381166698
Valid from
07.11.2024
EPIC
Content
Scope of delivery .......................................................................................................................... 1
Technical specifications................................................................................................................ 2
Suitable matching connectors ...................................................................................................... 3
Safety instructions ........................................................................................................................ 3
Necessary tool .............................................................................................................................. 4
Installation of EPIC
Preparing the cable ....................................................................................................................... 5
Stripping the cable ........................................................................................................................ 5
Crimping the contacts .................................................................................................................. 5
Mounting of the connector ........................................................................................................... 6
Connecting and disconnecting ..................................................................................................... 7
Cable laying .................................................................................................................................. 8
Trademark on the Product: EPIC
Scope of delivery
The connector EPIC
included separately.
Article number
381166698
381166699
Designation
M / F
4-6mm²
Document: L381166698EN
Version: 00
We reserve all rights according to DIN ISO 16016.
Assembly instruction
EPIC
®
SOLAR 4 GEN2 PANEL MOUNT
SOLAR 4 GEN2 PANEL MOUNT
®
ASSEMBLY INSTRUCTION
®
SOLAR 4 GEN2 PANEL MOUNT .................................................................. 5
®
®
SOLAR 4 GEN2 PANEL MOUNT is delivered pre-assembled, contacts are
EPIC SOLAR 4 GEN2 Panelmount M 4-6mm²
EPIC SOLAR 4 GEN2 Panelmount F 4-6mm²
For wire cross-sections 4,0mm² or 6,0mm²
Article description
Description
Male (M) or female (F) contacts
Page 1 of 8
Advertisement
Table of Contents
Summary of Contents for LAPP EPIC SOLAR 4 GEN2
-
Page 1: Table Of Contents
The connector EPIC SOLAR 4 GEN2 PANEL MOUNT is delivered pre-assembled, contacts are included separately. Article number Article description 381166698 EPIC SOLAR 4 GEN2 Panelmount M 4-6mm² 381166699 EPIC SOLAR 4 GEN2 Panelmount F 4-6mm² Designation Description M / F Male (M) or female (F) contacts 4-6mm²... -
Page 2: Technical Specifications
Assembly instruction 381166698 Valid from EPIC ® SOLAR 4 GEN2 PANEL MOUNT 07.11.2024 Female connector Male connector Contacts Female contact Male contact Technical specifications According to IEC 62582: 2014+A1:2020 Rated Voltage 1.500V DC Rated Current 40A (4,0 mm²) 50A (6,0 mm²) Rated impulse withstand voltage 16 kV Rated temperature... -
Page 3: Suitable Matching Connectors
SOLAR 4 GEN2 may only be assembled using tools and aids specified by LAPP. The cable may only be connected to the connector by trained electricians. To protect the installer from the danger of the electric current, the connector must be made floating on all sides during installation. -
Page 4: Necessary Tool
® SOLAR 4 GEN2 PANEL MOUNT 07.11.2024 Necessary tool Cable shears for cutting the PV-cables: LAPP Cable shear KS20, article number 62120523 Stripping Tool to strip the PV-Cable LAPP Universal Strip Solar, article number 21920120 Crimping tool Note: To comply the tested quality, it`s necessary to use only the indicated tools. -
Page 5: Solar 4 Gen2 Panel Mount
Assembly instruction 381166698 Valid from EPIC ® SOLAR 4 GEN2 PANEL MOUNT 07.11.2024 Installation of EPIC SOLAR 4 GEN2 PANEL MOUNT ® Preparing the cable Cut the cable cleanly - the strands must not have any oxidation or contamination. Stripping the cable Stripping length: L = 8mm. -
Page 6: Mounting Of The Connector
Assembly instruction 381166698 Valid from EPIC ® SOLAR 4 GEN2 PANEL MOUNT 07.11.2024 Illustration of the crimping process Contact in the crimp insert Contact with cable in the crimp insert Mounting of the connector Panel cut-out for installation of the connector Insert the connector in the cut-out and tighten the locknut by torque moment 2-3 Nm. -
Page 7: Connecting And Disconnecting
Assembly instruction 381166698 Valid from EPIC ® SOLAR 4 GEN2 PANEL MOUNT 07.11.2024 Insert the crimped contact into the connector until the contact clicks into place. Pull the cable slightly to make sure that the contact is properly engaged. Connecting and disconnecting Before plug in, check the plugging area for possible soiling and clean it if necessary. -
Page 8: Cable Laying
The cable must be led straight out of the connector at least L min = 50 mm. The bending radius R min must be at least 10x outer diameter of the cable. U.I. Lapp GmbH Schulze- Delitzsch- Straße 25 •D-70565 Stuttgart Tel.: +49 (0) 711 7838-01...
