Installation tools not included:
Materials Included:
4 short nylon rawlplug
4 short screws
2 long nylon rawlplug
2 acorn nut
2 nylon washer
2 metal washer
Installation notes:
Install this product according to the installation guide
Special site preparation is required.
Wall bracing and Baden Haus supplied hardware are
recommended.
The plumbing must be roughed into the plumbing
cutout area of the vanity.
Refer to the sink rough-in and the vanity rough-in for
proper placement. The water supply and drain lines
must be installed before installing the vanity.
X4
X4
X2
X2
X2
X2
LIBERA
X2
Advertisement
Summary of Contents for BH LIBERA Series
- Page 1 LIBERA Installation notes: Install this product according to the installation guide Special site preparation is required. Wall bracing and Baden Haus supplied hardware are recommended. The plumbing must be roughed into the plumbing cutout area of the vanity. Refer to the sink rough-in and the vanity rough-in for proper placement.
- Page 2 LIBERA Step 1 Determine the ideal location of your new vanity. Mark the holes and drill pilot holes in the dry wall. Step 2 Place the console frame on the finished wall and install at the locations drilled with the screws shown in Figure 2: The short nylon raw for the short screw.
