- Page 1 2016 KNX Touch Panel Manual Zhuhai Sation Technology Co,.Ltd 2016-1-13...
-
Page 2: Table Of Contents
Content Touch Panel.....................3 1.1 Technical data..................3 1.2 Products appearance................4 Overview functions.................5 Device Technology..................6 3.1 Product paramenters................6 3.2 Dimension drawing and circuit diagram..........7 Exemplary Installation...............10 Contact....................11 Appendix....................12... - Page 3 Copyright Clarify Copyright ownership belongs to Zhuhai Sation Technology Co,.Ltd. shall not be reproduced ,copied,or used in other ways without permission.Otherwise Zhuhai Sation Technology Co,.Ltd will have the right to pursue legal responsibilities. Notice 1. Please carefully read this manual before using the product.
-
Page 4: Touch Panel
1 Touch Panel 1.1 Technical data KNX-Bus feed DC 21V…31V Supply current < 15mA Supply Power consumption < 0.5W Channel 4 fold /6-fold /8-fold Rated current 12mA ON-OFF operation life Unlimited Lifetime Electrical life：>10 years Twin cable comply meet External KNX-TP1 standard connections... -
Page 5: Products Appearance
1.2 Product appearance PT1004 PT1006 PT1008... -
Page 6: Overview Functions
2 Overview functions This booklet provides all the details for the SATION Touch panel, including the installation and programming details. For easy installation,, the product of this series comply with International Installation Standard, mounted on 80mm or 86mm concealed wall socket. -
Page 7: Device Technology
3 Device Technology 3.1 Product parameter Power —operating voltage21...31V DC, bus support —EIB/KNX current consumption<15 mA —EIB/KNX power consumption Max.360 mA Switch performance (contact) —Maximum electrostatic discharge:4kv/10 times per minute —Maximum air electrostatic discharge: 8kv/ 10 times per minute —Maximum response time:500ms Lifetime —Mechanical life: Unlimited —Electrical life: 10 years... -
Page 8: Dimension Drawing And Circuit Diagram
3.2 Dimension drawing and circuit diagram 3.2.1 Dimension drawing... - Page 9 3.2.2 Circuit diagram (mm)
- Page 10 3.2.3 BCU(mm)
-
Page 11: Exemplary Installation
3.3 Exemplary Installation Wall Touch button Key identification chip Glass shell （Installed in wall box）... -
Page 12: Contact
4 Contact Us Zhuhai Sation Technology Co,.Ltd. 3F-2.BlogB1, No.1 software Road. Zhuhai Hi-tech zone ,Guangdong, China519000 TEL：0756-3628171 3628181 FAX：0756-2612730 https://www.sation.com.cn Factory Shenzhen H.Y Display Co,.Ltd. TEL：0755-27336598 FAX：0755-27301699... -
Page 13: Appendix
5 Appendix 5.1 PT10XX series panel electromagnetic compatibility(CE) standards in the chart below. items Require level Performanc Remarks ESD (EN61000-4-2) Contact 4KV/air 8KV 80MHz-2GHz: 3V/m RS (EN61000-4-3) 2G-2.7GHz: 1V/m EFT (EN61000-4-4) ±1KV L-N ±1KV SURGE (EN61000-4-5) L-PE ±2KV EN61000- C/S (EN61000-4-6) M/F (EN61000-4-8) 3V/m DIPS (EN61000-4-11) - Page 14 5.2 PT10XX series panel safety specification (CE) standard in the chart below. Items Require level performance Remarks EN60947-3 Insulation strength test √ Inflaming retarding test √ Temperature rise test √ Corrosion resisting test √ Electrical life test √ On-off volume control test √...
