Summary of Contents for ChlorKing 5000 TDS
- Page 1 ChlorKing 5000 TDS Installation and Operation ChlorKing 5000 TDS Controller Installation & Operations Guide ChlorKing 5000 TDS Page 1 of 7 10/26/2015 Installation & Operation...
-
Page 2: Section 1 Description
SECTION 1 DESCRIPTION 1.1 GENERAL INFORMATION The ChlorKing® 5000 TDS Controller automates the process of controlling Total Dissolved Solids (TDS). The controller constantly monitors TDS. When TDS reaches a predetermined value the controller will open an actuated valve to automatically drain water as a separate auto fill device fills the body of water until the desired TDS value is reached. -
Page 3: General Specifications
ChlorKing 5000 TDS Installation and Operation 1.3 GENERAL SPECIFICATIONS Output Description Input Volts Phase Frequency Volts/Amps ChlorKing 120vac@ 5000 TDS 120vac 50/60Hz 10amps Controller Rated Description TDS Range Inlet/Outlet Min/Max Flow Pressure ChlorKing 0-14,000 1 gpm – 5000 TDS 30 psi... - Page 4 ChlorKing 5000 TDS Installation and Operation 2.3 SAFETY CONSIDERATIONS IMPORTANT SAFETY INSTRUCTIONS READ AND FOLLOW ALL INSTRUCTIONS SAVE THESE INSTRUCTIONS WHEN INSTALLING, OPERATING, AND MAINTAINING THIS EQUIPMENT, KEEP SAFETY CONSIDERATIONS FOREMOST. USE PROPER TOOLS, PROTECTIVE CLOTHING, AND EYE PROTECTION WHEN WORKING ON OR INSTALLING THE EQUIPMENT.
- Page 5 ChlorKing 5000 TDS Installation and Operation Installation instructions: Mount the ChlorKing 5000 TDS controller to the wall. The controller black cord plugs into a 120VAC wall outlet. Plumb the water connections as shown in the diagram below. Schematic diagram of ChlorKing 5000 TDS Controller...
- Page 6 ChlorKing 5000 TDS Installation and Operation ChlorKing 5000 TDS operation The controller displays the TDS concentration in PPM. The set point is factory adjusted to 1500ppm TDS. To change the set point, press the menu button once. The display will display the set point. Once the set point is displayed, press and hold the menu button for 15 seconds.
- Page 7 ChlorKing 5000 TDS Installation and Operation To display water temperature, press the menu button two times. Pressing the menu button a third time will bring the salt concentration screen back up. The controller will default to the salt concentration screen automatically after a set period of time.
