Summary of Contents for Ethereal Helios FMM44
- Page 1 FMM44 ASSEMBLY INSTRUCTIONS Please read this instruction carefully before assembly. This model will hold 26-60in plasma and LCD TV. Weight Capacity :66LBS (30KG).
-
Page 2: Part List
CAUTION : SAFETY WARNING: Never let children climb on product or play with product. Do not sit or stand on product. Do not fasten a TV that is heavier than the recommended load rating to the mount. Using suitable concrete wall or wood stud wall. Improper installation may cause property damage and/or personal injury,so the installation must be done by two qualified contractors. - Page 3 ： Remove the bolts ① with Allen key Step 1 to separate wall plate unit (A) into two pieces.(Figure 1) Wall plate A1 Wall plate unit ① Figure 1 TV plate A2 ： Step 2 Pls remove the plaster board on the surface of concrete wall when assembling mount on the concrete wall.
- Page 4 ： Step 3 Plastic Cover (D) inserts into wall plate (A1). (Figure 4) Figure 4 ： Step 4 Per the hole pattern on the back panel of TV, Choose the suitable unit. 1. VESA within 200x200 connect TV plate(A2) to the TV directly. 2.
- Page 5 ： Step 5 Attach TV plate (A2) to the back of TV, choose corresponding bolt,washer and spacer to fix the holes of TV rear. If the back of TV is not flat, or the bolts used to assemble TV are too long, or there is interfere between TV bracket and cable inlets, we highly recommend you to use spacers.
- Page 6 ： Step 6 Hang pre-assembled TV unit on the wall plate and fix them by bolts ① . (Figure 8) CAUTION : This step must require 2 or more professional to finish. ① Figure 8 Forbidden Attention Figure 9 Figure 10 ⑤...
- Page 7 3. Place left TV mount and right mount in the appropriate position, making sure CENTERED on the back of the TV and LEVEL with on another. 4.This product only install on the perpendicular wall,not install on the ceiling. 2023 Ethereal © 460 Walker Street,Holly Hill,FL 32117-2653 Specifications are subject to change without notice.
