SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL
B
1. User Manual ............................................................................................ p. 2
2. Legal Regulations ................................................................................... p. 2
3. Safety Instructions ................................................................................. p. 3
4. Controller Programming ........................................................................ p. 4
5. Functional Principle ............................................................................... p. 7
6. Technical Data ........................................................................................... p. 8
7. Mounting .................................................................................................. p. 10
8. Mounting Principle .................................................................................... p. 12
9. Cutout Dimensions ................................................................................. p. 13
10. Dimensions (H x W x D) ......................................................................... p. 13
11. Electrical Connection ............................................................................. p. 14
12. Wiring Diagram ....................................................................................... p. 15
13. Modbus Connection ............................................................................... p. 17
14. Taking Into Operation ............................................................................. p. 18
15. Troubleshooting ...................................................................................... p. 18
18. Parts Supplied ......................................................................................... p. 20
19. Warranty / Limits of Liability ................................................................. p. 20
Table of Contents SCE-NG5290B230V
1
Advertisement
Table of Contents
Related Manuals for SCE ENVIRO-THERM NEXTGEN SCE-NG5290B230V
Summary of Contents for SCE ENVIRO-THERM NEXTGEN SCE-NG5290B230V
-
Page 1: Table Of Contents
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL Table of Contents SCE-NG5290B230V 1. User Manual .................... p. 2 2. Legal Regulations ................... p. 2 3. Safety Instructions ................. p. 3 4. Controller Programming ................ p. 4 5. Functional Principle ................p. 7 6. -
Page 2: User Manual
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 1. User Manual This instruction manual contains information and instructions to enable the user to work safely, correctly and economically on the unit. Understanding and adhering to the manual can help one: •... -
Page 3: Safety Instructions
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 3. Safety Instructions Upon delivery the unit is already meeting current technical standards therefore it can be safely taken into operation. Only trained specialists are allowed to work on the unit. Unauthorized personnel must be prohibited from working on the unit. Operating personnel must inform their superiors immediately if any malfunction of the unit becomes apparent. -
Page 4: Controller Programming
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 4. DISP-1503 Controller Programming The cooling unit is intended to be used as a complementary accessory to larger industrial equipment. The unit is used where heat needs to be dissipated from electrical control cabinets or similar enclosures in order to protect heat sensitive components. - Page 5 SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL I) Operations from Home Screen • Pressing for 1 second will go to Menu 1. This will show the status of DI1, DI2, S1, S2 and Onboard Sensor. Pressing will toggle between sensors/digital inputs. •...
- Page 6 SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL Alarm codes Alarm Code Description AL1 - HI High Temp Alarm AL2 - LO Low Temp Alarm AL3 - PrEP Pressure Pipe Alarm AL4 - AbS Ambient Sensor Faulty AL5 - PPS Pressure Pipe Sensor Faulty AL6 - ICES Ice Sensor Faulty...
-
Page 7: Functional Principle
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 5. Functional Principle The cooling unit for enclosures works on the basis of a refrigeration circuit consisting of four main components: compressor, evaporator, condenser and expansion device. The circuit is hermetically sealed and R513a refrigerant circulates inside it (R513a is chlorine free and has an Ozone Destruction Potential [ODP] of 0 and a Global Warming Potential [GWP] of 1430). -
Page 8: Technical Data
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 6. Technical Data Part Number SCE-NG5290B230V Cooling Capacity @ 95°F / 95°F 5290 BTU 1.27 kW @ 50 Hz Cooling Capacity @ 95°F / 131°F 1.33 kW @ 60 Hz Compressor Rotary piston... - Page 9 SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL Short Circuit Current Rating for Air Conditioners and Heat Exchangers As per UL508A Supplement SB, Seifert Systems’ air conditioners have a default SCCR of 5 kA. If no additional measures are taken in the installation, the resulting SCCR rating in the control panel would be 5 kA, assuming that the air conditioner is the lowest rated component in the panel.
-
Page 10: Mounting
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 7. Mounting The power supply rating on unit rating plate must comply with mains rating. Always disconnect the power supply before opening the unit. Heat load to be dissipated from enclosure should not exceed specific cooling output of the unit at any condition. When selecting a cooling unit, always allow for a safety margin of at least 15% extra cooling output in the worst conditions. - Page 11 SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL Filter installation: If you install / replace a filter please follow the steps below. back to top Rev 1...
-
Page 12: Mounting Principle
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 8. Mounting Principle • Do not use within the first 15 minutes after installation! • Use only the supplied mounting hardware. • Tighten fasteners to 40 inch lb. 1. M6 Screws • Ensure the mounting surface does not warp after assembly and 2. -
Page 13: Cutout Dimensions
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 9. Cutout Dimensions 15.55 15.55 10.47 10.47 10.04 9.96 1.18 1.18 8.74 11.54 19.29 4.33 6.89 37.40 11.54 37.40 35.83 14.96 11.54 Ø.28 Ø.28 (x11) (x8) 11.26 10. Dimensions (H x W x D) 15.55 9.99 37.40... -
Page 14: Electrical Connection
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 11. Electrical Connection Caution, risk of death Unconnected and / or faulty protective conductor systems can lead to dangerous voltages and electric shocks which can cause serious accidents. Work on electrical connections may only be carried out by trained electrical engineers. Alarm Contacts Alarm contacts ratings: Maximum switching power 60 W / 125 VA, maximum switching voltage 220 VDC / 250 VAC, maximum switching... -
Page 15: Wiring Diagram
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 12. DISP-1503 Wiring Diagram Components: X1: Power connector X2: Signals/alarm connector X3: RS485 connector X4: 230V jumper X5: Auto transformer Mi: Internal fan Capacitor for Mi Ma: Ambient fan Ca: Capacitor for Ma Mc: Compressor Cc: Capacitor for Mc Internal temp. - Page 16 SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL Door switch Door switch L1 for 120/230 V High temp alarm NC N for 120/230 V High temp alarm com Ground High temp alarm NO Notes High temp alarm can be wired NC or NO When wires: P1 P2 –...
-
Page 17: Modbus Connection
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 13. Modbus Connection All Enviro-Therm units are offered standard Three pole Modbus connector ® with a Modbus connection SCE-NG2970B / SCE-NG5290B Modbus connector included SCE-NG1195B / SCE-NG2320B SCE-NG5100B SCE-NG6800B SCE-NG8500B / SCE-NG14300B... -
Page 18: Taking Into Operation
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 14. Taking Into Operation Attention! The unit can be damaged by lack of lubricant. To ensure that the compressor is adequately lubricated, the oil, which has been displaced during transport, must first be allowed to flow back into place. The unit must therefore be allowed to stand for at least 30 min. -
Page 19: Maintenance & Cleaning
SAGINAW CONTROL & ENGINEERING • A/C USER MANUAL 16. Maintenance & Cleaning Always switch power supply off before starting any maintenance on the unit. Wait for 5 minutes for electrical components to discharge. The cooling unit is generally maintenance free and can be operated without filters in most environments. If the ambient air is extremely dusty, we recommend installing filter mats (see accessories). -
Page 20: Parts Supplied
19. Warranty / Limits of Liability All goods manufactured by SCE shall be warranted to be free of defects in material or workmanship for a period of two years from the date of shipment. Should the product be proven to SCE to be defective, we shall option to repair or replace the product.
