Pioneer S-W33 Service Manual

Y PIONEER'
The Art of Entertainment
Service
Manua oe
RRV1186
SPEAKER SYSTEM
="W 3 mt XEE
@ This product is a system(s) component. This product's instructions are contained within the
instruction manual of the related system component(s). The manual is packed with those-
component(s).
@ The woofer is attached to the inner baffle by 4
external screws.
To detach it, first remove back-boad.
The back-boad is attached by the 8 screws.
When attaching woofer, face its terminal rightward
and leftward.
The woofer has two terminals(L, R).
