JACS TD0231 User Manual

5g industrial dongle
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
x
1
TD0231
5G Industrial Dongle

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the TD0231 and is the answer not in the manual?

Questions and answers

Related Manuals for JACS TD0231

Summary of Contents for JACS TD0231

  • Page 1 TD0231 5G Industrial Dongle...

  • Page 2: Table Of Contents

    Index Chapter 1 TD0231 Introduction ...................... 3 Chapter 2 Product Overview ......................4 Packing List ........................4 Equipment Interface ......................4 LED behavior ........................5 Chapter 3 Hardware Installation ...................... 6 3.1. Install & Remove SIM Card ................... 6 3.1.1.

  • Page 3: Chapter 1 Td0231 Introduction

    GNSS receiver supports GPS, GLONASS, Beidou and Galileo constellations. This document will serve as a User Manual for TD0231 dongle. In the following document, the TD0231 dongle will be named as dongle for short. Carefully read the following safety symbols to help you use your dongle safely and correctly.

  • Page 4: Chapter 2 Product Overview

    Product Overview Chapter 2 Packing List Figure 2-1 Equipment Interface Figure 2-2...

  • Page 5: Led Behavior

    LED behavior When setting up the dongle unit, the LED will have the following behavior: Figure 2-3...

  • Page 6: Chapter 3 Hardware Installation

    Hardware Installation Chapter 3 3.1. Install & Remove SIM Card Please ensure that you are using the 4th Form Factor Card (4FF Card, i.e. Nano SIM Card) in our the dongle before you start reading through the following steps. Insert SIM card 3.1.1.

  • Page 7: Connect 5G Antenna

    3.2. Connect 5G Antenna There are four 5G antenna TNC ports on the dongle, and you shall install four antennas for the best performance. Technical Specification Frequency Bands Refer to 5G bands support list Input Impedance Voltage Standing Wave Ratio <...

  • Page 8: Connect Gps Antenna

    3.3. Connect GPS Antenna This dongle has one TNC GPS interface as an optional feature, which can support information regarding Real-Time location. Technical Specification Working Frequency 1575.42/1602MHz Active GNSS Technology GPS/GLONASS/Galileo/BeiDou Input Impedance Horizontal Position Accuracy 2.5 meters Interface Type TNC-J Male Figure 3-3 If GPS port needs the better ability of water and vibration proof, please twining PVC...
  • Page 9 If the screws cannot be fully screwed in, they may not be assembled in place. Please loosen the screws, reinsert the head in place, and then tighten the screws with a screwdriver. Figure 3-4...

  • Page 10: Chapter 4 Software Configuration

    Software Configuration Chapter 4 Getting Started 4.1.1 Login to the Web Management Page Launching a web browser to login to the web management page, you will configure and manage the router from that place. The following procedure describes how to use a web browser with Internet Explorer 7.0 to login to the web management page of the router.

  • Page 11: Home

    Home 4.2.1 Device Information To view the device information, perform the following steps: 1. Choose Home. 2. In the device information area, view the connection status, such as Product Model, Software Version, Online Time and Running Time. See an example screenshot in Figure 4-3. Figure 4-3 Cellular Network 4.2.2...

  • Page 12: Wan Status

    Figure 4-4 4.2.3 WAN Status To view the WAN Status, perform the following steps: Choose Home. 2. In the WAN Status area, view the information about Connect Method, Connect Mode, IP Address, Subnet Mask, and DNS Server. See Figure 4-5. Figure 4-5 Statistics...

  • Page 13: Viewing Cpu Usage

    Viewing CPU Usage 4.3.1 To view the CPU usage, perform the following steps: Choose Statistics. In the CPU Usage area, view the CPU usage information, such as Current CPU usage, Max CPU usage, Min CPU usage. See Figure 4-6. Figure 4-6 Viewing Memory Usage 4.3.2 To view memory usage, perform the following steps:...

  • Page 14: Viewing Throughput Statistics

    Figure 4-8 Viewing Throughput Statistics 4.3.4 To view the Throughput Statistics, perform the following steps: 1.Choose Statistics. 2.In the Throughput Statistics area, view the throughput statistics, such as APN throughput and LAN throughput. In this area, also you can choose and click the button Reset to empty the throughput statistics. As shown in Figure 4-9.

  • Page 15: Upgrade

    Figure 4-11 Upgrade Manual Upgrade 4.4.1 4.4.1.1 Version Information This function enables you to upgrade the software version of the SRG 5G series router to a new version. To view the version info, perform the following steps: Choose Upgrade> Manual Upgrade. In the Version Info area, you can view the product name and software version.

  • Page 16: Advanced Upgrade

    Choose Upgrade> Manual Upgrade. In the Version Upgrade area, click Browser. In the displayed dialog box, select the target software version file. Click Open. The dialog box closes. The saved path and name of the target software version file are displayed in the Upgrade file field Click Save.

  • Page 17: Auto Upgrade

    Figure 4-15 4.4.2.3 Recovery Partition File Here you can select the file from your computer to recover partition, to download the instructions file perform the following steps: 1. Choose Upgrade>advanced upgrade. 2. Click Upload, and then select the file from your computer to recover partition. As shown in Figure 4-16. Figure 4-16 4.4.2.4 Recovery Mode Here you can recover the equipment, but one thing you have to know is that be sure to download the EXE file before...

  • Page 18: Advanced Settings

    Enable auto upgrade. If you want to check new firmware after connecting to Internet, you need to enable the item of Check new firmware after connecting to Internet. Set the ftp server address to the Upgrade folder box. Set Version file. //This contains the new FW name Set Username and Password.

  • Page 19: Version Information

    4.5.1.2 Version Information To view the Version Information, perform the following steps: Choose Advanced Settings. In the Device Information area, view the device information, such as Product Model, Hardware Version, Software version, Uboot version, IMEI, IMSI and Serial Number, as shown in Figure 4-20. Figure 4-20 4.5.1.3 LAN Status...

  • Page 20: Dns Settings

    Figure 4-22 4.5.2.2 DNS Settings Static DNS has the highest priority, VPN DNS follows it and LTE DNS has the lowest priority. If you want to restore the VPN/LTE DNS, please clear the two DNS configuration and submit. To set the DNS, perform the following steps: 1.

  • Page 21: Radio Settings

    Figure 4-24 4.5.2.4 Radio Settings To set the device automatically connect to the internet, perform the following steps: Choose Network > Radio Settings. In the Setting area, select a connect method between Auto and Manual. As shown in Figure 4-25. Figure 4-25 In the Radio settings status will show the radio information.
  • Page 22 Figure 4-26...

  • Page 23: Scan Mode

    4.5.2.5 Scan Mode This function is used to config the UE mode of scan network. The default scan mode is full band. To set the LTE network scan mode, perform the following steps: choose Network>Scan mode. If select Bandlock, UE will only connect to the checked bands. Others will not be scanned. Also, there are 2.4G and 5G two buttons that you can choose.

  • Page 24: Lan Setting

    Figure 4-28 4.5.2.7 SIM Lock If you want to connect a specific network, and the router cannot connect other networks, you can set a SIM lock. To set the SIM lock, perform the following steps: Choose Network>SIM Lock. Input the PLMN you want to lock in the PLMN box. Click add to add the PLMN in the lock list.

  • Page 25: Static Route

    Figure 4-30 4.5.2.9 Static Route To add a static route, perform the following steps: Choose Network>Static Route. Click the Add list. Set the Destination IP address and Subnet mask. Select an Interface from the drop-down list. If you select LAN as the interface, you need to set a Gateway. Click Save.

  • Page 26: Security Settings

    Figure 4-32 4.5.3 Security Settings 4.5.3.1 Firewall This page describes how to set the firewall. If you enable or disable the firewall, you can modify the configuration. To set the firewall, perform the following steps: Choose Security Settings>Firewall. Choose Enable or Disable to modify the configuration. Click Save.
  • Page 27 Figure 4-34 4.5.3.2.2 Disabling MAC Filtering To disable MAC address filter, perform the following steps: Choose Security Settings>MAC Filtering. Set MAC filtering to Disable. Click Save. As shown in Figure 4-35. Figure 4-35 4.5.3.2.3 Setting Allow access network within the rules To set allow access network within the rules, perform the following steps: Choose Security Settings>MAC Filtering.
  • Page 28 4.5.3.2.4 Setting Deny access network within the rules To set deny access network within the rules, perform the following steps: Choose Security Settings>MAC Filtering. Set Deny access network within the rules. Click Save. As shown in Figure 4-37. Figure 4-37 4.5.3.2.5 Adding MAC filtering rule To add a MAC filtering rule, perform the following steps: Choose Security Settings>MAC Filtering.

  • Page 29: Enable Ip Filtering

    Set MAC address. Click Save. As shown in Figure 4-39. Figure 4-39 4.5.3.2.7 Deleting MAC Filtering rule To delete a MAC address filter rule, perform the following steps: Choose Security Settings>MAC Filtering. Choose the rule to be deleted and click Delete. As shown in Figure 4-40. Figure 4-40 4.5.3.3 IP Filtering...
  • Page 30 Figure 4-41 4.5.3.3.2 Disable IP Filtering To disable IP Filtering, perform the following steps: Choose Security Settings >IP Filtering. Set IP Filtering Disable. Click Save. As shown in Figure 4-42. Figure 4-42 4.5.3.3.3 Setting Allow access network outside the rules To set allow access network, perform the following steps: Choose Security Settings >IP Filtering.
  • Page 31 4.5.3.3.4 Setting Deny access network outside the rules To set allow access network, perform the following steps: Choose Security Settings >IP Filtering. Set Deny access network outside the rules. Click Save. As shown in Figure 4-44. Figure 4-44 4.5.3.3.5 Adding IP Filtering rule Add an IP address filtering rule, perform the following steps: Choose Security Settings >IP Filtering.
  • Page 32 Figure 4-45 4.5.3.3.6 Modifying IP Filtering rule To modify an IP filtering rule, perform the following steps: Choose Security Settings > IP Filtering. Choose the rule to be modified and click Edit. Repeat steps 3 through 9 in the previous procedure. Click Save.

  • Page 33: Url Filtering

    Figure 4-47 4.5.3.4 URL Filtering Data is filtered by a uniform resource locator (URL). This page enables you to configure URL filtering rules. 4.5.3.4.1 Enabling URL Filtering To enable URL Filtering, perform the following steps: Choose Security Settings >URL Filtering. Set URL Filtering to Enable.
  • Page 34 4.5.3.4.3 Adding URL Filtering list To add an URL filtering list, perform the following steps: Choose Security Settings >URL Filtering. Click Add list. Set URL. Click Save. As shown in Figure 4-50. Figure 4-50 4.5.3.4.4 Modify URL Filtering list To modify an URL filtering rule, perform the following steps: Choose Security Settings >URL Filtering.

  • Page 35: Parental Controls

    Figure 4-52 4.5.3.5 Parental Controls 4.5.3.5.1 Enabling Parental Controls To enable Parental Controls, perform the following steps: 1.Choose Security Settings > Parental Controls. 2.Set Parental Controls to Enable. As shown in Figure 4-53. 3.Click Save. Figure 4-53 4.5.3.5.2 Disabling Parental Controls To disable Parental Controls, perform the following steps: 1.Choose Security Settings >...
  • Page 36 4.5.3.5.3 Adding Parental Controls list To add a Parental Controls list, perform the following steps: 1.Choose Security Settings >Parental Controls. 2.Click Add list. 3.Set Name. 4.Set Device MAC address or IP address. 5.Set Weekdays and time. 6.Click Save. As shown in Figure 4-55. Figure 4-55 4.5.3.5.4 Modify Parental Controls list To modify a Parental Controls rule, perform the following steps:...

  • Page 37: Port Forwarding

    4.5.3.5.5 Deleting Parental Controls list To delete a Parental Controls list, perform the following steps: Choose Security Settings> Parental Controls. Choose the item to be deleted and click Delete. As shown in Figure 4-57. Figure 4-57 4.5.3.6 Port Forwarding When network address translation (NAT) is enabled on the router, only the IP address on the WAN side is open to the Internet.
  • Page 38 Figure 4-58 4.5.3.6.2 Modifying Port Forwarding rule To modify a port forwarding rule, perform the following steps: Security Settings Choose > Port Forwarding. Choose the item to be modified and click Edit. Re-config the service, protocol, and ports. Click Save. As shown in Figure 4-59. Figure 4-59 4.5.3.6.3 Deleting Port Forwarding rule To delete a port forwarding rule, perform the following steps:...
  • Page 39 Figure 4-60 4.5.3.7 UPnP On this page, you can enable or disable the Universal Plug and Play (UPnP) function. To enable UPnP, perform the following steps: Security Settings 1. Choose > UPnP. 2. Set UPnP to Enable. 3. Click Save. As shown in Figure4-61. Figure 4-61 4.5.3.8 On this page, you can enable or disable the Denial of service (DoS) function.

  • Page 40: Vpn

    4.5.3.9 If the demilitarized zone (DMZ) is enabled, the packets sent from the WAN are directly sent to a specified IP address on the LAN before being discarded by the firewall. To set DMZ, perform the following steps: 1.Choose Security Settings > DMZ Settings. 2.Set DMZ to Enable.

  • Page 41: Ipv6

    Figure 4-64 IPv6 4.5.5 Internet Protocol version 6 (IPv6) is the most recent version of the Internet Protocol (IP). Every device on the Internet is assigned a unique IP address for identification and location definition. 4.5.5.1 IPv6 Status The status page shows IPv6 information. As shown in Figure 4-65. Figure 4-65 4.5.5.2 IPv6 WAN Settings In this page, the user can enable or disable IPv6 function.

  • Page 42: Ipv6 Lan Settings

    Figure 4-66 4.5.5.3 IPv6 LAN Settings On this page, the user can choose the Auto configuration Type. As shown in Figure 4-67. Figure 4-67 System 4.5.6 4.5.6.1 Maintenance 4.5.6.1.1 Reboot This function enables you to restart the router. Settings take effect only after the router restarts. To restart the router, perform the following steps: Choose System>Maintenance.
  • Page 43 Figure 4-68 4.5.6.1.2 Reset This function enables you to restore the router to its default settings. To restore the router, perform the following steps: Choose System>Maintenance. The router is then restored to its default Click Factory Reset. As shown in Figure 4-69. settings.
  • Page 44 4.5.6.1.4 Upload Configuration File You can upload a backed-up configuration file to restore the router. To do so: Choose System>Maintenance. Click Browse on the Maintenance page. In the displayed dialog box, select the backed-up configuration file. Click Open. The dialog box chooses. In the box to be right of the Configuration file, the save path and name of the backed-up configuration file are displayed.
  • Page 45 Figure 4-72 4.5.6.3 Date & Time You can set the system time manually or synchronize it with the network. If you select Sync from network, the router regularly synchronizes the time with the specified Network Time Protocol (NTP) server. If you enable daylight saving time (DST), the router also adjusts the system time for DST. 4.5.6.3.1 Set manually To set the date and time, perform the following steps: Choose System >...
  • Page 46 4.5.6.3.2 Sync from network To synchronize the time with the network, perform the following steps: Choose System > Date & Time. Select Sync from network. From the Primary NTP server drop-down list, select a server as the primary server for time synchronization.
  • Page 47 Figure 4-75 The router will automatically provide the DST time based on the time zone. 4.5.6.4 TR069 TR-069 is a standard for communication between routers and the auto-configuration server (ACS). If your service provider uses the TR069 automatic service provision function, the ACS automatically provides the router parameters.
  • Page 48 4.5.6.5 SNMP You can enable SNMP and set config SNMP trap. The UE will actively report changes of certain values to the SNMP server. As shown in Figure 4-77 Figure 4-77 4.5.6.6 Iperf Iperf is a network performance testing tool. You can test TCP and UDP bandwidth quality. It can test the maximum TCP bandwidth, with a variety of parameters and UDP characteristics.
  • Page 49 Figure 4-78 4.5.6.6.2 UDP To set UDP, perform the following steps: 1.Choose System>Iperf. 2.Set Trap Server. 3.Set Server Port (1024~65535). 4.Set Management Port (1024~65535). 5.Set Measurement Time (10~86400). 6.Set Protocol, select UDP. 6.Set Packet Length (1~1470). 6.Set UDP Bandwidth. 7.Click Save and wait for few minutes, the results will be shown in the Result area. As shown in Figure 4-79.
  • Page 50 Figure 4-79 4.5.6.7 Diagnosis Simple network diagnostic function for CPE 4.5.6.7.1 Ping If the router fails to access the Internet, run the ping command to preliminarily identify the problem. To do so: Choose System>Diagnosis. In the Method area, select Ping. Enter the domain name in the Target IP or domain field, for example, www.google.com.
  • Page 51 Figure 4-80 4.5.6.7.2 Traceroute If the router fails to access the Internet, run the Traceroute command to preliminarily identify the problem. To do so: Choose System>Diagnosis. In the Method area, select Traceroute. Enter the domain name in the Target IP or domain field. For example, www.google.com. Set Maximum hops ad Timeout.
  • Page 52 4.5.6.8 Syslog The syslog record user operations and key running events. 4.5.6.8.1 Network To set the syslog to network, perform the following steps: Choose System>Syslog. In the Setting area, set the method to Network. In the Level drop-down list, select a log level. In the Forward IP address box, set the IP address.

  • Page 53: Port Mirror

    Figure 4-83 4.5.6.9 Port Mirror Port mirroring is used on a network switch to send a copy of network packets seen on one switch port. To do so: Choose System>Port Mirror. Enable Port Mirror. Select the WAN Interface which you want a copy. Type the Monitor IP, where the copy will send to.
  • Page 54 Set HTTP port. If you want to change the login port, you can set a new port in the box, the default HTTP port is 80. Set HTTPS enable. If you want to log in the web management page with the HTTPS protocol from WAN side, you need to enable the HTTPS.
  • Page 55 Figure 4- 4.5.6.12 QXDM setting When use QXDM to capture logs, users need to set configuration on CPE, so that the QXDM tool can work. To set the QXDM, perform the following steps: 1.Choose System>QXDM settings. 2.Set QXDM to Enable. 3.Set IP Address.
  • Page 56 Figure 4-88...

  • Page 57: Chapter 5 Faqs

    FAQs Chapter 5 The POWER indicator does not turn on.  Make sure that the power cable is connected properly and the router is powered on.  Make sure that the power supply is compatible with the router. Fails to Login the web management page. ...
  • Page 58 DISCLAIMER ALL CONTENTS OF THIS MANUAL ARE PROVIDED "AS IS". EXCEPT AS REQUIRED BY APPLICABLE LAWS, NO WARRANTIES OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY AND FITNESS FOR A PARTICULAR PURPOSE, ARE MADE IN RELATION TO THE ACCURACY, RELIABILITY OR CONTENTS OF THIS MANUAL.
