- Page 1 SERVICE MANUAL COOKER HOODS © ELECTROLUX HOME PRODUCTS Publication number Customer Care - EMEA Training and Operations Support “FABER” PRODUCTION Technical Support Electromechanical Range 599 75 36-46 Edition: 06/2012 - Rev. 00...
- Page 2 Technical Support - FV 2/18 599 75 36-46 Rev.00...
-
Page 3: Table Of Contents
1.3 - IMPORTANT INFORMATION ---------------------------------------------------------------- page 2 - MAIN FEATURES ---------------------------------------------------------------------------- page 5 3 - MODEL ZHP9022X PNC 942490324 --------------------------------------------------- page 5 3.1 - THE COMANDS ARE NOT WORKING ---------------------------------------------------- page 3.2 - THE MOTOR ARE NOT WORKING -------------------------------------------------------- page 4 - MODEL ZHT630X - W PNC 942490341 / 2 ------------------------------------------- page 8 4.1 - FILTERS ------------------------------------------------------------------------------------------- page... -
Page 4: Introduction
Before working on a device, check the efficiency of the system casing using appropriate equipment. As an example, refer to the indications described / illustrated in the portal Electrolux Learning Gateway (http://electrolux.edvantage.net). After the work, carry out electrical safety tests and ensure that the all safety devices are working properly. -
Page 5: Main Features
- Lighting with traditional lamp (bulb) - Mechanical controls 3 - MODEL ZHP9022X PNC 942490324 3.1 - THE COMANDS ARE NOT WORKING If it is certain that the command card is not functioning proceed with the replacement operation as follows: Extract the sliding panel and remove the metal grease filters;... - Page 6 Open the command unit by unscrewing the two side screws, extract the card and replace it with one that has the same characteristics according to the electrical connections (Fig. 5 and 6) Fig. 5 Reset everything and check to see that it is functioning correctly Fig.
-
Page 7: The Motor Are Not Working
3.2 - THE MOTOR ARE NOT WORKING In order to replace the motor or the impeller, operate as follows: Remove the external cover on the motor compartment, by using the two side handles; By using a small regular screwdriver, extract the two black screw caps (Fig. 7) Fig. -
Page 8: Model Zht630X - W Pnc 942490341
4 - MODEL ZHT630X - W PNC 942490341 / 2 4.1 - FILTERS To access the filters pull the two hooks and remove the protective grill. Fig. 10 Fig. 11 4.2 - ILLUMINATION To remove the ceiling press the hook fasteners. Unscrew the 2 screws. -
Page 9: Supply Connection
4.3 - SUPPLY CONNECTION To access to the connection cover of motor unscrew the screw fixing. Fig. 15 4.4 - MOTOR The motor is fixed with 4 screws. Detail of the caps covering the motor cover. Fig. 16 Fig. 17 Fig. -
Page 10: Controls
4.5 - CONTROLS To remove the small panel controls to push the pin from the inside out and slide the small panel. Fig. 20 Fig. 21 To disassemble the control unit remove the 4 screws. Fig. 23 Fig. 22 Technical Support - FV 10/18 599 75 36-46 Rev.00... -
Page 11: Setting Recycling / Expulsion
4.6 - SETTING RECYCLING / EXPULSION Attachment points of the door Recycling / Expulsion Fig. 25 Fig. 24 Snap flange which may be mounted above or below. Removing filters. Fig. 27 Fig. 26 Technical Support - FV 11/18 599 75 36-46 Rev.00... -
Page 12: Model Zhc 900X Pnc 942492623
5 - MODEL ZHC 900X PNC 942492623 5.1 - FILTERS Position filters. Fig. 28 5.2 - ILLUMINATION Screw fixation of ceiling. Fig. 29 Technical Support - FV 12/18 599 75 36-46 Rev.00... -
Page 13: Controls And Lamp
5.3 - CONTROLS AND LAMP Dismounting of the control group and lamp. Fig. 30 Fig. 31 Fig. 32 Fig. 33 Technical Support - FV 13/18 599 75 36-46 Rev.00... -
Page 14: Motor
5.4 - MOTOR Wire connectors and 2 fixing screws. Fig. 34 Technical Support - FV 14/18 599 75 36-46 Rev.00... -
Page 15: Model Zhc9131X Pnc 942492629
6 - MODEL ZHC9131X PNC 942492629 6.1 - FILTER - Metal filter only in the version of 60 cm, 2 filters in one of 90 cm. - Painted background. - Structure and background provided with protective. - New control unit "245" series. - Corners bent and welded. -
Page 16: Controls
6.3 - CONTROLS Lift the right side of the control panel and slide it left to free it from the body. Fig. 37 Remove the control panel, lifting (with a small screwdriver) the 4 securing tabs to the commands group. NOTE: When putting the group to the body, attach before the "black"... -
Page 17: Illumination
6.5 - ILLUMINATION Ceiling fixed to the body by plastic clips. Fig. 41 Lighting with filament lamps of 40W each Fig. 42 7 - MODEL ZHT920X PNC 942492663 7.1 - CONTROLS 2 screws to remove the frame from the hood body 2 screws to remove the controls box from the hood body... -
Page 18: Motor And Lighting
7.2 - MOTOR AND LIGHTING 4 screws to remove the motor holder 2 nuts to remove the motor 1 nut to remove the impeller Bulb reflector Fig. 44 8 - REVISIONS: Revision Date Description Author Approved by - on 06/2012 Document Creation Technical Support - FV 18/18...
