Summary of Contents for CeoTronics CT-InlinePowerPack

  • Page 1 CT-InlinePowerPack Operating manual dok1860-en-03-0125 1 / 20...

  • Page 2: Table Of Contents

    Contents Safety notices........................ Introduction ........................Connection options ....................... Connecting power receivers..................Connecting an adapter cable ..................Operation ........................Operating elements....................... Insertig or replacing the battery pack / adapter............. Plug connectors ......................11 4.3.1 Connecting........................11 4.3.2 Disconnecting ......................12 Connecting ........................13 Power on ........................
  • Page 3 3 / 20 dok1860-en-03-0125...

  • Page 4: Safety Notices

    Safety notices DANGER Immediate hazardous situation. Results in death or serious injury. WARNING Potentially hazardous situation. May result in death or serious injury. CAUTION Potentially hazardous situation with minor or moderate injury. NOTICE Indicates a situation that, if not avoided, may cause damage to the product or other prop- erty.

  • Page 5: Introduction

    The CT-InlinePowerPack is a product for supplying power to CEOTRONICS products with a CT-ComLink® interface. Thanks to the additional CLB socket, the CT-InlinePowerPack can also be used for simultan- eous forwarding of a communication signal (e.g. radio). 5 / 20...

  • Page 6: Connection Options

    Connection options Connecting power receivers The CLB plug of the CT-InlinePowerPack is used to supply power to CEOTRONICS devices via their CLB socket. CT-ComLink Headset CT-DECT Case M7 CT-MultiPTT 3C CT-MultiPTT 1C CT-InlinePowerPack 6 / 20 dok1860-en-03-0125...

  • Page 7: Connecting An Adapter Cable

    CEOTRONICS product. CT-DECT Case M7 To do this, an adapter cable is connected to the CLB socket of the CT-InlinePowerPack. This CT-MultiPTT 3C adapter cable is then used to connect the CT-InlinePowerPack to e.g. a radio device.

  • Page 8: Operation

    Operation Operating elements CLB plug connector for power supply of CEOTRONICS products CLB socket connector for adapter cable with CLB plug battery compartment 8 / 20 dok1860-en-03-0125...

  • Page 9: Insertig Or Replacing The Battery Pack / Adapter

    Insertig or replacing the battery pack / adapter Both a Varta EasyPack XL and an adapter for AAA cells (rechargeable batteries or batteries) can be inserted into the CT-InlinePowerPack. NOTICE When using the adapter, batteries and rechargeable batteries must not be mixed in the ad- apter.
  • Page 10 NOTICE The lid of the battery compartment will be higher than normal if the battery pack / adapter is inserted incorrectly. Do not try to close the lid by applying excessive force. This will damage the device. Incorrect Correct NOTICE Check the seal when closing.

  • Page 11: Plug Connectors

    Plug connectors Ensure careful handling of the plug connectors. 4.3.1 Connecting Step 1 Place the plug on the socket. Make sure that the red dots on the plug and socket match. Step 2 Carefully turn the plug on the socket until it slightly slides into the socket.

  • Page 12: Disconnecting

    4.3.2 Disconnecting To release the plug grip it as close as possible to the socket: Avoid movements as shown in the following illustrations. NOTICE Improper handling can damage the connector. The locked connector may neither be twisted nor bent. Never pull on the cable to disconnect the connector. 12 / 20 dok1860-en-03-0125...

  • Page 13: Connecting

    The CT-InlinePowerPack is switched on and off via the CEOTRONICS product connected to the CLB plug. Make sure that the connected CEOTRONICS product is switched off when not in use to avoid unnecessary draining of the battery pack / batteries.

  • Page 14: Accessories

    Accessories Description Short code Part no Battery pack VARTAEasyPack XL AKKU-VARTAEP 4024006-ROAD 4-way battery charger for VARTA EasyPack XL LADE-VARTAEP4 4024004 AAA adapter for three AAA cells BATADAP3-AAA 4024005 Spare parts for battery compartment cover: ET-APSTK-IPP 6009021 • 2x seal •...

  • Page 15: Maintenance And Care

    Cleaning Clean your CEOTRONICS device with a suitable cloth moistened with clean water. If neces- sary, you can also use a mild soap solution, e.g. in the form of a hand dishwashing detergent or the following cleaning agents: •...

  • Page 16: Abbreviations And Terms

    Abbreviations and terms Abbreviation/term Explanation Battery and rechargeable battery size micro CT-ComLink® B B = blue is usually used to connect a communication device or the CT-InlinePowerPack 16 / 20 dok1860-en-03-0125...

  • Page 17: Labeling

    Labeling signing field manufacturer short name serial number article number 17 / 20 dok1860-en-03-0125...
  • Page 18 Notes 18 / 20 dok1860-en-03-0125...
  • Page 19 Notes 19 / 20 dok1860-en-03-0125...
  • Page 20 CEOTRONICS AG Adam-Opel-Str. 6 63322 Rödermark (Deutschland) Tel: +49 6074 8751-0 Fax: +49 6074 8751-676-265 E-Mail verkauf@ceotronics.com...
