Supports two straight 400Gb/s or two 1:2 splitter ber cables for 200Gb/s
Finned-top OSFP for air-cooled switches
Flat-top OSFP for DGX- H100 or liquid-cooled
850nm VCSEL
Maximum reach:
30m using OM3 ber
50m using OM4 ber
Two MPO-12/APC optical connectors
17 Watts max power
2.0 Watt low-power sleep mode
Single 3.3V power supply
Class 1 laser safety
Hot pluggable, RoHS compliant
OSFPmsa.org compliant
CMIS 4.0 compliant
Case temperature range 0°C to +70°C
Applications
Used in Quantum-2 air-cooled switches, liquid-cooled and DGX-H100 systems to
switches, ConnectX-7, and BlueField-3 DPUs
MMA4Z00-NS 800Gb/s Twin-port OSFP, 2x400Gb/s Multimode 2xSR4, 50m
4
