Tytus TDT-KC2-0101 User Manual

Anaheim charcoal kettle with cart
Hide thumbs

Advertisement

Table of Contents

USER MANUAL
Anaheim Charcoal Kettle
with Cart
Model: TDT-KC2-0101
CONTENTS
1
3
4
Assembling Your Charcoal Grill
9
9
10
11
13

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TDT-KC2-0101 and is the answer not in the manual?

Questions and answers

Summary of Contents for Tytus TDT-KC2-0101

  • Page 1: Table Of Contents

    USER MANUAL Anaheim Charcoal Kettle with Cart Model: TDT-KC2-0101 CONTENTS Safety Warnings Package Contents Assembling Your Charcoal Grill Cleaning & Maintaining your Charcoal Grill Using Your Charcoal Grill Specifications Parts Diagram & List Warranty...

  • Page 2: Safety Warnings

    SAFETY WARNINGS IMPORTANT NOTE: Keep this manual with your charcoal kettle grill for future reference. RECORD YOUR SERIAL #: (Serial number can be found on the silver sticker on the center shelf.) CARBON MONOXIDE HAZARD CARBON MONOXIDE HAZARD - Burning charcoal inside can kill you. It gives off carbon monoxide, which has no odor.
  • Page 3 WARNING: Risk of burning! When petrol or white spirits are ignited, uncontrollable heat can develop as a result of deflagration. You should therefore only use harmless fuel. WARNING: Always use caution when handling hot coals to prevent injury. WARNING: Always light the fire with the grill lid open. WARNING Use grill at least 3ft.

  • Page 4: Package Contents

    PACKAGE CONTENTS Charcoal Kettle Lid Temperature Probes Main Grill Grates Charcoal Grate Magnetic Temperature Kettle Body Table Probe Holders Front Panel Center Panel Ash Catch Paper Towel Holder Cart Collapsible Trash Bin Bottle Cap Catch Includes: • Protective Cover (Boxed) •...
  • Page 5 ASSEMBLING YOUR CHARCOAL KETTLE STEP 1 Unfold the cart by rotating the cart bars to be perpendicular with the bottom frame. STEP 2 Place the middle shelf into position by aligning the cutouts over the screws and push them into place. (855) 969-5185 | TYTUSGRILLS.COM...
  • Page 6 ASSEMBLING YOUR CHARCOAL KETTLE STEP 3 Place the front panel onto the cart frame by aligning the bolts with the grooves and pressing down into place. STEP 4 Place the top table with the charcoal kettle body onto the cart frame, with the kettle on the left side (the same side as the tool hooks).
  • Page 7 STEP 5 Place the charcoal grate and the two cooking grates into the charcoal kettle. STEP 6 Place the bottle cap catch onto the charcoal kettle front panel and install the two temperature probes into the temperature probe module. (855) 969-5185 | TYTUSGRILLS.COM...
  • Page 8 ASSEMBLING YOUR CHARCOAL KETTLE STEP 7 Place the charcoal kettle lid onto the charcoal kettle body. STEP 8 Place the ash catch under the charcoal kettle body, aligning the notches with the grooves. ANAHEIM CHARCOAL KETTLE WITH CART USER MANUAL...
  • Page 9 STEP 9 Place the collapsible trash bin onto the bolts on the right side of the charcoal kettle cart. STEP 10 Place the charcoal kettle lid on the left side of the cart by placing the hook inside the charcoal lid onto the silver side handle for ease of use.

  • Page 10: Cleaning & Maintaining Your Charcoal Grill

    CLEANING & MAINTAINING YOUR CHARCOAL GRILL EXTERIOR POWDER COATED SURFACES Wipe your grill down after each use. Use warm soapy water to cut the grease. Do not use oven cleaner, abrasive cleansers or abrasive pads on powder coasted surfaces. COOKING GRATES Wipe your cooking grates with a clean cloth and apply a thin coating of cooking oil.

  • Page 11: Specifications

    SPECIFICATIONS SPECS DIMENSIONS Fuel Type Charcoal Assembled Width 46.73 inches Tool Hooks Assembled Depth 25.63 inches Assembled Height Warranty 3 year limited 47.56 inches (Lid Closed) Main Cooking Area 342 sq. inches (W & D) (20.87” diameter) MATERIALS 317.2 sq. inches Prep Area (W &...

  • Page 12: Parts Diagram & List

    PARTS PARTS DIAGRAM ANAHEIM CHARCOAL KETTLE WITH CART USER MANUAL...
  • Page 13 PARTS LIST Part # Description TYTUS Part # Part # Description TYTUS Part # Lid Handle TFR-CHR-001 Leg Base RR TFR-CHR-021 Lid Air Vent TFR-CHR-002 TFR-CHR-022 Leg Base RF TFR-CHR-003 Right Leg TFR-CHR-023 Thermometer TFR-CHR-004 Paper Towel TFR-CHR-024 Holder Gasket...

  • Page 14: Warranty

    (the “Products” or “Product” when referencing a singular product herein). Tytus Grills, LLC (“Tytus”) warrants the Products identified above to be free from defects in material and workmanship, for the relevant and specified Warranty Periods set forth below for specific parts or components of the Products, under proper use, maintenance, and care according to the owner’s manual, warnings, and instructions accompanying the Products:...
  • Page 15 United States and Canada, and only applies to products purchased and serviced in the United States and Canada. All replaced parts and Products, and Products on which a refund is made, become the property of Tytus. The addition of equipment or features to the Product that are not manufactured or recommended by Tytus could affect the intended function of the Product, and therefore may void the Warranty.
  • Page 16 TYTUS and TYTUS Grills are trademarks of TYTUS Grills, LLC. © 2024 TYTUS Grills, LLC. Designed in the USA. Made in China. Distributed by TYTUS Grills, LLC, Edina, MN.
