RSS IP Lite MW7
IP 7" Colour TFT Monitor
Installer Manual
Please read this manual carefully before using the product, and keep it for future reference.
We reserve the right to modify the specifica on of the product in this manual at any me without
no ce.
*This informa on is specific to the IP-MW7, please refer to the IP-M7 manuals for general installa on
informa on*
Advertisement
Summary of Contents for RSS IP Lite MW7
- Page 1 RSS IP Lite MW7 02/12/22 RSS IP Lite MW7 IP 7” Colour TFT Monitor Installer Manual Please read this manual carefully before using the product, and keep it for future reference. We reserve the right to modify the specifica on of the product in this manual at any me without no ce.
- Page 2 Contents This guide provides addi onal informa on on the IP-MW7 Monitor. Refer to the IP-M7 guide for installa on and installa on informa on. Parts and Func ons Home Screen Status Bar Icons Please refer to the IP-M7 Installer and User manuals for further informa on. Important Informa on By default the monitor has two func ons ‘Enabled’...
- Page 3 1. Parts and Func ons LCD Display Microphone Status Indicator Talk/Monitor Bu on Unlock Bu on Back Illuminated Back Illuminated The Status Indicator colour iden fies different modes Green—Monitor in standby mode Red—Do Not Disturb Red Flashing—Missed Call Blue—Incoming Call...
- Page 4 2 Home Screen IP-MW7 Intercom Icon—Enables intercommunica on with other monitors (if enabled by the Installer) Call Record Icon—Allows you to view previous and missed calls. Monitor Icon—Allows you to monitor the Entrance Panel(s) (if enabled by the Installer) Favourites Bar—Up to 4 favourites/shortcuts can be added here. Call Scene Icon—Allows the call mode to be set (includes ‘Do Not Disturb’) Status Bar—Displays icons showing the monitor status Se ngs Icon—Provides access to User se ngs, Manager se ngs and Installer...
-
Page 5: Status Bar Icons
3. Status Bar Icons Icon Description Indicates 1 or more missed calls. Tap to review the missed call. Missed call Indicates the device is in “Do Not Disturb” mode. Do Not Disturb Divert call Indicates the device is in “Divert call” mode. Device online Indicates the device is online, but not connected to the internet.
