  • Page 1 Saunders Bookshelf Assembly Guide...
  • Page 2 Welcome to the Feather & Black community. Since 2004, we’ve been passionately helping our customers create beautiful bedrooms with an exceptional level of quality and expertise. We know your home is a truly special place, so it’s a responsibility we don’t take lightly.
  • Page 3 Saunders Bookshelf - Assembly Instructions Product size: 800mm x 350mm x 1950mm If you require any advice during assembly, please call our customer service team on 01243 380600 Please retain these assembly instructions for future use Produced in Vietnam for Feather & Black...
  • Page 4: Before You Start

    Saunders Bookshelf Before you start Number of people required to assemble Thank you for purchasing this Saunders Bookshelf. Two people to assemble the product and two people to lift in to position. Please read these instructions fully prior to assembly to familiarise yourself with the various stages of construction.
  • Page 5 Saunders Bookshelf Components supplied (not actual size) D: Middle Shelf B: Right Side Leg Frame C: Top Shelf A: Left Side Leg Frame Quantity: 1 pc Quantity: 1 pc Quantity: 1 pc Quantity: 1 pc Box: 2 Box: 2 Box: 1...
  • Page 6 Saunders Bookshelf 1. Layout all parts in assembly postion on the floor. 2. Insert Wooden Dowels (G) into holes on inner sides of Left and Right Side Leg Frames (A) and (B). Produced in Vietnam for Feather & Black www.featherandblack.com...
  • Page 7 Saunders Bookshelf 3. Remove the drawer by pulling it gently towards you whilst pressing the release catches as shown in the diagram. Produced in Vietnam for Feather & Black www.featherandblack.com...
  • Page 8 Saunders Bookshelf 4. Starting with the Right Side Leg Frame (B) attach all Shelves (C), (D) and (E), and the Drawer Unit (F). Tighten all Bolts with Allen Key (M). IMPORTANT: To avoid the risk of damage to product you must use the gold coloured bolts, nuts and spring washers for this part.
  • Page 9 Saunders Bookshelf 6. Using 2 people lift the assembled unit onto its feet. 7. Screw the 2 X Fabric Anti-Tip Straps (N) to the back of the assembled unit into the pre-drilled holes using the screws provided. Attach the other side of the Anti-Tip Straps to the Wall.
  • Page 10 Saunders Bookshelf 8. Insert the drawer by aligning the rails and guides as shown in the diagram and pushing the drawer gently closed. Produced in Vietnam for Feather & Black www.featherandblack.com...
  • Page 11 featherandblack.com...
