Summary of Contents for Canvas REVEL 188-1309-6
- Page 1 REVEL ROLLING COOLER CART PRODUCT NO. 188-1309-6 ASSEMBLY INSTRUCTIONS HAVING TROUBLE? TOLL-FREE: 1-888-670-6684 IMPORTANT: Please read this manual carefully before beginning assembly of this product. Keep this manual for future reference. Production Number: XXXXXXXX...
- Page 2 REDISCOVER YOUR SPACE To the trend seekers and design mavens, CANVAS™ is the furniture and décor brand that helps you imagine and create a space you can be proud of. That’s because CANVAS™ ease with products that are made for real life and Canadian inspired.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Important Safety Instructions Parts List Before You Begin Assembly Step-by-step Guide Technical Data Troubleshooting Caring for Your Item Limited Warranty IMPORTANT SAFETY INSTRUCTIONS WARNING: To reduce the risk of serious injury, read the following safety instructions before assembly and use of the dining set. Some parts may contain sharp edges. -
Page 4: Parts List
PARTS LIST Handle P005100101 P00310012902 (Pre-assembled on C) P00320001803 Cooler Body Drain Plug P005100102 (Pre-assembled on C ) P007100004 Bottle Opener Bucket P00720001202 Leg 1 P00540066702 Leg 2 P00540066802 Shelf P00230011002 Caster P003300027 P003300028 Locking Caster REVEL ROLLING COOLER CART... -
Page 5: Hardware List
HARDWARE LIST H100010104 M4*28 Bolt H010040302 M6*12 Bolt M6*12 Bolt H010110056 (Pre-assembled on C) M6 Washer H050080001 M8 Hex Key H090030005 H090010020 Wrench M12 REVEL ROLLING COOLER CART... -
Page 6: Before You Begin Assembly
BEFORE YOU BEGIN ASSEMBLY MAKE SURE ALL PARTS ARE PRESENT ASSEMBLE IN A CLEARED AREA REMOVE PACKAGING MATERIALS READ EACH STEP CAREFULLY 1-888-670-6684 REVEL ROLLING COOLER CART... -
Page 7: Step-By-Step Guide
STEP 1 NOTE: To preserve the finish, place parts on a soft surface. REVEL ROLLING COOLER CART... - Page 8 STEP 2 NOTE: To preserve the finish, place parts on a soft surface. REVEL ROLLING COOLER CART...
- Page 9 STEP 3 NOTE: 1. To preserve the finish, place parts on a soft surface. 2. The casters should be tightened using a wrench. REVEL ROLLING COOLER CART...
- Page 10 STEP 4 NOTE: It is recommended to use the cross-head screwdriver to tighten the bolts. REVEL ROLLING COOLER CART...
- Page 11 STEP 5 NOTE: It is recommended to use the cross-head screwdriver to loosely/fully tighten the bolts. NOTE: Do not overtighten the screws in order to properly slide the bucket into place. REVEL ROLLING COOLER CART...
-
Page 12: Technical Data
TECHNICAL DATA 78.5 cm 39.5 cm (30 15/16”) (15 1/2”) 86.5 cm (34”) SPECIFICATIONS SSEMBLED DIMENSIONS (W x D x H) 78.5 x 39.5 x 86.5 cm 30 15/16 x 15 1/2 x 34” MAXIMUM WEIGHT CAPACITY 50 kg 110 lb ASSEMBLED PRODUCT WEIGHT 15.3 kg 33.7 lb... -
Page 13: Troubleshooting
TROUBLESHOOTING HAVING TROUBLE? LET US HELP YOU! TOLL-FREE: 1-888-670-6684 BEFORE RETURNING CALL US, YOUR PRODUCT WE CAN HELP If you have questions regarding your product or require warranty assistance, please call our customer service helpline. CARING FOR YOUR ITEM Before using, clean the cooler completely with a soft dry towel. Do not use harsh abrasives or cleaners. -
Page 14: Limited Warranty
LIMITED WARRANTY This CANVAS™ product carries a one (1) year warranty against defects in workmanship and materials. Trileaf Distribution agrees to replace the defective product free of charge within the stated warranty period, when returned by the original purchaser with proof of purchase. This product is not guaranteed against wear or breakage due to misuse and/or abuse. - Page 15 REDISCOVER YOUR SPACE...
