USER MANUAL
Master XL61 110v Infra-Red
Oil-Fired Heater
Product Code:
Serial Number Range:
From:
To:
Year Of Manufacture:
*Please note, when ordering online via our website if the part number is not recognised,
please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988
KEEP THIS BOOKLET FOR FUTURE REFERENCE
Nottingham: 0115 946 1988 • London: 0208 830 3333
The Hire Supply Company Terms & Conditions Apply At All Time E&OE
XL61110
Nottingham: sales@hscgroupuk.co.uk • London: sean@hscgroupuk.co.uk
www.hscgroupuk.co.uk
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for MCS Master XL61
Summary of Contents for MCS Master XL61
- Page 1 USER MANUAL Master XL61 110v Infra-Red Oil-Fired Heater Product Code: XL61110 Serial Number Range: From: Year Of Manufacture: *Please note, when ordering online via our website if the part number is not recognised, please Email spares@hscgroupuk.co.uk or Telephone 0115 946 1988 KEEP THIS BOOKLET FOR FUTURE REFERENCE Nottingham: 0115 946 1988 •...
- Page 3 TECHNICAL DATA TABLE - TABELLA DATI TECNICI - TECHNISCHE DATENTABELLE - TABLA DE DATOS TÉCNICOS - TABLEAU DES DONNÉES TECHNIQUES - TABEL TECHNISCHE GEGEVENS - TABELA DE DADOS TÉCNICOS - TEKNISK DATATABEL - TEKNISTEN TIETOJEN TAULUKKO - TABELL FOR TEKNISKE DATA - TABELL MED TEKNISKA EGENSKAPER - TABELA DANYCH TECHNICZNYCH - ТАБЛИЦЕ...
- Page 4 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGU- REN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGUR - RYSUN- KI - РИСУНКИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - PAVEIKSLĖLIAI - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - ФИ- ГУРА...
- Page 5 PICTURES - FIGURE - ABBILDUNGEN - FIGURAS - FIGURES - FIGU- REN - FIGURAS - FIGURER - KUVAT - FIGURER - FIGUR - RYSUN- KI - РИСУНКИ - OBRÁZKY - ÁBRÁK - SLIKE - ŞEKİLLER - SLIKE - PAVEIKSLĖLIAI - ATTĒLI - JOONISED - IMAGINI - OBRÁZKY - ФИ- ГУРА...
-
Page 6: Safety Information
IMPORTANT: READ AND UNDERSTAND THIS OPERATIONAL MANUAL BEFORE PERFORMING ASSEMBLY, COMMISSIONING OR MAINTENANCE ON THIS HEATER. INCORRECT USE OF THE HEATER CAN CAUSES SERIOUS INJURY. KEEP THIS MANUAL FOR FURTHER REFERENCE. ►►1. SAFETY INFORMATION ►1.2.3. Heaters in operation near tarpaulin, (WARNINGS) screens or other similar materials need to be located a safe distance away. -
Page 7: Operating Principle
►►3. FUEL NOTE: IN THE EVENT OF HEATER BEING TURNED OFF DUE TO RUNNING OUT OF WARNING: The heater only runs on FUEL, TURN THE HEATER OFF, REFUEL DIESEL or KEROSENE fuel. AND TURN IT BACK ON (SEE PARA. 5.1.). To avoid fire or explosion, use only diesel or ►►5.2. - Page 8 ►►8. DISPLAY ERRORS See B Fig. 3 ERROR CAUSE SOLUTION OPERATION ERROR 1. The “ON/OFF” switch is turned 1. After disconnecting the heater, see that “ON” (|) when the heater is plugged the switch is in the “OFF” (0) position, plug the heater in and turn the switch “ON”...
-
Page 9: Problem Identification
►►9. PREVENTIVE MAINTENANCE SCHEDULE WARNING: BEFOR INITIATING ANY REPAIR OR MAINTENANCE PROCEDURE UNPLUG THE FEEDER CABLE AND MAKE SURE THAT THE HEATER IS COOLED DOWN. COMPONENT MAINTENANCE FREQUENCY MAINTENANCE PROCEDURE Fuel tank Clean every 150-200 hours of Empty and rinse with fresh fuel operation or when necessary Nozzle Clean or replace once per season or... - Page 10 WIRING DIAGRAMS - SCHEMI ELETTRICI - SCHALTPLÄNE - ESQUEMAS ELÉCTRICOS - SCHEMAS ELECTRIQUES - ELEKTRI- SCHE SCHEMA’S - ESQUEMA ELÉTRICO - ELEKTRISKE SKEMAER - SÄHKÖKAAVIOT - KOPLINGSSKJEMA - ELEKTRISKA KOPP- LINGSSCHEMAN - SCHEMATY ELEKTRYCZNE - ЭЛЕКТРИЧЕСКИЕ СХЕМЫ - ELEKTRICKÁ SCHÉMATA - VILLANYBEKÖTÉSI RAJZOK - ELEKTR EMALARI - ELEKTRİK ŞEMASI - ELEKTRIČNE SHEME - ELEKTROS SCHEMOS - ELEKTRISKĀS SHĒMAS - ELEKTRISKEE-...
- Page 11 CE CONFORMITY CERTIFICATE - DICHIARAZIONE DI CONFORMITÀ CE - EG-KONFOR- MITÄTSERKLÄRUNG - DECLARACIÓN DE CONFORMIDAD CE - DECLARATION DE CON- FORMITE CE - EG-CONFORMITEITVERKLARING - DECLARAÇÃO DE CONFORMIDADE CE - EU-OVERENSSTEMMELSESERKLÆRING - EY-VAATIMUSTENMUKAISUUSVA- KUUTUS - CE-SAMSVARSERKLÆRING - EG-FÖRSÄKRAN OM ÖVERENSSTÄMMELSE - DEKLARACJA ZGODNOŚCI WE - ДЕКЛАРАЦИЯ...
- Page 12 ►en - DISPOSAL OF THE PRODUCT -This product has been designed and manufactured with top-quality materials and components, which can be re-cycled and re- used. -When a crossed-wheely bin symbol is attached to the product, it means that the product is protected by the, 2012/19/UE European Directive.
- Page 13 ►da - BORTSKAFFELSE -Dette produkt er designet og fremstillet med materialer og dele af høj kvalitet, der kan genanvendes. -Når et produkt er mærket med symbolet, der viser en affaldsspand på hjul med et kryds over, betyder det, at produktet er beskyttet af EF-Direktiv 2012/19/UE.
- Page 14 ►hu - HULLADÉKBA HELYEZÉS -A termék kiváló minőségű újrahasznosítható és újból felhasználható alkotóelemek felhasználásával készült. -Ha terméken elhelyezésre került az áthúzott hulladékgyűjtőt ábrázoló jel, az azt jelenti, hogy a termékre a 2012/19/UE irányelv vonatkozik. -Kérjük, tájékozódjon az elektromos és elektronikus hulladékok szelektív gyűjtéséről. -Tartsa be a helyben hatályos előírásokat, és ne a terméket ne helyezze a háztartási hulladékgyűjőbe.
- Page 15 ►ro - SCOATEREA DEFINITIVĂ DIN UZ A PRODUSULUI -Acest produs a fost proiectat şi fabricat cu materiale şi componente de înaltă calitate care pot fi reciclate şi refolosite. -Când pe produs este aplicat simbolul unei pubele cu roţi, marcată cu o cruce, înseamnă că produsul respectiv este conform Directivei Europene 2012/19/UE.
- Page 16 NOTE:_____________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________ ____________________________________________________________________...
- Page 17 Recycling ENVIRONMENTAL PROTECTION: Please recycle any unwanted materials as opposed to disposing them as general waste. It is recommended the original is retained and used to store the product when not in use for prolonged periods of time. If this is not applicable ensure the materials are sorted and recycled in accordance with local regulations.
