on a flat surface, such as the ground, covered by a blanket to avoid damaging your pizza oven. Remove your pizza stone from your pizza oven. Gently tilt the pizza oven backwards onto its lid.
  • Page 8 INSTALLING BATTERIES Close the battery pack and gently set the pizza oven back on its feet. To check the operation, turn on the rotation feature using the rocker switch on the right side of the control knob. NOTE: Batteries are not included. GAS PIZZA OVEN USER MANUAL...
  • Page 9: Package Contents

    PACKAGE CONTENTS Remove your pizza oven from the packaging, and lay out the contents in a large, sturdy area. Make sure that your pizza oven is not damaged and that you have all parts. Pizza Oven Regulator (855) 969-5185 | TYTUSGRILLS.COM...
  • Page 10: Assembling Your Pizza Oven

    ASSEMBLING YOUR PIZZA OVEN BEFORE ASSEMBLING YOUR PIZZA OVEN Make sure that you have assistance from another person to handle the grill box and other large, heavy parts. Use the “Package Contents” on page 8 and “Parts Diagram & Lists” on page 27 to ensure all items are included and free of damage.
  • Page 11 STEP 2 Lift the lid and place the stone onto the turntable. STEP 3 Gas Connections: A. If you are using the pizza oven on its own, place it on a fire safe, level platform and connect your brass quick connect to the propane gas regulator and connect to a standard 20 lb. propane tank.
  • Page 12: Using Your Pizza Oven

    USING YOUR PIZZA OVEN Before lighting or using your pizza oven, familiarize yourself with the safety guidelines at the front of this manual. See “Safety Warnings” on page 1. WARNING: Do not smoke while lighting the pizza oven or checking gas supply connections. LIGHTING YOUR PIZZA OVEN NOTE: If your pizza oven does not light properly, see "What Should I Do if My Pizza Oven Won't Light"...
  • Page 13 MANUALLY LIGHTING WITH A MATCH Insert a match into the manual lighting stick (included in the bag with this User Manual). Make sure that your propane gas tank is filled. Make sure that the end of each burner tube is properly located over each valve orifice. 4.
  • Page 14 USING YOUR PIZZA OVEN COOKING WITH YOUR PIZZA OVEN Before First Use Before cooking on your pizza oven for the first time: Clean the burner tubes to reduce the chance of flashback fire. Use a stainless-steel cleaner and a soft cloth to remove residual adhesives and oils from the inside and outside of your pizza oven lid.
  • Page 15 If you have a gas leak that you cannot repair, turn off the gas at the source, disconnect the fuel line from your pizza oven, and call the TYTUS Customer Support at (855) 969-5185, or your gas supplier for repair assistance.
  • Page 16: Using The Rotation Feature

    USING YOUR PIZZA OVEN PURGING AIR FROM THE GAS LINE/RESETTING THE REGULATOR Turn the control knob OFF. Turn off the gas at the tank valve. Disconnect the regulator from propane tank. 4. Let the gas line and regulator stand for five minutes to allow air to purge. Reconnect the regulator to the propane tank.
  • Page 17: Converting Your Pizza Oven To Natural Gas

    CONVERTING YOUR PIZZA OVEN TO NATURAL GAS Using your TYTUS Natural Gas Conversion Kit (sold separately and available at TYTUSGrills.com), you can convert your pizza oven to use a natural gas line. Ensure the pizza oven is cool and disconnected from the current gas source.
  • Page 18 CONVERTING YOUR PIZZA OVEN TO NATURAL GAS Remove the latch and then remove the nozzle. Using your 6 mm hex nut driver, remove the LP orifice from your pizza oven. Make sure you do not remove the natural gas orifice. NG Orifice LP Orifice GAS PIZZA OVEN USER MANUAL...
  • Page 19 10. Reinstall the nozzle and the latch. 11. Place the cover panel back in place. 12. Using a Phillips head screwdriver, install the 10 screws into the cover panel. (855) 969-5185 | TYTUSGRILLS.COM...
  • Page 20 CONVERTING YOUR PIZZA OVEN TO NATURAL GAS 13. Using a pair of pliers or a wrench, carefully remove the gas line from the bottom of your pizza oven. 14. Connect your natural gas regulator hose to the manifold tube of your pizza oven. 15.
  • Page 21 17. Remove your control knob from your pizza oven and adjust your gas flow valve by two counterclockwise turns, using the provided flathead screwdriver. Turn counterclockwise twice. 18. Place your control knob back on your pizza oven. 19. Connect the 10 ft. Natural gas hose to the source of your natural gas. (855) 969-5185 | TYTUSGRILLS.COM...
  • Page 22: Testing For Leaks

    CONVERTING YOUR PIZZA OVEN TO NATURAL GAS TESTING FOR LEAKS WARNING: Do not smoke, use a lighter, or have any open flame when testing for gas leaks. Turn off your gas supply and turn the control knob to OFF. Check all hoses for cracks, tears, or other signs of wear. Make sure that there are no kinks or bends in the hoses and all hoses are securely connected.
  • Page 23: Use & Care Instructions

    USE & CARE INSTRUCTIONS EXTERIOR POWDER COATED SURFACES Wipe your pizza oven down after each use. Use warm soapy water to cut the grease. Do not use oven cleaner, abrasive cleansers or abrasive cleaning pads on powder coated surfaces. LIFTING THE DOME FOR EASY CLEANING Unclip the two safety latches and lift the pizza oven lid.
  • Page 24: Frequently Asked Questions

    Reinstall all orifices, burners, screws, and cooking components. If you suspect an obstruction in the gas valves or manifold, call the TYTUS Customer Support at (855) 969-5185.
  • Page 25 Open the gas supply for one second to clear any obstruction from the fuel line. Close off the gas supply at its source and reconnect fuel line to the pizza oven. If an obstruction is suspected in the orifice or gas valves, call the TYTUS Support Center. WARNING: Do not smoke while clearing the gas line.
  • Page 26 When storing your pizza oven inside, do not cover your pizza oven with any type of cover as moisture will be trapped under the cover, causing premature rusting. Visit TYTUSGrills.com to purchase a fitted TYTUS Series Cover. GAS PIZZA OVEN USER MANUAL...
  • Page 27: Specifications

    SPECIFICATIONS DIMENSIONS SPECS Assembled Width 26.7 inches No. Main Burners Assembled Depth 22.6 inches Ignition Type Piezo Assembled Height Fuel Type LP + NG Convertible 15.7 inches (Lid Closed) Max Temp 900° F Main Cooking Area 153.94 sq. inches 14” pizza stone Main Burner BTUs 18,000 Total Cooking Area...
  • Page 28: Parts Diagram & List

    PARTS DIAGRAM & LIST PARTS DIAGRAM GAS PIZZA OVEN USER MANUAL...
  • Page 29: Parts List

    PARTS LIST Part # Description TYTUS Part # Part # Description TYTUS Part # DJ-21002-01 DJ-21002-19 Control panel Lid hinge DJ-11606-DNA-11 DJ-21002-20 Valve Lid stopper DJ-21002-03 TFR-BNB-080 Knob base Rotation plate Knob TFR-BNB-081 DJ-21002-04 stopper Leg base DJ-11606-DNA-17 Ceramic wool...
  • Page 30: Warranty

    (the “Products” or “Product” when referencing a singular product herein). Tytus Grills, LLC (“Tytus”) warrants the Products identified above to be free from defects in material and workmanship, for the relevant and specified Warranty Periods set forth below for specific parts or components of the Products, under proper use, maintenance, and care according to the owner’s manual, warnings, and instructions accompanying the Products:...
  • Page 31 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of Tytus. The addition of equipment or features to the Product that are not manufactured or recommended by Tytus could affect the intended function of the Product, and therefore may void the Warranty.
  • Page 32 TYTUS and TYTUS Grills are trademarks of TYTUS Grills, LLC. © 2024 TYTUS Grills, LLC. Designed in the USA. Made in China. Distributed by TYTUS Grills, LLC, 7151 Metro Blvd, Edina, MN 55439...
