SIS2400 2400W IMPACT SHREDDER

ORIGINAL INSTRUCTIONS

FOR YOUR SAFETY

PLEASE READ THESE INSTRUCTIONS CAREFULLY

AND RETAIN THEM FOR FUTURE USE.

Table of Contents

Need help?

Do you have a question about the SIS2400 and is the answer not in the manual?

Questions and answers

Summary of Contents for SGS SIS2400

Page 1 SIS2400 2400W IMPACT SHREDDER ORIGINAL INSTRUCTIONS FOR YOUR SAFETY PLEASE READ THESE INSTRUCTIONS CAREFULLY AND RETAIN THEM FOR FUTURE USE.
Page 2 Objects thrown by the product could hit the user or other bystanders. Always ensure that other people and pets remain at a safe distance from the product when it is in operation. In general, children must not come near the area where the product is. WWW.SGS-ENGINEERING.COM PAGE 2...
Page 3: General Safety
GENERAL SAFETY 1. This appliance can be used by children aged from 1 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards involved.
Page 4: While Working
30 mA residual current device (RCD). WHILE WORKING 1. Make sure that the hopper is empty before switching the product on. 2. Keep your head, hair and other body parts away from the mouth of the hopper. WWW.SGS-ENGINEERING.COM PAGE 4...
Page 5 3. Do not touch any moving parts of the product until it has been disconnected from the power supply and the moving parts have come to a complete standstill. 4. Avoid any abnormal posture when using the product. Stand on the same level as the feet/wheels of the shredder. 5.
Page 6 4. Never try to repair the product unless you are qualified to do so. All service of the product other than that mentioned in this instruction manual should be carried out by qualified personnel and only using original spare parts. WWW.SGS-ENGINEERING.COM PAGE 6...
Page 7: Electrical Safety
ELECTRICAL SAFETY Warning! The following instructions state how to avoid accidents and injuries due to electric shock. 1. Damaged cables, connectors and plugs or extension leads not corresponding to specifications, must not be used. Unplug the product immediately if the mains cable or plug has been damaged.
Page 8 6. Never unplug the extension cable from the wall socket or connector on the product by pulling the cable, always grip and pull the plug itself. 7. Keep the cable away from heat, oil, sharp edges and moving parts. WWW.SGS-ENGINEERING.COM PAGE 8...
Page 9: General View
GENERAL VIEW Parts of the shredder Transport handle Hopper Locking knob On/Off switch Power cord Debris bag hook Motor housing Discharge chute Stand 10. Wheel 11. Plunger 12. Feeding funnel 13. Ventilation slot PAGE 9...
Page 10 GENERAL VIEW A. Shredder housing Stand C. Collection bag D. Wheel capsx2 Wheels x2 Plunger G. Screws x 4 H. Hex key M8 Axe (includes 4 x washers and 2 x split pins) Stand supporting WWW.SGS-ENGINEERING.COM PAGE 10...
Page 11: Technical Specifications
TECHNICAL SPECIFICATIONS Rated voltage 230-240V, 50Hz Power 2800W Rated voltage 230-240V, 50Hz Power 2500W(P40) Collection bag Max. cutting dia. 45mm No-load speed 3600 rpm Sound pressure level(LpA) 97.5 dB(A),K=3.0 dB(A) Measured sound power level (LwA) 109.2 dB(A),K=3.0 dB(A) Guaranteed sound power level (LwA) 112dB(A) Weight 8.3kg...
Page 12 Remove the washers and split pins from the axle and fix the wheels as shown in the diagram below. Fix the stand supporting to stand with screws. Insert the stand to the motor housing, align the holes on the housing and stand, and fix with the 2 assembly screws using suitable screwdriver. WWW.SGS-ENGINEERING.COM PAGE 12...
Page 13 Hang the debris bag onto the debris bag hook as shown below. PAGE 13...
Page 14: Operation
13. Remove any jammed debris from the blades and examine them for any damage before re-commencing shredding. 14. If the blade has stalled for more than 5 seconds the safety overload switch will automatically switch the machine off. Allow the machine to cool down for at least 1 WWW.SGS-ENGINEERING.COM PAGE 14...
Page 15 minute before re-starting. Push the overload switch first and then push on the On/Off switch to re-start the machine. 15. If the cutting mechanism strikes any foreign object or if the shredder starts to make any unusual noise or vibration, immediately switch off and allow the cutting blades to stop.
Page 16 Load the material into the feed funnel. Insert the plunger into the feed funnel pushing the material onto the blade disc. Wait until all the material has been shredded before adding more material. WWW.SGS-ENGINEERING.COM PAGE 16...
Page 17 NOTE: Your fingers must never ent er the feed funnel. NOTE: Never use the tool if the hopper is not fitted. NOTE: Do not overreach. Collect the shredded material Shut-off the power unit before attaching or removing the bag. You can use either the collection bag supplied or place the shredder on a tarpaulin sheet to catch the shredded material.
Page 18 We do not recommend this be done as the weight of each blade is critical to maintain the balance of the cutting disc. Any imbalance could cause damage to the machine and possible injury to the operator. WWW.SGS-ENGINEERING.COM PAGE 18...
Page 19: Care And Maintenance
CARE AND MAINTENANCE Disconnect the shredder from the mains before carrying out any servicing or cleaning operations. Clean the exterior of the shredder using a moist cloth. Use only mild cleaning agents, never solvents or corrosive chemicals. Never wash the shredder using a pressure washer or hosepipe. Prevent water get into the machine.
Page 20: Troubleshooting Chart
Reversing the blade to clear jams section). Empty the collection box. The shredded material The pressure plate is not Adjust the pressure comes out in chains. in correct position. plate (refer to the Adjusting the pressure plate section) WWW.SGS-ENGINEERING.COM PAGE 20...
Page 21: Parts Diagram
PARTS DIAGRAM WWW.SGS-ENGINEERING.COM PAGE 21 CALL FOR ASSISTANCE: 01332 576 850...
Page 22 Qty Code No Product name No Product name Qty Code Hopper Assembly 908561 16 Power cord 908576 Deflector Assembly 908562 17 PCB 908577 Bolt M8*30 908563 18 Collection bag 908578 Elastic pad 908564 19 Wheel cover 908579 Flat pad 908565 20 Pin 908580 Press block...
Page 23 SGS Engineering (UK) Ltd Unit 1 West Side Park Raynesway Derby, DE21 7AZ EC Declaration of Conformity This is an important document and should be retained MANUFACTURER’S NAME: SGS Engineering (UK) Ltd TYPE OF EQUIPMENT: SGS 2400W Impact Shredder PART NUMBER:...
